1 - HOUSING SECTION
BSD-2605104601.A0
2605104601
|
£24.45
|
£29.34
|
|
|
2 - FIELD 230V
BSD-2604220647.A27
2604220647
|
£21.52
|
£25.83
|
|
|
3 - ARMATURE 230-240V
BSD-2604011166.A11
2604011166
|
£45.67
|
£54.80
|
|
|
3/60 - FAN
BSD-2606610029.A432
2606610029
|
£2.61
|
£3.13
|
|
|
4 - SWITCH
BSD-2607200501.A12
2607200501
|
£10.82
|
£12.99
|
|
|
6 - GROMMET dia6.2-dia6.9x90 MM
BSD-2600707066.A149
2600707066
|
£2.48
|
£2.97
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601119553.A5
2601119553
|
-
|
|
|
|
14 - NEEDLE BEARING
BSD-2600914019.A108
2600914019
|
£5.30
|
£6.36
|
|
|
21 - SPEED GOVERNOR
BSD-2607230050.A0
2607230050
|
-
|
|
|
|
22 - CHANGE-OVER SWITCH
BSD-2602098008.A3
2602098008
|
£1.75
|
£2.10
|
|
|
23 - SCREW 4x16
BSD-2603490022.A2686
2603490022
|
£1.75
|
£2.10
|
|
|
24 - TAPPING SCREW DIN 7981-ST2.2x9.5-C-H
BSD-2910611002.A4
2910611002
|
£1.75
|
£2.10
|
|
|
25 - O-RING 5.0x1.5 MM
BSD-1900210000.A14
1900210000
|
£1.75
|
£2.10
|
|
|
27 - DAMPING ELEMENT
BSD-2603239024.A61
2603239024
|
£1.75
|
£2.10
|
|
|
28 - OVAL-HEAD SCREW
BSD-2603429006.A37
2603429006
|
£1.32
|
£1.58
|
|
|
29 - HANDLE COVER
BSD-2608040109.A41
2608040109
|
£4.26
|
£5.11
|
|
|
30 - DRILLING SPINDLE 1/2
BSD-2606135093.A8
2606135093
|
-
|
|
|
|
31 - LOCKING WASHER 0.6 MM
BSD-2600118001.A181
2600118001
|
£1.75
|
£2.10
|
|
|
31 - LOCKING WASHER 0.8 MM
BSD-2600118002.A56
2600118002
|
£1.75
|
£2.10
|
|
|
31 - LOCKING WASHER 0.3 MM
BSD-2600118006.A221
2600118006
|
-
|
|
|
|
32 - COMPRESSION SPRING
BSD-2604616006.A176
2604616006
|
£1.75
|
£2.10
|
|
|
33 - SINTERED-METAL BUSHING
BSD-2600301054.A5
2600301054
|
£2.33
|
£2.80
|
|
|
34 - CYLINDRICAL GEAR
BSD-2606317082.A38
2606317082
|
£13.12
|
£15.75
|
|
|
35 - CYLINDRICAL GEAR
BSD-2606317083.A18
2606317083
|
£11.30
|
£13.56
|
|
|
36 - SHIM 0.5 MM
BSD-2600100695.A23
2600100695
|
£1.75
|
£2.10
|
|
|
37 - SHIM 0.3 MM
BSD-2600101047.A7
2600101047
|
£1.75
|
£2.10
|
|
|
38 - CONTACT STRAP
BSD-2601329072.A30
2601329072
|
-
|
|
|
|
39 - RETAINING WASHER
BSD-2600101084.A4
2600101084
|
£1.75
|
£2.10
|
|
|
40 - FLAT KEY
BSD-2602300034.A11
2602300034
|
-
|
|
|
|
41 - GUIDING PLATE
BSD-2601098031.A20
2601098031
|
£1.75
|
£2.10
|
|
|
42 - CATCH DISK
BSD-2600190070.A43
2600190070
|
£5.58
|
£6.70
|
|
|
44 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A404
1903230010
|
£1.75
|
£2.10
|
|
|
45 - INDEXING DISK
BSD-2601990001.A84
2601990001
|
£1.32
|
£1.58
|
|
|
