1 - GEAR HOUSING
BSD-2605806959.A18
2605806959
|
-
|
|
|
|
2 - DRILLING SPINDLE 1/2-UNF-2
BSD-2606135001.A14
2606135001
|
-
|
|
|
|
3 - GROOVE BALL BEARING 15x32x9
BSD-2600905014.A19
2600905014
|
-
|
|
|
|
4 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A23
2916660013
|
£2.16
|
£2.59
|
|
|
5 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A423
2916650006
|
£1.75
|
£2.10
|
|
|
6 - COMPRESSION SPRING
BSD-2604617000.A182
2604617000
|
£2.61
|
£3.13
|
|
|
7 - CYLINDRICAL GEAR Z=48
BSD-2606317014.A53
2606317014
|
-
|
|
|
|
8 - SHIM 1.0 MM
BSD-2600101515.A50
2600101515
|
£1.95
|
£2.34
|
|
|
10 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A81
1903230007
|
£1.75
|
£2.10
|
|
|
11 - COMPRESSION SPRING
BSD-2604610007.A15
2604610007
|
-
|
|
|
|
12 - CYLINDRICAL GEAR Z=36
BSD-2606317025.A13
2606317025
|
-
|
|
|
|
13 - SHIM WASHER 0.2 MM
BSD-2600000012.A48
2600000012
|
£1.75
|
£2.10
|
|
|
13 - SHIM WASHER 0.3 MM
BSD-2600000013.A35
2600000013
|
-
|
|
|
|
13 - SHIM WASHER 0.5 MM
BSD-2600000014.A7
2600000014
|
£1.75
|
£2.10
|
|
|
13 - SHIM WASHER 0.1 MM
BSD-2600000018.A24
2600000018
|
-
|
|
|
|
14 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A731
1903230010
|
£1.75
|
£2.10
|
|
|
15 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A575
2600914010
|
£2.80
|
£3.36
|
|
|
16 - TOOTHED SHAFT Z=10/22/21
BSD-2606309902.A25
2606309902
|
-
|
|
|
|
16/1 - TOOTHED SHAFT Z=10
BSD-2606309004.A17
2606309004
|
-
|
|
|
|
17 - CYLINDRICAL GEAR Z=22
BSD-2606317026.A5
2606317026
|
-
|
|
|
|
19 - CYLINDRICAL GEAR Z=21
BSD-2606320006.A35
2606320006
|
-
|
|
|
|
20 - SHIM 0.3 MM
BSD-2600100607.A1087
2600100607
|
£1.75
|
£2.10
|
|
|
21 - LOCATING WASHER
BSD-2606490031.A57
2606490031
|
-
|
|
|
|
22 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A359
2600917003
|
£2.80
|
£3.36
|
|
|
23 - RATCHET CAP
BSD-2600590006.A1373
2600590006
|
£1.75
|
£2.10
|
|
|
24 - FLANGED BEARING
BSD-2605700928.A26
2605700928
|
-
|
|
|
|
25 - SLOTTED SPRING PIN 4x30 MM DIN 7346
BSD-2917780105.A152
2917780105
|
£1.75
|
£2.10
|
|
|
26 - RATCHET CAP
BSD-2600590006.A1372
2600590006
|
£1.75
|
£2.10
|
|
|
27 - ROTARY KNOB
BSD-2602026017.A23
2602026017
|
£7.36
|
£8.83
|
|
|
28 - FELT WASHER
BSD-2600108077.A188
2600108077
|
£1.75
|
£2.10
|
|
|
29 - CUPPED WASHER
BSD-2600500002.A20
2600500002
|
£1.75
|
£2.10
|
|
|
30 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A744
2600905021
|
£8.67
|
£10.41
|
|
|
31 - NEEDLE BEARING dia6/12 MM
BSD-2600914017.A1
2600914017
|
£11.30
|
£13.56
|
|
|
35 - ARMATURE 220-240V
BSD-2604010524.A21
2604010524
|
-
|
|
|
|
36 - FAN
BSD-2606610049.A265
2606610049
|
£2.16
|
£2.59
|
|
|
37 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A944
2916660008
|
£2.16
|
£2.59
|
|
|
38 - RECEPTACLE
BSD-2600400008.A433
2600400008
|
£1.75
|
£2.10
|
|
|
40 - MOTOR HOUSING
BSD-2605104146.A11
2605104146
|
-
|
|
|
|
41 - COVER DISC
BSD-2601328032.A23
2601328032
|
-
|
|
|
|
43 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1343
2603490017
|
£2.16
|
£2.59
|
|
|
44 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A116
2603435015
|
£2.16
|
£2.59
|
|
|
46 - FIELD 220-240V
BSD-1604220254.A80
1604220254
|
£21.68
|
£26.01
|
|
|
47 - CABLE L=130 MM
BSD-2604448005.A382
2604448005
|
£1.75
|
£2.10
|
|
|
48 - BRUSH HOLDER
BSD-2604449027.A19
2604449027
|
£1.75
|
£2.10
|
|
|
50 - BALL BEARING 7x22x7
BSD-1900905018.A974
1900905018
|
£18.96
|
£22.75
|
|
|
51 - SHIM
BSD-2600150004.A450
2600150004
|
£2.16
|
£2.59
|
|
|
52 - SHIM 0.3 MM
BSD-2600101023.A207
2600101023
