1 - MOTOR HOUSING
BSD-2605104902.A13
2605104902
|
-
|
|
|
|
1 - HOUSING SECTION
BSD-2605104932.A4
2605104932
|
-
|
|
|
|
3 - ARMATURE 110-115V
BSD-2604010370.A3
2604010370
|
-
|
|
|
|
4 - BEARING BRACKET
BSD-2605807000.A16
2605807000
|
-
|
|
|
|
6 - GROOVE BALL BEARING
BSD-2600900001.A3
2600900001
|
-
|
|
|
|
7 - SOCKET HEAD CAP SCREW
BSD-2603410027.A16
2603410027
|
-
|
|
|
|
8 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A808
2916690003
|
£1.75
|
£2.10
|
|
|
9 - GUIDE SLEEVE
BSD-2600400024.A11
2600400024
|
£2.80
|
£3.36
|
|
|
10 - NEEDLE ROLLER A 3x9.8G2DIN 5402
BSD-1903201041.A7
1903201041
|
-
|
|
|
|
12 - POLE SHOE 110-115V
BSD-2604220295.A3
2604220295
|
-
|
|
|
|
13 - BRUSH HOLDER
BSD-1601323007.A86
1601323007
|
-
|
|
|
|
15 - SPIRAL SPRING
BSD-1604652004.A117
1604652004
|
£2.61
|
£3.13
|
|
|
16 - BRUSH PLATE
BSD-1601034025.A36
1601034025
|
-
|
|
|
|
17 - TAPPING SCREW DIN 7972-BZ2.9x6.5
BSD-2910601004.A28
2910601004
|
-
|
|
|
|
19 - SINTERED-METAL BUSHING
BSD-1600301900.A70
1600301900
|
-
|
|
|
|
20 - FELT WASHER
BSD-1600205023.A97
1600205023
|
£1.32
|
£1.58
|
|
|
21 - O-RING 8.0x2.5 MM
BSD-1610210014.A8
1610210014
|
-
|
|
|
|
23 - ECCENTRIC COG WHEEL Z=39
BSD-2606319073.A45
2606319073
|
-
|
|
|
|
24 - SPRING WASHER
BSD-2600150050.A11
2600150050
|
£1.75
|
£2.10
|
|
|
25 - COUNTER WEIGHT
BSD-1619P02421.A23
1619P02421
|
£8.67
|
£10.41
|
|
|
26 - SHIM 0.5 MM
BSD-2600102658.A9
2600102658
|
£1.32
|
£1.58
|
|
|
26 - SHIM 0.2 MM
BSD-2600102656.A61
2600102656
|
£1.32
|
£1.58
|
|
|
27 - SHIM dia 18.3 MM
BSD-2600101673.A20
2600101673
|
£1.75
|
£2.10
|
|
|
28 - DRILLING SPINDLE
BSD-2601030017.A8
2601030017
|
-
|
|
|
|
29 - NEEDLE BEARING
BSD-2600917904.A12
2600917904
|
£7.36
|
£8.83
|
|
|
30 - SLIDING PIECE
BSD-2601321036.A38
2601321036
|
-
|
|
|
|
31 - LIFTING ROD
BSD-2600780900.A20
2600780900
|
-
|
|
|
|
31 - LIFTING ROD
BSD-2600780002.A20
2600780002
|
-
|
|
|
|
32 - CLAMP SCREW
BSD-2603400000.A64
2603400000
|
£4.26
|
£5.11
|
|
|
33 - CLAMPING SADDLE
BSD-2602329011.A3
2602329011
|
£4.75
|
£5.70
|
|
|
34 - COUNTERSUNK-HEAD SCREW DIN 7962-M3.5x8-10.9
BSD-2603421040.A271
2603421040
|
£1.75
|
£2.10
|
|
|
35 - SINTERED-METAL BUSHING
BSD-2600301049.A19
2600301049
|
£1.75
|
£2.10
|
|
|
36 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2194
2603410001
|
£1.75
|
£2.10
|
|
|
37 - ON-OFF SWITCH
BSD-2607200048.A94
2607200048
|
-
|
|
|
|
38 - SUPPRESSION CAPACITOR
BSD-2607329099.A3
2607329099
|
-
|
|
|
|
39 - POWER SUPPLY CORD GB 110V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460205.A110
2604460205
|
£27.23
|
£32.68
|
|
|
40 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A828
2600703012
|
£2.80
|
£3.36
|
|
|
40 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A396
2600703013
|
£2.61
|
£3.13
|
|
|
40 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A435
2600703011
|
£2.80
|
£3.36
|
|
|
41 - FASTENING CLAMP
BSD-1601034026.A7
1601034026
|
-
|
|
|
|
42 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A287
2910211005
|
£1.75
|
£2.10
|
|
|
44 - CHANGE-OVER SWITCH
BSD-1607200050.A32
1607200050
|
-
|
|
|
|
45 - SILICON DIODE
BSD-2607320008.A116
2607320008
|
-
|
|
|
|
46 - BASE PLATE
BSD-2601016043.A5
2601016043
|
-
|
|
|
|
48 - SQUARE NUT DIN 562-M5-04
BSD-2915121005.A17
2915121005
|
£1.75
|
£2.10
|
|
|
49 - PAN HEAD SCREW
BSD-2603410028.A5
2603410028
|
-
|
|
|
|
50 - SEALING CAP
BSD-1605500078.A11
1605500078
|
-
|
|
|
|
50 - HOUSING COVER
BSD-2605500037.A10
2605500037
|
-
|
|
|
|
51 - MANUFACTURER'S NAMEPLATE
BSD-2601007003.A129
2601007003
|
-
|
|
|
|
51 - MANUFACTURER'S NAMEPLATE
BSD-2601110043.A4
2601110043
|
-
|
|
|
|
51 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A498
1601110481
|
£2.16
|
£2.59
|
|
|
52 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A399
2910211019
|
£1.75
|
£2.10
|
|
|
53 - TAPPING SCREW DIN 7971-BZ3.9x9.5
BSD-2910211017.A76
2910211017
|
-
|
|
|
|
54 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A239
2910211006
|
£1.75
|
£2.10
|
|
|
57 - INTERMEDIATE PLATE
BSD-2601000014.A3
2601000014
|
-
|
|
|
|
814 - CARBON BRUSH
BSD-1604321900.A38
1604321900
|
-
|
|
|
|
847 - RETAINING BRACKET
BSD-2608135900.A19
2608135900
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3538
160111A3H3
|
£2.61
|
£3.13
|
|
