1 - MOTOR HOUSING
BSD-1605108137.A7
1605108137
|
-
|
|
|
|
2 - FIELD 240V
BSD-1604220194.A29
1604220194
|
£23.86
|
£28.63
|
|
|
3 - ARMATURE 220V
BSD-1604010183.A20
1604010183
|
£48.38
|
£58.06
|
|
|
4 - SWITCH
BSD-2607200367.A18
2607200367
|
£7.78
|
£9.33
|
|
|
5 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A171
1607000386
|
£21.52
|
£25.83
|
|
|
5/20 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A444
1900452012
|
£1.75
|
£2.10
|
|
|
6 - GROMMET dia6.4-dia7.5x75 MM
BSD-1600703016.A231
1600703016
|
£1.75
|
£2.10
|
|
|
7 - CABLE CLIP
BSD-2601035001.A669
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601110601.A66
2601110601
|
-
|
|
|
|
11 - FAN
BSD-2606610049.A424
2606610049
|
£2.16
|
£2.59
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A650
1607328028
|
£5.30
|
£6.36
|
|
|
12/20 - BLADE TERMINAL
BSD-2601355007.A160
2601355007
|
-
|
|
|
|
13 - NEEDLE BEARING dia7 MM
BSD-2600910006.A12
2600910006
|
£3.72
|
£4.47
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A579
2600905021
|
£8.67
|
£10.41
|
|
|
15 - CONNECTING CABLE
BSD-2604448059.A30
2604448059
|
-
|
|
|
|
15 - CONNECTING CABLE L = 278 MM
BSD-2604448012.A24
2604448012
|
£1.32
|
£1.58
|
|
|
16 - SUPPRESSION FILTER
BSD-2604465054.A28
2604465054
|
-
|
|
|
|
17 - GEAR HOUSING
BSD-1605806420.A2
1605806420
|
-
|
|
|
|
18 - COVERING HOOD
BSD-1605510163.A2
1605510163
|
-
|
|
|
|
19 - BASE PLATE 145x290 MM
BSD-1608000106.A10
1608000106
|
-
|
|
|
|
20 - PARTS SET
BSD-1607000218.A18
1607000218
|
-
|
|
|
|
21 - DRIVE SHAFT M6. dia12 MM
BSD-1603124114.A10
1603124114
|
£8.49
|
£10.19
|
|
|
22 - CYLINDRICAL GEAR Z=25
BSD-1606320080.A7
1606320080
|
-
|
|
|
|
23 - CONICAL SPRING WASHER dia 12x16x33 MM
BSD-1605703083.A11
1605703083
|
-
|
|
|
|
24 - O-RING 24.0x1.5 MM
BSD-1610210013.A4
1610210013
|
£2.16
|
£2.59
|
|
|
25 - SEALING CAP
BSD-1605500139.A6
1605500139
|
-
|
|
|
|
26 - COVER STRIP
BSD-1601099017.A4
1601099017
|
-
|
|
|
|
27 - HANDLE COVER
BSD-1605500141.A2
1605500141
|
-
|
|
|
|
28 - AIR-DEFLECTOR RING
BSD-1600591008.A8
1600591008
|
-
|
|
|
|
30 - EXTENSION SPRING
BSD-1604650010.A48
1604650010
|
£1.75
|
£2.10
|
|
|
31 - SINTERED-METAL BUSHING J6G7x10R6x6DIN1850
BSD-1900301007.A31
1900301007
|
£3.72
|
£4.47
|
|
|
32 - RIVING KNIFE
BSD-1600025015.A6
1600025015
|
-
|
|
|
|
35 - WING SCREW M6
BSD-1603480018.A34
1603480018
|
£2.16
|
£2.59
|
|
|
36 - MANUFACTURER'S NAMEPLATE
BSD-1601110491.A0
1601110491
|
-
|
|
|
|
37 - WING NUT M6
BSD-1603339006.A62
1603339006
|
£2.52
|
£3.02
|
|
|
38 - ROUND-HEAD BOLT DIN 603-M6x20
BSD-2910281201.A119
2910281201
|
£1.75
|
£2.10
|
|
|
41 - HEX SOCKET HEAD CAP SCREW M6x14 MM
BSD-1603414007.A226
1603414007
|
£2.29
|
£2.75
|
|
|
42 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A573
2603410001
|
£1.75
|
£2.10
|
|
|
43 - TAPPING SCREW DIN7981-ST3.9x16-C-Z
BSD-2912401019.A40
2912401019
|
£1.75
|
£2.10
|
|
|
45 - THREAD-FORMING TAP. SCREW DIN 7500-CM4x10
BSD-2914411246.A0
2914411246
|
-
|
|
|
|
46 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A309
1907950006
|
£4.26
|
£5.11
|
|
|
47 - ROUND-HEAD BOLT DIN 603-M6x25
BSD-2910281203.A71
2910281203
|
£2.61
|
£3.13
|
|
|
48 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A733
2916660008
|
£2.16
|
£2.59
|
|
|
49 - SEAL BUSHING
BSD-1600328029.A13
1600328029
|
-
|
|
|
|
50 - RUBBER BUFFER
BSD-1600305001.A55
1600305001
|
£1.75
|
£2.10
|
|
|
53 - THREAD-FORMING TAP. SCREW TT M5x16 MM
BSD-1603435021.A4
1603435021
|
-
|
|
|
|
55 - SPACER BUSHING
BSD-1600309010.A0
1600309010
|
£2.61
|
£3.13
|
|
|
56 - CONICAL SPRING WASHER dia 12x33 MM. SW22
BSD-1605703082.A2
1605703082
|
-
|
|
|
|
58 - MITER SQUARE
BSD-1608190010.A7
1608190010
|
£2.52
|
£3.02
|
|
|
59 - TAPPING SCREW DIN 7971-BZ3.9x9.5
BSD-2910211017.A280
2910211017
|
-
|
|
|
|
60 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x12-8.8
BSD-2910141193.A19
2910141193
|
-
|
|
|
|
61 - PLAIN WASHER DIN 433-6.4-ST 50
BSD-2916011013.A91
2916011013
|
£1.75
|
£2.10
|
|
|
130 - STICKER
BSD-1601110265.A120
1601110265
|
-
|
|
|
|
650 - PARALLEL-GUIDE
BSD-2608005036.A96
2608005036
|
£8.67
|
£10.41
|
|
|
700 - FITTING dia 25x35 MM
BSD-1600499005.A69
1600499005
|
£3.49
|
£4.19
|
|
|
701 - CIRCULAR SAW BLADE Z=12
BSD-2608640122.A10
2608640122
|
-
|
|
|
|
705 - CIRCULAR SAW BLADE Z=60
BSD-2608640126.A4
2608640126
|
-
|
|
|
|
800 - CARBON BRUSH
BSD-1607014117.A54
1607014117
|
£10.10
|
£12.12
|
|
|
804 - ON-OFF SWITCH
BSD-1607000231.A93
1607000231
|
£18.96
|
£22.75
|
|
|
820 - PARTS SET
BSD-1607000218.A20
1607000218
|
-
|
|
|
|
829 - PIVOTING BLADE GUARD
BSD-1605510168.A3
1605510168
|
-
|
|
|
|
839 - GROOVE BALL BEARING 12x28x8
BSD-1900905121.A398
1900905121
|
£18.96
|
£22.75
|
|
|
878 - PARTS SET
BSD-1607000205.A57
1607000205
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1470
160111A3H3
|
£2.61
|
£3.13
|
|
