1 - HOUSING SECTION
BSD-2605104936.A7
2605104936
|
-
|
|
|
|
1 - HOUSING SECTION
BSD-2605104958.A17
2605104958
|
-
|
|
|
|
2 - POLE SHOE 110V
BSD-2604220345.A0
2604220345
|
-
|
|
|
|
3 - ARMATURE WITH FAN 110V
BSD-2604010491.A0
2604010491
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200060.A3
2607200060
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200900.A0
2607200900
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 110V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460205.A114
2604460205
|
£27.23
|
£32.68
|
|
|
6 - GROMMET dia6.4-dia7.5x75 MM
BSD-1600703016.A25
1600703016
|
£1.75
|
£2.10
|
|
|
6 - GROMMET dia9.5 MM
BSD-2600703006.A185
2600703006
|
-
|
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A165
1601302014
|
£2.61
|
£3.13
|
|
|
8 - NAMEPLATE
BSD-2601105052.A9
2601105052
|
-
|
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110013.A179
1601110013
|
-
|
|
|
|
10 - CARBON-BRUSH SET
BSD-2604321904.A125
2604321904
|
£10.10
|
£12.12
|
|
|
11 - SUPPRESSION CAPACITOR
BSD-2607329069.A36
2607329069
|
-
|
|
|
|
15 - CHUCK dia1.5-13 MM. 1/2
BSD-1608571069.A394
1608571069
|
£23.86
|
£28.63
|
|
|
15 - KEY CHUCK dia1.5-13 MM. 1/2
BSD-1608571055.A13
1608571055
|
-
|
|
|
|
15/01 - CHUCK WRENCH SG2
BSD-2607950007.A906
2607950007
|
£6.52
|
£7.83
|
|
|
16 - DRILLING SPINDLE
BSD-2603122024.A7
2603122024
|
-
|
|
|
|
17 - LOCKING WASHER 1.0 MM
BSD-2600118003.A37
2600118003
|
-
|
|
|
|
17 - LOCKING WASHER 0.8 MM
BSD-2600118002.A83
2600118002
|
£1.75
|
£2.10
|
|
|
17 - LOCKING WASHER 0.6 MM
BSD-2600118001.A154
2600118001
|
£1.75
|
£2.10
|
|
|
17 - LOCKING WASHER 0.3 MM
BSD-2600118006.A209
2600118006
|
-
|
|
|
|
18 - O-RING 15x2 MM
BSD-1900210012.A11
1900210012
|
£1.75
|
£2.10
|
|
|
19 - SHIM 1.0 MM
BSD-2600101515.A188
2600101515
|
£1.95
|
£2.34
|
|
|
20 - CYLINDRICAL GEAR Z=48
BSD-2606317014.A11
2606317014
|
-
|
|
|
|
22 - CONTROL SHAFT
BSD-2603120004.A3
2603120004
|
-
|
|
|
|
24 - BALL DIN 5401-5 G28
BSD-1903230009.A390
1903230009
|
£1.75
|
£2.10
|
|
|
27 - COMPRESSION SPRING
BSD-2604617000.A93
2604617000
|
£2.61
|
£3.13
|
|
|
28 - GROOVE BALL BEARING
BSD-1600905003.A82
1600905003
|
-
|
|
|
|
29 - TAPPING SCREW DIN 7971-BZ2.9x16
BSD-2910211007.A215
2910211007
|
£1.75
|
£2.10
|
|
|
29 - TORX OVAL-HEAD SCREW 3x18
BSD-2603490018.A791
2603490018
|
£1.75
|
£2.10
|
|
|
30 - COMPRESSION SPRING
BSD-2604610007.A47
2604610007
|
-
|
|
|
|
30 - COMPRESSION SPRING
BSD-2604610007.A48
2604610007
|
-
|
|
|
|
31 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A396
1903230007
|
£1.75
|
£2.10
|
|
|
32 - CYLINDRICAL GEAR Z=35
BSD-2606317015.A21
2606317015
|
-
|
|
|
|
33 - GROOVE BALL BEARING dia9 MM
BSD-2600905003.A25
