1 - MOTOR HOUSING
BSD-3605108056.A1
3605108056
|
£21.52
|
£25.83
|
|
|
2 - STATOR 220-320W
BSD-3604090034.A6
3604090034
|
£21.68
|
£26.01
|
|
|
3 - ROTOR
BSD-3604220039.A0
3604220039
|
£81.81
|
£98.17
|
|
|
5 - BEARING FLANGE
BSD-3605700065.A11
3605700065
|
£10.10
|
£12.12
|
|
|
6 - GROOVE BALL BEARING 8x22x7
BSD-3600905124.A0
3600905124
|
£14.91
|
£17.89
|
|
|
7 - BEARING FLANGE
BSD-3605700064.A1
3605700064
|
£11.30
|
£13.56
|
|
|
8 - GROOVE BALL BEARING 7x14x5
BSD-1900905030.A41
1900905030
|
£33.74
|
£40.49
|
|
|
9 - O-RING 4.0x1.0 MM
BSD-3600210015.A6
3600210015
|
£3.72
|
£4.47
|
|
|
10 - NEEDLE ROLLER A 2x11.8G2DIN5402
BSD-1903201002.A29
1903201002
|
£1.75
|
£2.10
|
|
|
11 - SILENCER
BSD-3601010020.A1
3601010020
|
-
|
|
|
|
27 - SHIM
BSD-3600100090.A0
3600100090
|
£4.26
|
£5.11
|
|
|
30 - SPACER RING
BSD-3600209003.A2
3600209003
|
£5.58
|
£6.70
|
|
|
31 - CYLINDRICAL GEAR Z=14
BSD-3606316093.A70
3606316093
|
£2.61
|
£3.13
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A199
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A408
3603201000
|
£1.75
|
£2.10
|
|
|
34 - RETAINING SNAP RING
BSD-3600400008.A13
3600400008
|
£18.96
|
£22.75
|
|
|
37 - SHIM 0.3 MM
BSD-1600101618.A119
1600101618
|
£2.61
|
£3.13
|
|
|
39 - CYLINDRICAL GEAR Z=14
BSD-3606316073.A11
3606316073
|
£2.61
|
£3.13
|
|
|
41 - GROOVE BALL BEARING
BSD-3600900011.A1
3600900011
|
£27.23
|
£32.68
|
|
|
42 - O-RING 28x2 MM
BSD-1900210327.A12
1900210327
|
£4.26
|
£5.11
|
|
|
43 - O-RING 30x2.5 MM
BSD-1900210131.A35
1900210131
|
£4.26
|
£5.11
|
|
|
45 - SHIM
BSD-2600102036.A25
2600102036
|
£2.61
|
£3.13
|
|
|
50 - SHIM
BSD-2600102036.A26
2600102036
|
£2.61
|
£3.13
|
|
|
56 - FITTING
BSD-3603462019.A10
3603462019
|
£16.41
|
£19.69
|
|
|
57 - VALVE BUSHING
BSD-3600209004.A28
3600209004
|
£2.16
|
£2.59
|
|
|
60 - STRAINER
BSD-3600002006.A62
3600002006
|
£3.72
|
£4.47
|
|
|
61 - SILENCER
BSD-2607000179.A1
2607000179
|
£8.67
|
£10.41
|
|
|
65 - O-RING 15x2 MM
BSD-1900210112.A137
1900210112
|
£2.61
|
£3.13
|
|
|
67 - STRAIGHT PIN
BSD-3603201043.A0
3603201043
|
£2.16
|
£2.59
|
|
|
69 - SHIM WASHER
BSD-3600105001.A17
3600105001
|
£1.75
|
£2.10
|
|
|
74 - O-RING 12.0x2.0 MM
BSD-1610210233.A37
1610210233
|
£2.80
|
£3.36
|
|
|
75 - VALVE SPOOL
BSD-3608750031.A6
3608750031
|
£14.91
|
£17.89
|
|
|
77 - PUSH-BUTTON
BSD-3602053003.A21
3602053003
|
£2.61
|
£3.13
|
|
|
78 - COUNTERSUNK-HEAD SCREW M3x10-A2-70 DIN963
BSD-2918000052.A5
2918000052
|
£1.75
|
£2.10
|
|
|
79 - CONTROL LEVER
BSD-3602000000.A7
3602000000
|
£2.80
|
£3.36
|
|