|
£1.75
|
£2.10
|
|
|
52 - SHIM 0.2 MM
BSD-2600101022.A412
2600101022
|
£1.75
|
£2.10
|
|
|
52 - SHIM 0.5 MM
BSD-2600101020.A237
2600101020
|
£1.75
|
£2.10
|
|
|
53 - CARBON-BRUSH SET
BSD-2604321905.A355
2604321905
|
£11.30
|
£13.56
|
|
|
55 - BRUSH PLATE
BSD-2601015047.A185
2601015047
|
-
|
|
|
|
58 - SWITCH
BSD-2607200084.A6
2607200084
|
£10.10
|
£12.12
|
|
|
58 - ON-OFF SWITCH
BSD-2607200087.A4
2607200087
|
-
|
|
|
|
58 - ON-OFF SWITCH
BSD-2607200137.A62
2607200137
|
-
|
|
|
|
58 - ON-OFF SWITCH
BSD-2607200088.A1
2607200088
|
-
|
|
|
|
58 - ON-OFF SWITCH
BSD-2607200089.A4
2607200089
|
-
|
|
|
|
59 - CABLE CLIP
BSD-2601035001.A1528
2601035001
|
£1.75
|
£2.10
|
|
|
60 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2177
2910211019
|
£1.75
|
£2.10
|
|
|
61 - SUPPRESSION FILTER
BSD-2607329096.A53
2607329096
|
£7.36
|
£8.83
|
|
|
64 - HOUSING COVER
BSD-2605132046.A1
2605132046
|
-
|
|
|
|
65 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A915
2910211021
|
£1.75
|
£2.10
|
|
|
66 - HEADLESS SCREW 65 MM
BSD-2603435071.A153
2603435071
|
-
|
|
|
|
67 - TAPPING SCREW 79 MM
BSD-2603435012.A100
2603435012
|
-
|
|
|
|
68 - ROTARY KNOB
BSD-2602026018.A14
2602026018
|
-
|
|
|
|
70 - SPRING RETAINING RING DIN 471-10x1MM-FSt
BSD-2916650001.A476
2916650001
|
£2.61
|
£3.13
|
|
|
74 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1481
2600703012
|
£2.80
|
£3.36
|
|
|
74 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A133
2600703011
|
£2.80
|
£3.36
|
|
|
75 - POWER SUPPLY CORD EU 2.65m 2 x 1.0mm H05 RN-F
BSD-1607000388.A33
1607000388
|
£12.04
|
£14.45
|
|
|
75 - ELEC. CABLE W/CONNECTION CH 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460053.A127
2604460053
|
-
|
|
|
|
75 - POWER SUPPLY CORD
BSD-2604460056.A3
2604460056
|
-
|
|
|
|
75 - POWER SUPPLY CORD AUS 2.6m 2 x 0.75mm PVC
BSD-2604460061.A7
2604460061
|
-
|
|
|
|
75 - POWER SUPPLY CORD GB 110V 2.65m 2 x 1.0mm H05 VV-F
BSD-3604460069.A21
3604460069
|
£37.72
|
£45.27
|
|
|
76 - CABLE
BSD-2604448003.A252
2604448003
|
-
|
|
|
|
77 - KEY CHUCK dia1.5-13 MM. 1/2
BSD-1608571055.A53
1608571055
|
-
|
|
|
|
77 - CHUCK dia1.5-13 MM. 1/2
BSD-1608571069.A166
1608571069
|
£23.86
|
£28.63
|
|
|
78 - CHUCK WRENCH SG2
BSD-2607950007.A1237
2607950007
|
£6.52
|
£7.83
|
|
|
81 - STICKER
BSD-2601110076.A16
2601110076
|
-
|
|
|
|
82 - STICKER
BSD-2601110225.A4
2601110225
|
-
|
|
|
|
82 - STICKER
BSD-2601110262.A1
2601110262
|
-
|
|
|
|
83 - STICKER
BSD-2601110224.A1
2601110224
|
-
|
|
|
|
83 - STICKER
BSD-2601110263.A4
2601110263
|
-
|
|
|
|
84 - STICKER
BSD-2601110105.A4
2601110105
|
-
|
|
|
|
85 - STICKER
BSD-2601110072.A16
2601110072
|
-
|
|
|
|
86 - STICKER
BSD-2601110041.A194
2601110041
|
-
|
|
|
|
87 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1320
2603410001
|
£1.75
|
£2.10
|
|
|
88 - SHIM 0.2 MM
BSD-2600100575.A139
2600100575
|
£2.16
|
£2.59
|
|
|
88 - SHIM 0.3 MM
BSD-2600100576.A180
2600100576
|
-
|
|
|
|
88 - SHIM 0.5 MM
BSD-2600100577.A142
2600100577
|
£1.75
|
£2.10
|
|
|
651 - AUXILIARY HANDLE
BSD-2602025094.A106
2602025094
|
£7.36
|
£8.83
|
|
|
652 - WING NUT M6 DIN 315-G-GTW-40
BSD-2915191006.A78
2915191006
|
-
|
|
|
|
653 - HEX SCREW DIN 931-M6x75-8.8
BSD-2911011220.A13
2911011220
|
-
|
|
|
|
653 - HEX SCREW DIN 931-M6x45-8.8
BSD-2911011211.A13
2911011211
|
-
|
|
|
|
654 - CONICAL SPRING WASHER
BSD-2601098001.A28
2601098001
|
-
|
|
|
|
655 - DEPTH-GAUGE
BSD-2607010026.A4
2607010026
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2717
160111A3H3
|
£2.61
|
£3.13
|
|