46 - PRESSURE PLATE
BSD-2601074003.A162
2601074003
|
£1.75
|
£2.10
|
|
|
47 - SHIM 0.2 MM
BSD-1600100632.A358
1600100632
|
£1.75
|
£2.10
|
|
|
52 - SHIM 0.3 MM
BSD-2600100607.A291
2600100607
|
£1.75
|
£2.10
|
|
|
54 - BEARING SLEEVE
BSD-2600400027.A13
2600400027
|
£4.26
|
£5.11
|
|
|
55 - SHIM 0.5 MM
BSD-2600100637.A19
2600100637
|
£1.75
|
£2.10
|
|
|
56 - FORK LEVER
BSD-2601990009.A8
2601990009
|
£2.29
|
£2.75
|
|
|
57 - ROTARY HEAD
BSD-2602026091.A26
2602026091
|
-
|
|
|
|
58 - RATCHET CAP
BSD-2600590006.A497
2600590006
|
£1.75
|
£2.10
|
|
|
62 - DRIVER PIN
BSD-2601335001.A37
2601335001
|
£2.16
|
£2.59
|
|
|
64 - SHIM WASHER
BSD-2600100618.A92
2600100618
|
£1.75
|
£2.10
|
|
|
65 - ROLLER BODY
BSD-2609007376.A45
2609007376
|
£1.75
|
£2.10
|
|
|
67 - CATCH DISK
BSD-2600190071.A22
2600190071
|
£6.52
|
£7.83
|
|
|
68 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A342
2600914010
|
£2.80
|
£3.36
|
|
|
76 - FELT STRIP
BSD-2601005011.A181
2601005011
|
-
|
|
|
|
77 - FELT STRIP
BSD-2601005021.A35
2601005021
|
£1.32
|
£1.58
|
|
|
96 - PLAIN WASHER
BSD-2600100066.A23
2600100066
|
£1.75
|
£2.10
|
|
|
210 - REFERENCE PLATE
BSD-2601116284.A22
2601116284
|
£1.32
|
£1.58
|
|
|
654 - AUXILIARY HANDLE
BSD-2602025125.A193
2602025125
|
£10.10
|
£12.12
|
|
|
755 - DEPTH-GAUGE
BSD-2603001019.A22
2603001019
|
£2.63
|
£3.16
|
|
|
780 - KEYLESS CHUCK 1/2
BSD-2608572122.A5
2608572122
|
-
|
|
|
|
805 - POWER SUPPLY CORD EU 2.65m 2 x 1.0mm H05 RN-F
BSD-1607000388.A257
1607000388
|
£12.04
|
£14.45
|
|
|
808 - MARKING PLATE
BSD-2601119810.A1
2601119810
|
-
|
|
|
|
813 - GROOVE BALL BEARING 7x19x6
BSD-2600905103.A32
2600905103
|
£5.58
|
£6.70
|
|
|
816 - BRUSH PLATE
BSD-2604337061.A12
2604337061
|
£14.91
|
£17.89
|
|
|
816/04 - BRUSH HOLDER
BSD-1607000CJ1.A64
1607000CJ1
|
£5.87
|
£7.04
|
|
|
819 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A394
2910611006
|
£1.75
|
£2.10
|
|
|
828 - TAPPING SCREW DIN 7981-ST3.9x19-C-H
BSD-2910611020.A56
2910611020
|
£1.75
|
£2.10
|
|
|
849 - TOOTHED SHAFT
BSD-2606309936.A5
2606309936
|
-
|
|
|
|
850 - CARRIER
BSD-2606440900.A19
2606440900
|
-
|
|
|
|
863 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A512
2916080007
|
£2.61
|
£3.13
|
|
|
866 - BEARING BRACKET
BSD-2605807934.A36
2605807934
|
-
|
|
|
|
890 - FASTENING PARTS KIT
BSD-2607001305.A305
2607001305
|
£4.26
|
£5.11
|
|
|
891 - CROSS RECESSED-HEAD SCREW M3x5
BSD-2603410046.A16
2603410046
|
£2.16
|
£2.59
|
|
