1 - MOTOR HOUSING
BSD-1605108110.A6
1605108110
|
-
|
|
|
|
2 - FIELD 220V
BSD-1604220175.A9
1604220175
|
-
|
|
|
|
3 - ARMATURE 220V
BSD-1604010187.A13
1604010187
|
-
|
|
|
|
4 - SWITCH
BSD-2607200084.A42
2607200084
|
£10.10
|
£12.12
|
|
|
4 - ON-OFF SWITCH
BSD-2607200109.A6
2607200109
|
-
|
|
|
|
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460403.A164
1604460403
|
£16.41
|
£19.69
|
|
|
6 - GROMMET dia6.4-dia7.5x75 MM
BSD-1600703016.A240
1600703016
|
£1.75
|
£2.10
|
|
|
6 - GROMMET dia9.5 MM
BSD-2600703006.A224
2600703006
|
-
|
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A320
2600703013
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-2601035001.A681
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-1601110046.A90
1601110046
|
£1.75
|
£2.10
|
|
|
11 - SUPPRESSION CAPACITOR
BSD-1607328023.A1
1607328023
|
-
|
|
|
|
13 - STICKER
BSD-1601110092.A5
1601110092
|
-
|
|
|
|
15 - PROTECTIVE COVER
BSD-1605510127.A6
1605510127
|
-
|
|
|
|
16 - CIRCULAR SAW BLADE dia16xdia190x1.4x2.4MM
BSD-1608640029.A2
1608640029
|
-
|
|
|
|
17 - BEARING COVER
BSD-1605808059.A10
1605808059
|
-
|
|
|
|
18 - GEAR HOUSING
BSD-1605806377.A0
1605806377
|
-
|
|
|
|
19 - INTERMEDIATE RING
BSD-1600206018.A19
1600206018
|
-
|
|
|
|
20 - RETAINING RING 35 DIN 9045
BSD-2916600018.A32
2916600018
|
£1.75
|
£2.10
|
|
|
21 - GROOVE BALL BEARING
BSD-1600905003.A71
1600905003
|
-
|
|
|
|
21 - GROOVE BALL BEARING 15x32x9
BSD-1600905004.A35
1600905004
|
-
|
|
|
|
22 - FILLING PIECE
BSD-1605500111.A5
1605500111
|
-
|
|
|
|
23 - AIR-DEFLECTOR RING
BSD-1600502014.A22
1600502014
|
-
|
|
|
|
24 - TAPPING SCREW 4.80x75 MM
BSD-3603435508.A22
3603435508
|
-
|
|
|
|
25 - SEALING CAP
BSD-1605500109.A6
1605500109
|
-
|
|
|
|
26 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1446
2910021118
|
£1.75
|
£2.10
|
|
|
27 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A670
2915011005
|
£1.75
|
£2.10
|
|
|
28 - INTERMEDIATE RING
BSD-1600502011.A111
1600502011
|
£2.61
|
£3.13
|
|
|
29 - BALL BEARING 7x19x6
BSD-2600905032.A38
2600905032
|
£5.30
|
£6.36
|
|
|
30 - HOUSING COVER
BSD-1605500112.A6
1605500112
|
-
|
|
|
|
32 - HANDLE
BSD-1605132092.A5
1605132092
|
-
|
|
|
|
33 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2023
2910211019
|
£1.75
|
£2.10
|
|
|
35 - SOCKET HEAD CAP SCREW DIN 84-AM5x16-8.8
BSD-2910021158.A45
2910021158
|
£1.32
|
£1.58
|
|
|
36 - PROTECTIVE COVER dia 115 MM
BSD-1605510125.A9
1605510125
|
-
|
|
|
|
37 - PLAIN WASHER 0.3 MM
BSD-1600100633.A148
1600100633
|
-
|
|
|
|
38 - PAN HEAD SCREW DIN 923-M5x5-5.8
BSD-2910271147.A34
2910271147
|
-
|
|
|
|
39 - SPIRAL SPRING
BSD-1604652009.A1
1604652009
|
-
|
|
|
|
40 - ROUND-HEAD GROOVED PIN 2.6x3 DIN 1476-ST
BSD-2917721051.A115
2917721051
|
-
|
|
|
|
41 - CONICAL SPRING WASHER SW 46
BSD-1605703069.A104
1605703069
|
-
|
|
|
|
42 - HEX SOCKET HEAD CAP SCREW M6x14 MM
BSD-1603414007.A268
1603414007
|
£2.29
|
£2.75
|
|
|
43 - CONICAL SPRING WASHER
BSD-1605703071.A6
1605703071
|
-
|
|
|
|
44 - SOCKET HEAD CAP SCREW DIN 84-AM5x12-8.8
BSD-2910021154.A83
2910021154
|
£1.75
|
£2.10
|
|
|
45 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A370
2916680006
|
-
|
|
|
|
46 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A525
1900905163
|
£11.30
|
£13.56
|
|
|
47 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A373
2916660014
|
£1.75
|
£2.10
|
|
|
