1 - MOTOR HOUSING
BSD-1605108129.A7
1605108129
|
-
|
|
|
|
2 - FIELD 220-230V
BSD-1604220354.A15
1604220354
|
£33.74
|
£40.49
|
|
|
3 - ARMATURE 220V
BSD-1604010320.A3
1604010320
|
-
|
|
|
|
3/50 - FAN
BSD-1606610126.A19
1606610126
|
£7.36
|
£8.83
|
|
|
4 - SWITCH
BSD-1607200080.A4
1607200080
|
£37.27
|
£44.72
|
|
|
5 - POWER SUPPLY CORD I 4.15m 2 x 1.0mm H07 RN-F
BSD-1614460039.A37
1614460039
|
£16.74
|
£20.09
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1293
3600703011
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A654
1601302014
|
£2.61
|
£3.13
|
|
|
8 - NAMEPLATE
BSD-160111A3H3.A2554
160111A3H3
|
£2.61
|
£3.13
|
|
|
9 - STICKER
BSD-1601110046.A5
1601110046
|
£1.75
|
£2.10
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328034.A357
1607328034
|
£4.26
|
£5.11
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1206
2600905032
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING
BSD-3600905065.A0
3600905065
|
-
|
|
|
|
17 - SPIRAL SPRING
BSD-1604652006.A9
1604652006
|
£1.75
|
£2.10
|
|
|
19 - SEALING CAP
BSD-1605500109.A22
1605500109
|
-
|
|
|
|
20 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2185
2910211019
|
£1.75
|
£2.10
|
|
|
21 - AIR-DEFLECTOR RING
BSD-1600591009.A0
1600591009
|
-
|
|
|
|
24 - HANDLE
BSD-1605132116.A0
1605132116
|
-
|
|
|
|
27 - INTERMEDIATE RING
BSD-1600206026.A28
1600206026
|
£1.75
|
£2.10
|
|
|
28 - INTERMEDIATE RING
BSD-1600502011.A142
1600502011
|
£2.61
|
£3.13
|
|
|
30 - TAB WASHER
BSD-1601030022.A119
1601030022
|
£1.75
|
£2.10
|
|
|
31 - GEAR HOUSING
BSD-1605806425.A1
1605806425
|
-
|
|
|
|
32 - CROWN GEAR Z=55
BSD-1606333603.A6
1606333603
|
-
|
|
|
|
32 - CROWN GEAR Z=55
BSD-1606333603.A7
1606333603
|
-
|
|
|
|
33 - BEVEL GEAR Z=12
BSD-1606333232.A1
1606333232
|
-
|
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A248
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A35
1600190005
|
£1.32
|
£1.58
|
|
|
35 - ROTARY SHAFT LIP SEAL
BSD-1600290018.A7
1600290018
|
£4.26
|
£5.11
|
|
|
37 - SPRING WASHER
BSD-1600150026.A19
1600150026
|
£2.80
|
£3.36
|
|
|
38 - SPRING RETAINING RING
BSD-1600119009.A18
1600119009
|
£1.75
|
£2.10
|
|
|
39 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A683
2600910001
|
£4.26
|
£5.11
|
|
|
40 - BEARING COVER
BSD-1605808054.A5
1605808054
|
-
|
|
|
|
41 - COVER DISC
BSD-1600102012.A103
1600102012
|
-
|
|
|
|
42 - GRINDING SPINDLE M14. L=101 MM
BSD-1603523090.A44
1603523090
|
-
|
|
|
|
43 - SEALING DISK
BSD-1600108055.A285
1600108055
|
£1.75
|
£2.10
|
|
|
45 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A95
2910011162
|
£1.75
|
£2.10
|
|
|
46 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A247
2910011157
|
-
|
|
|
|
47 - GROOVE BALL BEARING 17x40x12
BSD-1900905203.A14
1900905203
|
-
|
|
|
|
48 - TAPPING SCREW
BSD-3603435037.A3
3603435037
|
-
|
|
|
|
50 - HEX NUT
BSD-1603300017.A25
1603300017
|
-
|
|
|
|
53 - STICKER
BSD-1601110456.A3
1601110456
|
-
|
|
|
|
54 - REFERENCE PLATE
BSD-1601110476.A2
1601110476
|
-
|
|
|
|
57 - WIRE GUIDE
BSD-1601025001.A57
1601025001
|
£1.75
|
£2.10
|
|
|
59 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A953
2910211021
|
£1.75
|
£2.10
|
|
|
60 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1686
2910021118
|
£1.75
|
£2.10
|
|
|
61 - TAPPING SCREW B4.8x38 MM
BSD-1603435011.A2
1603435011
|
-
|
|
|
|
62 - CONNECTING CABLE L=235 MM
BSD-3604438000.A4
3604438000
|
-
|
|
|
|
63 - BLADE TERMINAL
BSD-1604477001.A123
1604477001
|
£1.75
|
£2.10
|
|
|
64 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A140
2910211018
|
£1.75
|
£2.10
|
|
|
65 - END SPLICE DIN 46 228-A2.5-7
BSD-1900452003.A149
1900452003
|
£2.61
|
£3.13
|
|
|
650/60 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A555
1907950007
|
£5.30
|
£6.36
|
|
|
652/20 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x18-8.8
BSD-2910141240.A117
2910141240
|
£1.32
|
£1.58
|
|
|
712/10 - PROTECTIVE COVER dia 180 MM
BSD-1605510110.A0
1605510110
|
-
|
|
|
|
712/10/40 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x18-8.8
BSD-2910141240.A118
2910141240
|
£1.32
|
£1.58
|
|
|
712/20/30 - ROUND-HEAD BOLT DIN 603-M 8x25
BSD-2910281244.A237
2910281244
|
-
|
|
|
|
712/20/40 - WING NUT DIN 315-M8-GT-C
BSD-2915191007.A142
2915191007
|
£3.72
|
£4.47
|
|
|
712/20/50 - PLAIN WASHER DIN 315-M8-GT-C
BSD-2600100041.A37
2600100041
|
£1.75
|
£2.10
|
|
|
712/20/60 - COMPRESSION SPRING
BSD-1604643003.A117
1604643003
|
£6.52
|
£7.83
|
|
|
750/10 - AUXILIARY HANDLE M14x1.5 MM
BSD-2602025075.A27
2602025075
|
£10.30
|
£12.36
|
|
|
750/20 - SINGLE-HEAD ENG. WRENCH SW17
BSD-1607950525.A8
1607950525
|
£2.70
|
£3.24
|
|
|
750/30 - PIN-TYPE FACE-WRENCH
BSD-1607950048.A126
1607950048
|
£4.88
|
£5.86
|
|
|
750/40 - CLAMPING-FLANGE dia45 MM
BSD-2600501006.A371
2600501006
|
£16.43
|
£19.72
|
|
|
750/50 - ROUND NUT M14
BSD-1603345025.A13
1603345025
|
£8.21
|
£9.85
|
|
|
752 - PROTECTIVE COVER dia 180 MM
BSD-1605510154.A1
1605510154
|
-
|
|
|
|
801 - BRUSH HOLDER
BSD-3604336012.A21
3604336012
|
£5.58
|
£6.70
|
|
|
810 - CARBON BRUSH
BSD-1607014125.A21
1607014125
|
-
|
|
|
