1 - HOUSING SECTION
BSD-2605104366.A0
2605104366
|
-
|
|
|
|
2 - FIELD 230-240V
BSD-2604220447.A21
2604220447
|
£23.86
|
£28.63
|
|
|
3 - ARMATURE 220V
BSD-2604010715.A24
2604010715
|
-
|
|
|
|
3/60 - FAN
BSD-2606610049.A23
2606610049
|
£2.16
|
£2.59
|
|
|
4 - ON-OFF SWITCH
BSD-2607200218.A4
2607200218
|
-
|
|
|
|
5 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H05 VV-F
BSD-1604460015.A41
1604460015
|
-
|
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A439
2600703012
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A711
2600703013
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2240
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-2601118205.A0
2601118205
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A295
2607329114
|
-
|
|
|
|
16 - BRUSH PLATE
BSD-2609992612.A7
2609992612
|
-
|
|
|
|
16 - BRUSH PLATE
BSD-2609992612.A8
2609992612
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1728
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1806
2603490022
|
£1.75
|
£2.10
|
|
|
20 - STICKER
BSD-2601118206.A0
2601118206
|
-
|
|
|
|
25 - HOUSING COVER
BSD-2605500122.A0
2605500122
|
-
|
|
|
|
27 - GEAR COVER
BSD-2605500100.A6
2605500100
|
-
|
|
|
|
28 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A0
2603410048
|
£1.75
|
£2.10
|
|
|
30 - BASE PLATE
BSD-2608000074.A3
2608000074
|
-
|
|
|
|
31 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x10-8.8
BSD-2910141152.A46
2910141152
|
£1.75
|
£2.10
|
|
|
32 - PLAIN WASHER
BSD-3600100002.A0
3600100002
|
£1.75
|
£2.10
|
|
|
33 - COUNTERSUNK-HEAD SCREW DIN 7982-B3.9x13
BSD-2910601318.A5
2910601318
|
-
|
|
|
|
35 - LIFTING ROD
BSD-2600780017.A1
2600780017
|
-
|
|
|
|
36 - CLAMPING SADDLE
BSD-2601321012.A8
2601321012
|
-
|
|
|
|
37 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x12-12.9
BSD-2910405154.A38
2910405154
|
£1.95
|
£2.34
|
|
|
38 - SEALING DISK
BSD-2601334002.A29
2601334002
|
-
|
|
|
|
39 - FELT WASHER
BSD-2600108006.A34
2600108006
|
£1.75
|
£2.10
|
|
|
40 - SINTERED-METAL BUSHING
BSD-2600302004.A1
2600302004
|
-
|
|
|
|
41 - GUIDING PLATE
BSD-2601334009.A5
2601334009
|
-
|
|
|
|
46 - PIVOT PIN
BSD-2603105038.A3
2603105038
|
£3.34
|
£4.01
|
|
|
53 - NEEDLE-ROLLER ASSEMBLY
BSD-2600913003.A7
2600913003
|
£3.34
|
£4.01
|
|
|
55 - SHIM 1.0 MM
BSD-2600100647.A58
2600100647
|
£1.32
|
£1.58
|
|
|
55 - SHIM 0.2 MM
BSD-2600101614.A25
2600101614
|
-
|
|
|
|
56 - SHIM 0.5 MM
BSD-2600100039.A6
2600100039
|
£1.75
|
£2.10
|
|
|
62 - SPRING RETAINING RING DIN 471-10x1MM-FSt
BSD-2916650001.A24
2916650001
|
£2.61
|
£3.13
|
|
|
63 - SHIM 17 x 0.5
BSD-2600101674.A7
2600101674
|
-
|
|
|
|
63 - SHIM 17 x 0.2
BSD-2600101675.A2
2600101675
|
-
|
|
|
|
66 - SHIM WASHER
BSD-2600200027.A29
2600200027
|
-
|
|
|
|
74 - SPACER RING
BSD-2600200028.A6
2600200028
|
-
|
|
|
|
75 - FORK LEVER
BSD-2601923006.A3
2601923006
|
-
|
|
|
|
77 - SHIM
BSD-2600100040.A19
2600100040
|
£1.75
|
£2.10
|
|
|
79 - SHIM
BSD-2600100047.A34
2600100047
