1 - MOTOR HOUSING
BSD-1605108157.A1
1605108157
|
-
|
|
|
|
2 - FIELD 220-240V
BSD-1604220254.A71
1604220254
|
£21.68
|
£26.01
|
|
|
3/50 - FAN
BSD-1606610121.A181
1606610121
|
£1.75
|
£2.10
|
|
|
4 - ON-OFF SWITCH
BSD-1607200086.A179
1607200086
|
£11.30
|
£13.56
|
|
|
4/10 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A489
2910110048
|
£1.75
|
£2.10
|
|
|
5 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H05 VV-F
BSD-1604460148.A34
1604460148
|
-
|
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1417
2600703012
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A160
2600703011
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A109
2600703013
|
£2.61
|
£3.13
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A1081
1601302017
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110727.A1
1601110727
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328029.A73
1607328029
|
-
|
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1163
2600905032
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A468
1600905032
|
£5.58
|
£6.70
|
|
|
17 - MANUFACTURER'S NAMEPLATE
BSD-1601110728.A0
1601110728
|
-
|
|
|
|
18 - COMPRESSION SPRING
BSD-1604611026.A677
1604611026
|
£1.75
|
£2.10
|
|
|
21 - GEAR HOUSING
BSD-1605806429.A4
1605806429
|
£7.36
|
£8.83
|
|
|
22 - ADJUSTING SLIDE
BSD-1602319002.A112
1602319002
|
£2.61
|
£3.13
|
|
|
23 - SWITCH HANDLE
BSD-1602026057.A412
1602026057
|
£1.97
|
£2.36
|
|
|
25 - HOUSING COVER
BSD-1600508006.A1
1600508006
|
-
|
|
|
|
26 - RUBBER BUSHING
BSD-1600502020.A59
1600502020
|
£2.61
|
£3.13
|
|
|
27 - RUBBER RING
BSD-1600206025.A946
1600206025
|
£2.16
|
£2.59
|
|
|
28 - BEARING FLANGE
BSD-1605805061.A69
1605805061
|
£10.10
|
£12.12
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1601328005.A135
1601328005
|
£2.61
|
£3.13
|
|
|
32 - GRINDING SPINDLE
BSD-1607000D6A.A379
1607000D6A
|
£7.36
|
£8.83
|
|
|
35 - SHIM 0.2 MM
BSD-1600136010.A189
1600136010
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.3 MM
BSD-1600136011.A140
1600136011
|
£2.16
|
£2.59
|
|
|
35 - SHIM 0.1 MM
BSD-1600136012.A183
1600136012
|
£1.75
|
£2.10
|
|
|
36 - SPRING WASHER
BSD-1600150011.A239
1600150011
|
£1.75
|
£2.10
|
|
|
38 - CROWN GEAR Z=36
BSD-1606333606.A80
1606333606
|
£11.30
|
£13.56
|
|
|
39 - SPIRAL SPRING
BSD-1604652013.A1046
1604652013
|
£1.75
|
£2.10
|
|
|
40 - SPRING RETAINING RING DIN 472-25x1.2MM
BSD-2916660009.A14
2916660009
|
£2.16
|
£2.59
|
|
|
41 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A591
1600910018
|
£5.30
|
£6.36
|
|
|
43 - BEVEL GEAR Z=11
BSD-1606333605.A17
1606333605
|
£3.72
|
£4.47
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A358
1603300016
|
£1.75
|
£2.10
|
|
|
47 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A168
2910211018
|
£1.75
|
£2.10
|
|
|
48 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A157
2910211005
|
£1.75
|
£2.10
|
|
|
49 - TAPPING SCREW DIN7981-ST3.9x19-F-Z
BSD-2912401420.A205
2912401420
|
£1.75
|
£2.10
|
|
|
50 - TAPPING SCREW DIN7981-ST3.9x19-F-Z
BSD-2912401420.A206
2912401420
|
£1.75
|
£2.10
|
|
|
53 - CONNECTING CABLE
BSD-1604448015.A68
1604448015
|
£1.75
|
£2.10
|
|
|
54 - CONNECTING CABLE
BSD-1604448016.A79
1604448016
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN7981-ST3.9x19-F-Z
BSD-2912401420.A207
2912401420
|
£1.75
|
£2.10
|
|
|
650/10 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A482
160202509T
|
£3.72
|
£4.47
|
|
|
650/20 - ROUND NUT M14
BSD-1603345043.A1160
1603345043
|
£8.67
|
£10.41
|
|
|
650/30 - PIN-TYPE FACE-WRENCH
BSD-1607950052.A380
1607950052
|
£3.72
|
£4.47
|
|
|
650/40 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A399
2605703014
|
£7.36
|
£8.83
|
|
|
650/40/20 - O-RING 20.35x1.78 MM
BSD-1600210039.A1009
1600210039
|
£2.16
|
£2.59
|
|
|
650/50 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A465
2607950511
|
£4.26
|
£5.11
|
|
|
652 - PROTECTIVE COVER dia 115 MM(4 1/2)
BSD-2605510125.A94
2605510125
|
£27.23
|
£32.68
|
|
|
652/20 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A196
2910022197
|
-
|
|
|
|
803 - ARMATURE WITH FAN 230-240V
BSD-1604010259.A33
1604010259
|
-
|
|
|
|
805 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H05 VV-F
BSD-1604460148.A33
1604460148
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3HC.A69
160111A3HC
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014116.A236
1607014116
|
£11.30
|
£13.56
|
|
|
816 - BRUSH HOLDER
BSD-1600A003G4.A365
1600A003G4
|
£3.72
|
£4.47
|
|
|
838 - CROWN GEAR
BSD-1607000943.A11
1607000943
|
£23.86
|
£28.63
|
|
