1 - MOTOR HOUSING
BSD-2605104715.A8
2605104715
|
-
|
|
|
|
2 - FIELD 230-240V
BSD-1614220136.A0
1614220136
|
£19.45
|
£23.34
|
|
|
3 - ARMATURE WITH FAN 230-240V
BSD-2604011242.A13
2604011242
|
£41.62
|
£49.95
|
|
|
4 - SWITCH
BSD-2607200556.A51
2607200556
|
£27.23
|
£32.68
|
|
|
6 - GROMMET dia6.2-dia6.9x90 MM
BSD-2600707066.A176
2600707066
|
£2.48
|
£2.97
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601117437.A2
2601117437
|
-
|
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1920
2600905032
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-1610905017.A36
1610905017
|
£13.12
|
£15.75
|
|
|
19 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A784
2603490017
|
£2.16
|
£2.59
|
|
|
20 - REFERENCE PLATE
BSD-2601117443.A2
2601117443
|
-
|
|
|
|
24 - DRILLING SPINDLE
BSD-2606135099.A19
2606135099
|
£13.41
|
£16.09
|
|
|
26 - COMPRESSION SPRING
BSD-2604616013.A2
2604616013
|
£2.61
|
£3.13
|
|
|
27 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A221
1900905163
|
£11.30
|
£13.56
|
|
|
28 - SHIM 0.5 MM
BSD-2600100695.A113
2600100695
|
£1.75
|
£2.10
|
|
|
29 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A264
2916650008
|
£1.75
|
£2.10
|
|
|
30 - FLAT KEY
BSD-2602300032.A47
2602300032
|
£3.72
|
£4.47
|
|
|
31 - RETAINING WASHER
BSD-2600101671.A142
2600101671
|
£1.75
|
£2.10
|
|
|
32 - SHIM
BSD-2600101056.A18
2600101056
|
£1.75
|
£2.10
|
|
|
33 - CYLINDRICAL GEAR
BSD-2606317084.A46
2606317084
|
£13.12
|
£15.75
|
|
|
34 - CYLINDRICAL GEAR
BSD-2606317098.A89
2606317098
|
£12.04
|
£14.45
|
|
|
35 - SHIM 0.3 MM
BSD-2600101047.A293
2600101047
|
£1.75
|
£2.10
|
|
|
36 - CATCH DISK
BSD-2600190090.A8
2600190090
|
£2.52
|
£3.02
|
|
|
37 - CATCH DISK
BSD-2600190078.A15
2600190078
|
£5.87
|
£7.04
|
|
|
38 - SHIM WASHER 1.0 MM
BSD-2600000021.A133
2600000021
|
£1.75
|
£2.10
|
|
|
38 - SHIM WASHER 1.35 MM
BSD-2600000030.A101
2600000030
|
£1.75
|
£2.10
|
|
|
38 - SHIM WASHER 1.7 MM
BSD-2600000031.A33
2600000031
|
£1.75
|
£2.10
|
|
|
39 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A12
2603410048
|
£1.75
|
£2.10
|
|
|
40 - BALL 5.25 MM
BSD-2603230007.A36
2603230007
|
£1.75
|
£2.10
|
|
|
40 - BALL DIN 5401-5 G28
BSD-1903230009.A721
1903230009
|
£1.75
|
£2.10
|
|
|
40 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A113
1903230010
|
£1.75
|
£2.10
|
|
|
41 - CHANGEOVER LEVER
BSD-2602098014.A14
2602098014
|
£1.95
|
£2.34
|
|
|
42 - PRESSURE PLATE
BSD-2600114016.A14
2600114016
|
£2.33
|
£2.80
|
|
|
44 - GASKET
BSD-2601073014.A21
2601073014
|
£1.32
|
£1.58
|
|
|
45 - AIR GUIDE PLATE
BSD-2600148007.A8
2600148007
|
£1.75
|
£2.10
|
|
|
46 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A526
2603490024
|