|
-
|
|
|
|
80 - CONTROL LEVER
BSD-2602026044.A5
2602026044
|
-
|
|
|
|
81 - RATCHET CAP
BSD-2600590006.A278
2600590006
|
£1.75
|
£2.10
|
|
|
82 - SHIM 0.5 MM
BSD-3600100013.A8
3600100013
|
-
|
|
|
|
82 - SHIM 0.2 MM
BSD-2600100050.A1
2600100050
|
-
|
|
|
|
83 - SPRING RETAINING RING DIN 471 9x1MM
BSD-2916640006.A13
2916640006
|
£1.75
|
£2.10
|
|
|
85 - REVERSE-TRANSFER LEVER
BSD-2601321016.A7
2601321016
|
-
|
|
|
|
86 - BEARING BOLT
BSD-2603100048.A5
2603100048
|
-
|
|
|
|
88 - COMPRESSION SPRING
BSD-2604617002.A6
2604617002
|
£1.75
|
£2.10
|
|
|
90 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A300
2916660008
|
£2.16
|
£2.59
|
|
|
93 - O-RING 5.0x1.5 MM
BSD-1900210000.A307
1900210000
|
£1.75
|
£2.10
|
|
|
95 - ROTARY HEAD
BSD-2602026045.A6
2602026045
|
-
|
|
|
|
96 - LOCKING LEVER
BSD-2602051000.A5
2602051000
|
-
|
|
|
|
97 - COMPRESSION SPRING
BSD-1604651007.A6
1604651007
|
-
|
|
|
|
98 - DAMPING PLATE
BSD-2601022000.A219
2601022000
|
£1.75
|
£2.10
|
|
|
100 - EARTH CONDUCTOR dia0.35 MM
BSD-2604448010.A50
2604448010
|
-
|
|
|
|
101 - CONNECTING CABLE L = 278 MM
BSD-2604448012.A78
2604448012
|
£1.32
|
£1.58
|
|
|
102 - CONNECTING CABLE L=180MM
BSD-2604448113.A8
2604448113
|
£1.75
|
£2.10
|
|
|
103 - CONNECTING CABLE L=243 MM
BSD-2604448033.A38
2604448033
|
-
|
|
|
|
104 - CONNECTING CABLE L=162MM
BSD-2604448122.A25
2604448122
|
-
|
|
|
|
105 - CONNECTING CABLE L=263MM
BSD-2604448119.A24
2604448119
|
£1.32
|
£1.58
|
|
|
106 - STICKER
BSD-2601110740.A4
2601110740
|
-
|
|
|
|
109 - CABLE L=233 MM
BSD-1614431010.A50
1614431010
|
£3.72
|
£4.47
|
|
|
110 - CONTACT SPRING
BSD-2601329057.A222
2601329057
|
-
|
|
|
|
757 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A289
2607950004
|
£1.75
|
£2.10
|
|
|
808 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A181
2912401020
|
£2.16
|
£2.59
|
|
|
810 - CARBON-BRUSH SET
BSD-2607014009.A30
2607014009
|
-
|
|
|
|
810/06 - RATCHET CAP
BSD-2601322017.A8
2601322017
|
£1.75
|
£2.10
|
|
|
810/06 - RATCHET CAP
BSD-2601322013.A487
2601322013
|
£1.75
|
£2.10
|
|
|
813 - NEEDLE BEARING
BSD-2600917902.A14
2600917902
|
-
|
|
|
|
814 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A348
2600905039
|
£12.04
|
£14.45
|
|
|
826 - GEAR HOUSING
BSD-2605806989.A5
2605806989
|
-
|
|
|
|
842 - POROUS BEARING
BSD-2602130901.A3
2602130901
|
-
|
|
|
|
847 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A440
2916080007
|
£2.61
|
£3.13
|
|
|
848 - CONNECTING ROD
BSD-2602130900.A6
2602130900
|
-
|
|
|
|
854 - LOCKING WASHER DIN 6799-7-FSt
BSD-2916080910.A268
2916080910
|
£2.16
|
£2.59
|
|
|
858 - ECCENTRIC COG WHEEL Z=45
BSD-2606320043.A7
2606320043
|
-
|
|
|
|
864 - NEEDLE-ROLLER CAGE
BSD-2607001130.A27
2607001130
|
£5.58
|
£6.70
|
|
|
870 - COUNTERWEIGHT
BSD-2608012002.A5
2608012002
|
-
|
|
|
|
878 - LOCKING WASHER DIN 6799-5-FSt
BSD-2916080008.A53
2916080008
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3HC.A227
160111A3HC
|
£2.61
|
£3.13
|
|
