An exploded drawing and listing for the Bosch PSB 1200-2 RPE / 0603171732 / CH 230 Volt
Ex VAT Inc VAT
1 - MOTOR HOUSING BSD-2605104715.A3 2605104715 -
2 - FIELD 230-240V BSD-1604220395.A4 1604220395 £24.45 £29.34
3 - ARMATURE WITH FAN 230-240V BSD-2604011249.A4 2604011249 £41.62 £49.95
4 - SWITCH BSD-2607200544.A15 2607200544 £31.64 £37.97
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F BSD-1604460432.A21 1604460432 £11.30 £13.56
6 - GROMMET dia6.2-dia6.9x90 MM BSD-2600707066.A181 2600707066 £2.48 £2.97
9 - MANUFACTURER'S NAMEPLATE BSD-2601117439.A1 2601117439 -
13 - BALL BEARING 7x19x6 BSD-2600905032.A1915 2600905032 £5.30 £6.36
14 - GROOVE BALL BEARING 9x24x7 BSD-1610905017.A30 1610905017 £13.12 £15.75
19 - TORX OVAL-HEAD SCREW 3x10 BSD-2603490017.A780 2603490017 £2.16 £2.59
20 - REFERENCE PLATE BSD-2601117624.A1 2601117624 -
24 - DRILLING SPINDLE BSD-2606135099.A17 2606135099 £13.41 £16.09
26 - COMPRESSION SPRING BSD-2604616013.A4 2604616013 £2.61 £3.13
27 - GROOVE BALL BEARING 17x35x10 BSD-1900905163.A226 1900905163 £11.30 £13.56
28 - SHIM 0.5 MM BSD-2600100695.A108 2600100695 £1.75 £2.10
29 - SPRING RETAINING RING DIN 471 17x1 MM BSD-2916650008.A257 2916650008 £1.75 £2.10
30 - FLAT KEY BSD-2602300032.A50 2602300032 £3.72 £4.47
31 - RETAINING WASHER BSD-2600101671.A137 2600101671 £1.75 £2.10
32 - SHIM BSD-2600101056.A14 2600101056 £1.75 £2.10
33 - CYLINDRICAL GEAR BSD-2606317084.A48 2606317084 £13.12 £15.75
34 - CYLINDRICAL GEAR BSD-2606317098.A87 2606317098 £12.04 £14.45
35 - SHIM 0.3 MM BSD-2600101047.A295 2600101047 £1.75 £2.10
36 - CATCH DISK BSD-2600190090.A2 2600190090 £2.52 £3.02
37 - CATCH DISK BSD-2600190078.A20 2600190078 £5.87 £7.04
38 - SHIM WASHER 1.0 MM BSD-2600000021.A130 2600000021 £1.75 £2.10
38 - SHIM WASHER 1.35 MM BSD-2600000030.A104 2600000030 £1.75 £2.10
38 - SHIM WASHER 1.7 MM BSD-2600000031.A30 2600000031 £1.75 £2.10
39 - THREAD-FORMING TAP. SCREW M4x8 BSD-2603410048.A8 2603410048 £1.75 £2.10
40 - BALL 5.25 MM BSD-2603230007.A32 2603230007 £1.75 £2.10
40 - BALL DIN 5401-5 G28 BSD-1903230009.A718 1903230009 £1.75 £2.10
40 - BALL DIN 5401-5.5MM-III-ST BSD-1903230010.A116 1903230010 £1.75 £2.10
41 - CHANGEOVER LEVER BSD-2602098014.A18 2602098014 £1.95 £2.34
42 - PRESSURE PLATE BSD-2600114016.A19 2600114016 £2.33 £2.80
44 - GASKET BSD-2601073014.A16 2601073014 £1.32 £1.58
45 - AIR GUIDE PLATE BSD-2600148007.A3 2600148007 £1.75 £2.10
46 - TORX OVAL-HEAD SCREW 4x25 BSD-2603490024.A531 2603490024 £1.75 £2.10
47 - HOUSING COVER BSD-2605132052.A6 2605132052 -
48 - CONTACT SPRING BSD-2601324046.A18 2601324046 -
53 - DISC SPRING BSD-2600550008.A92 2600550008 £1.75 £2.10
61 - SHIM 0.3 MM BSD-2600100607.A47 2600100607 £1.75 £2.10
62 - NEEDLE-ROLLER BEARING dia6 MM BSD-2600914010.A41 2600914010 £2.80 £3.36
63 - HEADLESS SCREW BSD-2603435076.A5 2603435076 -
64 - HEADLESS SCREW BSD-2603435077.A3 2603435077 £1.75 £2.10
65 - BULB SHIELD BSD-2601099100.A2 2601099100 -
70 - HOLDING-DOWN-APPLIANCE BSD-2601328068.A18 2601328068 £1.75 £2.10
71 - RATCHET CAP BSD-2600590006.A192 2600590006 £1.75 £2.10
72 - TORX OVAL-HEAD SCREW 4x30 BSD-2603490025.A121 2603490025 £1.75 £2.10
73 - SCREW 4x16 BSD-2603490022.A1911 2603490022 £1.75 £2.10
74 - CONTACT BAR BSD-2601324045.A5 2601324045 -
75 - BLADE TERMINAL BSD-2604477005.A18 2604477005 £1.75 £2.10
76 - BRUSH PLATE BSD-2604337096.A19 2604337096 £14.91 £17.89
78 - SPRING RETAINING RING DIN 472 35x1.5 MM BSD-2916660014.A161 2916660014 £1.75 £2.10
79 - SPEED GOVERNOR 220-240V BSD-2607230065.A0 2607230065 -
80 - CHANGE-OVER SWITCH BSD-2602099016.A18 2602099016 £2.33 £2.80
81 - CARRIER BRACKET BSD-2602319024.A3 2602319024 £1.75 £2.10
82 - END STOP BSD-2602319025.A20 2602319025 £1.32 £1.58
84 - RETAINING WASHER BSD-2601098067.A8 2601098067 £2.33 £2.80
85 - KEYLESS CHUCK BSD-2608572137.A2 2608572137 -
88 - HOLDING PLATE BSD-2601328070.A5 2601328070 £1.75 £2.10
210 - REFERENCE PLATE BSD-2601116284.A13 2601116284 £1.32 £1.58
653 - AUXILIARY HANDLE BSD-2602025125.A184 2602025125 £10.10 £12.12
655 - DEPTH-GAUGE BSD-2609005615.A287 2609005615 £4.26 £5.11
808 - MARKING PLATE BSD-2601116000.A0 2601116000 -
825 - GEAR HOUSING BSD-2605806893.A6 2605806893 -
843 - INTERMEDIATE FLANGE BSD-2605700942.A15 2605700942 £33.45 £40.14
859 - TRANSMISSION BSD-1600A00MM2.A35 1600A00MM2 £37.72 £45.27
867 - TOOTHED RACK BSD-2606308924.A5 2606308924 -
876/04 - CARBON-BRUSH SET BSD-2604321927.A14 2604321927 £10.82 £12.99
891 - CROSS RECESSED-HEAD SCREW M3x5 BSD-2603410046.A48 2603410046 £2.16 £2.59
