An exploded drawing and listing for the Bosch PSR 12 VE / 0603937566 / EU 12 Volt
Ex VAT Inc VAT
1 - HOUSING SECTION BSD-2605104566.A1 2605104566 -
2/10 - PINION Z=9 BSD-2606316164.A26 2606316164 £4.26 £5.11
5 - ADJUSTING SLIDE BSD-2601099055.A77 2601099055 -
25 - KEY CHUCK dia 1-10 MM. 3/8 BSD-1608571047.A12 1608571047 -
25/7 - CHUCK WRENCH SG1. 80 MM BSD-1607950055.A27 1607950055 -
45 - PLANETARY GEAR TRAIN BSD-2606200054.A13 2606200054 -
93 - SCREWDRIVER BLADE 6 MM BSD-1609200147.A339 1609200147 £3.72 £4.47
96 - SUPPORT BSD-2608040079.A27 2608040079 £1.75 £2.10
101 - TORX OVAL-HEAD SCREW 3x18 BSD-2603490018.A715 2603490018 £1.75 £2.10
102 - RETAINING BRACKET BSD-2601329041.A134 2601329041 £2.33 £2.80
653 - FAST CHARGER EU 230/14.4V. 3-5h BSD-2607225011.A16 2607225011 -
654 - SLIDE-IN ACCU PACKAGE 12V. 1.5Ah. NiCd BSD-2607336145.A15 2607336145 -
797 - CARRYING LOOP BSD-2601398009.A139 2601398009 -
802 - DC MOTOR 12V BSD-2607022954.A4 2607022954 -
804 - ON-OFF SWITCH BSD-2607200353.A22 2607200353 -
809 - MANUFACTURER'S NAMEPLATE BSD-2601119104.A3 2601119104 -
820 - REFERENCE PLATE BSD-2601119105.A0 2601119105 -
899 - CORDLESS SCREW DRIVER BSD-0603937520.A2 0603937520 -