2600905003
|
-
|
|
|
|
34 - SOCKET HEAD CAP SCREW
BSD-2603410031.A16
2603410031
|
-
|
|
|
|
35 - BEARING BRACKET
BSD-2605807902.A22
2605807902
|
-
|
|
|
|
35 - LOCATING WASHER
BSD-2606490031.A1
2606490031
|
-
|
|
|
|
35 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A34
2600917003
|
£2.80
|
£3.36
|
|
|
36 - SPRING RETAINING RING DIN 471 9x1MM
BSD-2916640006.A46
2916640006
|
£1.75
|
£2.10
|
|
|
38 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A158
2603410023
|
-
|
|
|
|
39 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A6
2916650006
|
£1.75
|
£2.10
|
|
|
40 - TAPPING SCREW DIN 7971-BZ3.9x9.5
BSD-2910211017.A104
2910211017
|
-
|
|
|
|
43 - COMPRESSION SPRING
BSD-2604610009.A54
2604610009
|
-
|
|
|
|
46 - NEEDLE BEARING
BSD-1600910012.A35
1600910012
|
£2.80
|
£3.36
|
|
|
46 - NEEDLE BEARING
BSD-2600910005.A26
2600910005
|
-
|
|
|
|
47 - O-RING 8.0x2.5 MM
BSD-1610210014.A84
1610210014
|
-
|
|
|
|
48 - ROTARY KNOB
BSD-2603120008.A17
2603120008
|
-
|
|
|
|
49 - STRAIGHT PIN
BSD-2603101002.A14
2603101002
|
-
|
|
|
|
50 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A123
1602381001
|
-
|
|
|
|
51 - TOOTHED SHAFT Z= 9
BSD-2606309003.A5
2606309003
|
-
|
|
|
|
52 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A314
2600914010
|
£2.80
|
£3.36
|
|
|
53 - SHIM 0.3 MM
BSD-2600100570.A141
2600100570
|
£1.75
|
£2.10
|
|
|
54 - TOOTHED GEAR Z=22
BSD-2606320009.A7
2606320009
|
-
|
|
|
|
55 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A249
1903230006
|
£2.16
|
£2.59
|
|
|
56 - COMPRESSION SPRING
BSD-2604611002.A6
2604611002
|
-
|
|
|
|
57 - CYLINDRICAL GEAR Z=21
BSD-2606320006.A19
2606320006
|
-
|
|
|
|
59 - TOOTHED SHAFT Z= 21/22/9
BSD-2606309900.A11
2606309900
|
-
|
|
|
|
60 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A454
2910211019
|
£1.75
|
£2.10
|
|
|
61 - FELT WASHER
BSD-2600108002.A103
2600108002
|
£2.16
|
£2.59
|
|
|
62 - CUPPED WASHER
BSD-2600500002.A419
2600500002
|
£1.75
|
£2.10
|
|
|
63 - O-RING 35.0x2.0 MM
BSD-2600210026.A35
2600210026
|
£2.16
|
£2.59
|
|
|
64 - RECEPTACLE
BSD-2600400008.A749
2600400008
|
£1.75
|
£2.10
|
|
|
67 - SILICON DIODE
BSD-2607320008.A134
2607320008
|
-
|
|
|
|
68 - ON-OFF SWITCH
BSD-2607200904.A0
2607200904
|
-
|
|
|
|
69 - BRUSH HOLDER
BSD-2604337000.A8
2604337000
|
-
|
|
|
|
72 - SEALING DISK
BSD-1600109006.A21
1600109006
|
-
|
|
|
|
74 - SHIM
BSD-2600150005.A9
2600150005
|
£1.75
|
£2.10
|
|
|
75 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A46
2916660008
|
£2.16
|
£2.59
|
|
|
76 - STICKER
BSD-2601110222.A0
2601110222
|
-
|
|
|
|
77 - THERMOSWITCH
BSD-1607202900.A14
1607202900
|
-
|
|
|
|
80 - LEAF SPRING
BSD-2601302008.A2
2601302008
|
-
|
|
|