£1.75
|
£2.10
|
|
|
47 - HOUSING COVER
BSD-2605132052.A3
2605132052
|
-
|
|
|
|
48 - CONTACT SPRING
BSD-2601324046.A14
2601324046
|
-
|
|
|
|
53 - DISC SPRING
BSD-2600550008.A87
2600550008
|
£1.75
|
£2.10
|
|
|
61 - SHIM 0.3 MM
BSD-2600100607.A44
2600100607
|
£1.75
|
£2.10
|
|
|
62 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A36
2600914010
|
£2.80
|
£3.36
|
|
|
63 - HEADLESS SCREW
BSD-2603435076.A1
2603435076
|
-
|
|
|
|
64 - HEADLESS SCREW
BSD-2603435077.A7
2603435077
|
£1.75
|
£2.10
|
|
|
65 - BULB SHIELD
BSD-2601099100.A7
2601099100
|
-
|
|
|
|
70 - HOLDING-DOWN-APPLIANCE
BSD-2601328068.A22
2601328068
|
£1.75
|
£2.10
|
|
|
71 - RATCHET CAP
BSD-2600590006.A197
2600590006
|
£1.75
|
£2.10
|
|
|
72 - TORX OVAL-HEAD SCREW 4x30
BSD-2603490025.A126
2603490025
|
£1.75
|
£2.10
|
|
|
73 - SCREW 4x16
BSD-2603490022.A1916
2603490022
|
£1.75
|
£2.10
|
|
|
74 - CONTACT BAR
BSD-2601324045.A9
2601324045
|
-
|
|
|
|
75 - BLADE TERMINAL
BSD-2604477005.A21
2604477005
|
£1.75
|
£2.10
|
|
|
76 - BRUSH PLATE
BSD-2604337096.A12
2604337096
|
£14.91
|
£17.89
|
|
|
78 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A156
2916660014
|
£1.75
|
£2.10
|
|
|
79 - BULB SHIELD
BSD-2601099101.A0
2601099101
|
-
|
|
|
|
80 - CHANGE-OVER SWITCH
BSD-2602099016.A22
2602099016
|
£2.33
|
£2.80
|
|
|
81 - CARRIER BRACKET
BSD-2602319024.A7
2602319024
|
£1.75
|
£2.10
|
|
|
82 - END STOP
BSD-2602319025.A16
2602319025
|
£1.32
|
£1.58
|
|
|
84 - RETAINING WASHER
BSD-2601098067.A3
2601098067
|
£2.33
|
£2.80
|
|
|
85 - KEYLESS CHUCK
BSD-2608572137.A7
2608572137
|
-
|
|
|
|
86 - CONNECTING CABLE L=80 MM
BSD-1614448014.A84
1614448014
|
£2.61
|
£3.13
|
|
|
87 - CONNECTING CABLE
BSD-2604448246.A2
2604448246
|
-
|
|
|
|
88 - HOLDING PLATE
BSD-2601328070.A1
2601328070
|
£1.75
|
£2.10
|
|
|
210 - REFERENCE PLATE
BSD-2601116284.A10
2601116284
|
£1.32
|
£1.58
|
|
|
653 - AUXILIARY HANDLE
BSD-2602025125.A188
2602025125
|
£10.10
|
£12.12
|
|
|
655 - DEPTH-GAUGE
BSD-2609005615.A282
2609005615
|
£4.26
|
£5.11
|
|
|
805 - POWER SUPPLY CORD EU 2.65m 2 x 1.0mm H05 RN-F
BSD-1607000388.A188
1607000388
|
£12.04
|
£14.45
|
|
|
808 - MARKING PLATE
BSD-2601117590.A0
2601117590
|
-
|
|
|
|
825 - GEAR HOUSING
BSD-2605806893.A3
2605806893
|
-
|
|
|
|
835 - FAN
BSD-2606610102.A1
2606610102
|
£3.80
|
£4.56
|
|
|
843 - INTERMEDIATE FLANGE
BSD-2605700942.A18
2605700942
|
£33.45
|
£40.14
|
|
|
859 - TRANSMISSION
BSD-1600A00MM2.A28
1600A00MM2
|
£37.72
|
£45.27
|
|
|
867 - TOOTHED RACK
BSD-2606308924.A2
2606308924
|
-
|
|
|
|
876 - CARBON-BRUSH SET
BSD-2604321927.A21
2604321927
|
£10.82
|
£12.99
|
|
|
891 - CROSS RECESSED-HEAD SCREW M3x5
BSD-2603410046.A44
2603410046
|
£2.16
|
£2.59
|
|
