2 - FIELD 230-240V
BSD-2604220480.A7
2604220480
|
£21.68
|
£26.01
|
|
|
4 - SWITCH
BSD-1607200158.A10
1607200158
|
£8.67
|
£10.41
|
|
|
5 - POWER SUPPLY CORD GB 230V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460140.A9
2604460140
|
£21.68
|
£26.01
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A708
2600703017
|
£2.61
|
£3.13
|
|
|
9 - MANUFACTURER'S NAMEPLATE PHO 3100
BSD-2609131526.A2
2609131526
|
£2.61
|
£3.13
|
|
|
12 - SUPPRESSION FILTER
BSD-2609120049.A14
2609120049
|
£2.61
|
£3.13
|
|
|
16 - BRUSH HOLDER
BSD-2609120334.A0
2609120334
|
£2.16
|
£2.59
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1066
2603490022
|
£1.75
|
£2.10
|
|
|
26 - ADJUSTING NUT
BSD-2609110728.A2
2609110728
|
£2.80
|
£3.36
|
|
|
28 - PULLEY
BSD-2609110268.A9
2609110268
|
£2.80
|
£3.36
|
|
|
29 - PULLEY
BSD-2609110267.A12
2609110267
|
£4.26
|
£5.11
|
|
|
30 - HANDLE
BSD-2609100589.A0
2609100589
|
£5.58
|
£6.70
|
|
|
31 - V-BELT
BSD-2609100410.A0
2609100410
|
£10.10
|
£12.12
|
|
|
32 - COVER
BSD-2609100585.A2
2609100585
|
£5.30
|
£6.36
|
|
|
33 - COMPRESSION SPRING
BSD-2609110077.A5
2609110077
|
£2.61
|
£3.13
|
|
|
35 - BRUSH-COVER
BSD-2609100583.A0
2609100583
|
£7.36
|
£8.83
|
|
|
37 - CAP-HANDLE
BSD-2609100140.A10
2609100140
|
£5.30
|
£6.36
|
|
|
38 - RATCHET DISC
BSD-2609110162.A13
2609110162
|
£2.61
|
£3.13
|
|
|
40 - AIR-DEFLECTOR RING
BSD-2609100028.A19
2609100028
|
£2.61
|
£3.13
|
|
|
41 - CONTACT STRAP
BSD-2601329053.A11
2601329053
|
£1.75
|
£2.10
|
|
|
43 - COILED SPRING PIN DIN 7343-5x2.5
BSD-2917800053.A1
2917800053
|
£2.16
|
£2.59
|
|
|
44 - SQUARE NUT M6
BSD-2603320004.A74
2603320004
|
£1.75
|
£2.10
|
|
|
46 - ADJUSTING SLIDE
BSD-2609110729.A0
2609110729
|
£23.86
|
£28.63
|
|
|
47 - RATCHET SPRING
BSD-2601254000.A54
2601254000
|
£1.75
|
£2.10
|
|
|
49 - HANDLE COVER
BSD-2609100582.A2
2609100582
|
£11.30
|
£13.56
|
|
|
57 - CONNECTING CABLE L=233 MM
BSD-2604448181.A24
2604448181
|
£2.16
|
£2.59
|
|
|
58 - CONNECTING CABLE L=213 MM
BSD-2604448118.A58
2604448118
|
£1.75
|
£2.10
|
|
|
60 - DEFLECTOR PIPE
BSD-2609100086.A2
2609100086
|
£5.58
|
£6.70
|
|
|
74 - PLANING KNIFE
BSD-2608635341.A68
2608635341
|
£16.41
|
£19.69
|
|
|
75 - SET SCREW
BSD-2603400016.A32
2603400016
|
£1.75
|
£2.10
|
|
|
76 - GRIPPING WEDGE
BSD-2603111001.A34
2603111001
|
£13.12
|
£15.75
|
|
|
80 - KNIFE GUARD
BSD-2609100088.A21
2609100088
|
£4.26
|
£5.11
|
|
|
81 - SPRING
BSD-2609110109.A12
2609110109
|
£2.80
|
£3.36
|
|
|
654 - OFFSET SCREWDRIVER DIN 911 SW2.5
BSD-1907950003.A45
1907950003
|
£2.61
|
£3.13
|
|
|
656 - STOP BRACKET
BSD-2608005015.A62
2608005015
|
£11.30
|
£13.56
|
|
|
657/1 - O-RING 4.0x1.5 MM
BSD-1610210043.A103
1610210043
|
£1.75
|
£2.10
|
|
|
657/2 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A221
2916011014
|
£1.75
|
£2.10
|
|
|
657/3 - WING SCREW M 6x16 MM
BSD-2603480003.A159
2603480003
|
£2.61
|
£3.13
|
|
|
657/4 - STOP BRACKET
BSD-1601332018.A91
1601332018
|
£3.72
|
£4.47
|
|
|
657/5 - ROUND-HEAD BOLT DIN 603-M6x20
BSD-2910281201.A103
2910281201
|
£1.75
|
£2.10
|
|
|
657/6 - WING NUT
BSD-2609199008.A0
2609199008
|
£1.75
|
£2.10
|
|
|
801 - HOUSING
BSD-2609100620.A2
2609100620
|
£40.80
|
£48.96
|
|
|
803 - ARMATURE 230-240V
BSD-2609199269.A2
2609199269
|
£37.27
|
£44.72
|
|
|
808 - NAMEPLATE
BSD-2609135765.A0
2609135765
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321933.A5
2604321933
|
£13.12
|
£15.75
|
|
|
813 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A506
1610905025
|
£6.52
|
£7.83
|
|
|
814 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A64
2600905052
|
£7.36
|
£8.83
|
|
|
825 - BEARING FLANGE
BSD-2609100622.A0
2609100622
|
£21.52
|
£25.83
|
|
|
827 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A505
1610905025
|
£6.52
|
£7.83
|
|
|
850 - GROOVE BALL BEARING 10x26x8
BSD-2600905064.A61
2600905064
|
£11.30
|
£13.56
|
|
|
870 - PLANER HEAD
BSD-2609110193.A2
2609110193
|
£59.53
|
£71.44
|
|
