1 - MOTOR HOUSING
BSD-1605108127.A3
1605108127
|
-
|
|
|
2 - FIELD 230-240V
BSD-1604220325.A2
1604220325
|
-
|
|
|
3/50 - FAN
BSD-1606610121.A32
1606610121
|
£1.75
|
£2.10
|
|
4 - ON-OFF SWITCH
BSD-1607200086.A2
1607200086
|
£11.30
|
£13.56
|
|
4/10 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A159
2910110048
|
£1.75
|
£2.10
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A424
2600703012
|
£2.80
|
£3.36
|
|
6 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A751
2600703011
|
£2.80
|
£3.36
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A714
2600703013
|
£2.61
|
£3.13
|
|
7 - FASTENING CLAMP
BSD-1601302017.A353
1601302017
|
£1.75
|
£2.10
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601118174.A3
1601118174
|
£3.80
|
£4.56
|
|
12 - SUPPRESSION FILTER
BSD-1607328029.A145
1607328029
|
-
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1831
2600905032
|
£5.30
|
£6.36
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A163
1600905032
|
£5.58
|
£6.70
|
|
17 - MANUFACTURER'S NAMEPLATE
BSD-1601118154.A13
1601118154
|
£2.33
|
£2.80
|
|
18 - COMPRESSION SPRING
BSD-1604611026.A199
1604611026
|
£1.75
|
£2.10
|
|
21 - GEAR HOUSING
BSD-1605806429.A29
1605806429
|
£7.36
|
£8.83
|
|
22 - ADJUSTING SLIDE
BSD-1602319002.A239
1602319002
|
£2.61
|
£3.13
|
|
23 - SWITCH HANDLE
BSD-1602026057.A36
1602026057
|
£1.97
|
£2.36
|
|
25 - HOUSING COVER
BSD-1600508005.A5
1600508005
|
£3.80
|
£4.56
|
|
26 - RUBBER BUSHING
BSD-1600502020.A363
1600502020
|
£2.61
|
£3.13
|
|
27 - RUBBER RING
BSD-1600206025.A6
1600206025
|
£2.16
|
£2.59
|
|
28 - BEARING FLANGE
BSD-1605805061.A21
1605805061
|
£10.10
|
£12.12
|
|
29 - AIR-DEFLECTOR RING
BSD-1601328005.A27
1601328005
|
£2.61
|
£3.13
|
|
32 - GRINDING SPINDLE
BSD-1607000D6A.A575
1607000D6A
|
£7.36
|
£8.83
|
|
35 - SHIM 0.1 MM
BSD-1600136012.A252
1600136012
|
£1.75
|
£2.10
|
|
35 - SHIM 0.2 MM
BSD-1600136010.A257
1600136010
|
£2.61
|
£3.13
|
|
35 - SHIM 0.3 MM
BSD-1600136011.A72
1600136011
|
£2.16
|
£2.59
|
|
36 - SPRING WASHER
BSD-1600150011.A76
1600150011
|
£1.75
|
£2.10
|
|
38 - CROWN GEAR Z=36
BSD-1606333606.A14
1606333606
|
£11.30
|
£13.56
|
|
39 - SPIRAL SPRING
BSD-1604652013.A149
1604652013
|
£1.75
|
£2.10
|
|
40 - SPRING RETAINING RING DIN 472-25x1.2MM
BSD-2916660009.A253
2916660009
|
£2.16
|
£2.59
|
|
41 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A330
1600910018
|
£5.30
|
£6.36
|
|
43 - BEVEL GEAR Z=11
BSD-1606333605.A85
1606333605
|
£3.72
|
£4.47
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A727
1603300016
|
£1.75
|
£2.10
|
|
47 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A347
2910211018
|
£1.75
|
£2.10
|
|
48 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A199
2910211005
|
£1.75
|
£2.10
|
|
49 - TAPPING SCREW DIN7981-ST3.9x19-F-Z
BSD-2912401420.A250
2912401420
|
£1.75
|
£2.10
|
|
50 - TAPPING SCREW DIN7981-ST3.9x19-F-Z
BSD-2912401420.A251
2912401420
|
£1.75
|
£2.10
|
|
53 - CONNECTING CABLE
BSD-1604448015.A112
1604448015
|
£1.75
|
£2.10
|
|
54 - CONNECTING CABLE
BSD-1604448016.A35
1604448016
|
£1.75
|
£2.10
|
|
55 - TAPPING SCREW DIN7981-ST3.9x19-F-Z
BSD-2912401420.A252
2912401420
|
£1.75
|
£2.10
|
|
650/20 - ROUND NUT M14
BSD-1603345043.A113
1603345043
|
£8.67
|
£10.41
|
|
650/30 - PIN-TYPE FACE-WRENCH
BSD-1607950052.A475
1607950052
|
£3.72
|
£4.47
|
|
650/40 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A115
2605703014
|
£7.36
|
£8.83
|
|
650/40/20 - O-RING 20.35x1.78 MM
BSD-1600210039.A1450
1600210039
|
£2.16
|
£2.59
|
|
650/50 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A169
2607950511
|
£4.26
|
£5.11
|
|
651/10 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A246
160202509T
|
£3.72
|
£4.47
|
|
652 - PROTECTIVE COVER dia 115 MM(4 1/2)
BSD-2605510125.A7
2605510125
|
£27.23
|
£32.68
|
|
652/20 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A66
2910022197
|
-
|
|
|
803 - ARMATURE WITH FAN 230-240V
BSD-1604010615.A0
1604010615
|
-
|
|
|
805 - POWER SUPPLY CORD
BSD-1603460163.A0
1603460163
|
-
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A4414
160111A3H3
|
£2.61
|
£3.13
|
|
810 - CARBON-BRUSH SET
BSD-1607014116.A70
1607014116
|
£11.30
|
£13.56
|
|
816 - BRUSH HOLDER
BSD-1600A003G4.A14
1600A003G4
|
£3.72
|
£4.47
|
|
838 - CROWN GEAR
BSD-1607000943.A44
1607000943
|
£23.86
|
£28.63
|
|
896 - FAST LOCKING FLANGE M14. SDS-CLIC
BSD-1603340027.A63
1603340027
|
£46.82
|
£56.18
|
|