|
83 - COMPRESSION SPRING
BSD-3604643012.A23
3604643012
|
£1.75
|
£2.10
|
|
|
88 - SILENCER
BSD-3601010001.A72
3601010001
|
£2.16
|
£2.59
|
|
|
92 - REFERENCE PLATE
BSD-3601110574.A24
3601110574
|
£2.61
|
£3.13
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A467
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601119055.A100
3601119055
|
£3.72
|
£4.47
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A854
3601119236
|
£3.72
|
£4.47
|
|
|
100 - BEARING HOUSING
BSD-3605125034.A0
3605125034
|
£54.42
|
£65.30
|
|
|
101 - CLUTCH ELEMENT
BSD-3606490005.A1
3606490005
|
£81.81
|
£98.17
|
|
|
102 - DRIVE SHAFT
BSD-3606490004.A0
3606490004
|
£93.88
|
£112.65
|
|
|
103 - BALL DIN 5401-8 MM III-ST
BSD-1903230014.A7
1903230014
|
£1.75
|
£2.10
|
|
|
104 - BUSHING
BSD-3600300021.A1
3600300021
|
£33.74
|
£40.49
|
|
|
105 - SUPPORTING DISC
BSD-3600100031.A1
3600100031
|
£8.67
|
£10.41
|
|
|
106 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A331
1903230004
|
£2.16
|
£2.59
|
|
|
107 - DISC SPRING
BSD-2600550018.A4
2600550018
|
£2.80
|
£3.36
|
|
|
108 - SUPPORTING DISC
BSD-2600103015.A1
2600103015
|
£7.36
|
£8.83
|
|
|
109 - COMPRESSION SPRING
BSD-2604619009.A17
2604619009
|
£2.80
|
£3.36
|
|
|
110 - RETAINING SNAP RING
BSD-2600501031.A0
2600501031
|
£14.91
|
£17.89
|
|
|
111 - STICKER
BSD-3601110030.A0
3601110030
|
£2.16
|
£2.59
|
|
|
113 - ADJUSTING NUT
BSD-3600460004.A0
3600460004
|
£54.42
|
£65.30
|
|
|
126 - LEAF SPRING
BSD-2601250001.A108
2601250001
|
£3.72
|
£4.47
|
|
|
128 - BALL DIN 5401-5 G28
BSD-1903230009.A623
1903230009
|
£1.75
|
£2.10
|
|
|
129 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A169
1903230003
|
£2.61
|
£3.13
|
|
|
652 - HOSE FITTING
BSD-3603386068.A15
3603386068
|
£21.52
|
£25.83
|
|
|
700 - SCREWDRIVER BLADE
BSD-2607000239.A11
2607000239
|
-
|
|
|
|
701 - DEPTH-GAUGE
BSD-2600460008.A0
2600460008
|
£16.96
|
£20.35
|
|
|
702 - DEPTH-GAUGE
BSD-2600460009.A25
2600460009
|
-
|
|
|
|
703 - GUIDE SLEEVE
BSD-3608548000.A0
3608548000
|
-
|
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030244.A6
3607030244
|
£23.86
|
£28.63
|
|
|
807 - DEPTH-GAUGE
BSD-2600460007.A31
2600460007
|
-
|
|
|
|
810 - VALVE SPOOL
BSD-3608750030.A1
3608750030
|
£33.74
|
£40.49
|
|
|
828 - RING GEAR Z=42/54
BSD-3606334021.A11
3606334021
|
£18.96
|
£22.75
|
|
|
829 - ASSEMBLY OF SERVICE PARTS
BSD-3607031322.A3
3607031322
|
£63.50
|
£76.20
|
|
|
844 - PARTS SET
BSD-3607010026.A41
3607010026
|
£8.67
|
£10.41
|
|
|
868 - VALVE CONE
BSD-3607030354.A8
3607030354
|
£14.91
|
£17.89
|
|