48 - SPRING WASHER dia27.5xdia34.8x0.5 MM
BSD-1600150008.A26
1600150008
|
-
|
|
|
|
49 - CYLINDRICAL GEAR Z=41
BSD-1606320076.A16
1606320076
|
-
|
|
|
|
50 - DRIVE SHAFT
BSD-1603124105.A9
1603124105
|
-
|
|
|
|
51 - SHIM 0.5 MM
BSD-1600100631.A374
1600100631
|
£1.75
|
£2.10
|
|
|
52 - NEEDLE BEARING
BSD-1600910013.A72
1600910013
|
£5.58
|
£6.70
|
|
|
53 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A97
1603435006
|
-
|
|
|
|
54 - LENS HEAD SCREW
BSD-3603435025.A1
3603435025
|
£1.75
|
£2.10
|
|
|
55 - TAB WASHER
BSD-1601030022.A142
1601030022
|
£1.75
|
£2.10
|
|
|
56 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A158
2910211011
|
£1.75
|
£2.10
|
|
|
57 - BASE PLATE 110x298 MM
BSD-1608000075.A29
1608000075
|
-
|
|
|
|
58 - RUBBER BUFFER
BSD-1602386002.A142
1602386002
|
-
|
|
|
|
59 - PERFORATED PANEL M6-20x10x5 MM
BSD-1601030025.A3
1601030025
|
-
|
|
|
|
60 - PLAIN WASHER dia6.4xdia16x2 MM
BSD-1609201082.A213
1609201082
|
-
|
|
|
|
61 - HEX SOCKET HEAD CAP SCREW DIN 6912 M6x12-8.8
BSD-2910375193.A132
2910375193
|
-
|
|
|
|
62 - RIVING KNIFE
BSD-1600025012.A25
1600025012
|
-
|
|
|
|
63 - WING NUT M6
BSD-1603339006.A33
1603339006
|
£2.52
|
£3.02
|
|
|
64 - ROUND-HEAD BOLT DIN 603-M6x20
BSD-2910281201.A138
2910281201
|
£1.75
|
£2.10
|
|
|
65 - SLIDE PLATE
BSD-1601030026.A63
1601030026
|
-
|
|
|
|
66 - DIAL
BSD-1608000076.A20
1608000076
|
-
|
|
|
|
67 - SPIRAL SPRING
BSD-1604652006.A143
1604652006
|
£1.75
|
£2.10
|
|
|
70 - CLAMPING PIECE
BSD-1601030024.A82
1601030024
|
-
|
|
|
|
71 - COUNTERSUNK-HEAD SCREW M6x20 MM
BSD-1603490000.A35
1603490000
|
-
|
|
|
|
72 - SEAL
BSD-1601015016.A5
1601015016
|
-
|
|
|
|
73 - DAMPING PLATE
BSD-2601022000.A554
2601022000
|
£1.75
|
£2.10
|
|
|
74 - TAPPING SCREW DIN 7971-B4.8x19
BSD-2910211234.A42
2910211234
|
£1.75
|
£2.10
|
|
|
75 - TAB WASHER
BSD-1611331007.A1
1611331007
|
£1.32
|
£1.58
|
|
|
76 - INTERMEDIATE RING
BSD-1600300086.A2
1600300086
|
-
|
|
|
|
77 - ROTARY SHAFT LIP SEAL
BSD-1600290012.A37
1600290012
|
-
|
|
|
|
78 - PLAIN WASHER DIN 433-6.4-ST 50
BSD-2916011013.A78
2916011013
|
£1.75
|
£2.10
|
|
|
79 - SOCKET-TERMINAL STRIP 1x1.5 MM/2
BSD-1901091012.A213
1901091012
|
£5.30
|
£6.36
|
|
|
80 - CONNECTING CABLE L=260 MM
BSD-1604440008.A29
1604440008
|
-
|
|
|
|
80/20 - TERMINAL LUG
BSD-1601353003.A100
1601353003
|
-
|
|
|
|
81 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A278
1907950006
|
£4.26
|
£5.11
|
|
|
82 - LEAF SPRING
BSD-1601253007.A31
1601253007
|
-
|
|
|
|
84 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A687
2603410001
|
£1.75
|
£2.10
|
|
|
650 - END STOP
BSD-1601336004.A15
1601336004
|
-
|
|
|
|
700/1 - CONICAL SPRING WASHER
BSD-1600120071.A4
1600120071
|
-
|
|
|
|
700/2 - WOBBLING-DISC
BSD-1600132001.A11
1600132001
|
-
|
|
|
|
700/3 - CIRCULAR SAW BLADE Z= 12
BSD-1608640043.A6
1608640043
|
-
|
|
|
|
700/4 - SLOTTED SPRING PIN 3x8 DIN 1481
BSD-2917760075.A25
2917760075
|
-
|
|
|
|
700/5 - WOBBLING-DISC
BSD-1600132002.A4
1600132002
|
-
|
|
|
|
700/6 - DRIVE BUSHING
BSD-1600390009.A5
1600390009
|
-
|
|
|
|
700/7 - HEX SOCKET HEAD CAP SCREW M 6x16 DIN 6912-8.8
BSD-2910372197.A10
2910372197
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014126.A65
1607014126
|
£16.41
|
£19.69
|
|
|
868 - BRUSH HOLDER
BSD-1604336017.A219
1604336017
|
£7.36
|
£8.83
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1527
160111A3H3
|
£2.61
|
£3.13
|
|
