2 - FIELD 220-240V
BSD-2604220655.A9
2604220655
|
-
|
|
|
|
3 - ARMATURE 220-240V
BSD-2604011234.A5
2604011234
|
£41.62
|
£49.95
|
|
|
3/50 - FAN
BSD-2606610029.A154
2606610029
|
£2.61
|
£3.13
|
|
|
4 - SWITCH
BSD-2607200524.A1
2607200524
|
£14.75
|
£17.70
|
|
|
5 - POWER SUPPLY CORD CH 2.65m 2 x 0.75mm H05 VV-F
BSD-1604460433.A5
1604460433
|
£11.30
|
£13.56
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A657
2600703017
|
£2.61
|
£3.13
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601117239.A1
2601117239
|
-
|
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601116702.A1
2601116702
|
-
|
|
|
|
13 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A594
2600905021
|
£8.67
|
£10.41
|
|
|
14 - FLANGED BEARING
BSD-2605805008.A0
2605805008
|
£5.30
|
£6.36
|
|
|
16 - BRUSH PLATE
BSD-1600A012AZ.A11
1600A012AZ
|
£11.30
|
£13.56
|
|
|
25 - BEARING BOLT
BSD-2603105080.A45
2603105080
|
£2.61
|
£3.13
|
|
|
29 - NEEDLE BEARING
BSD-2600914022.A4
2600914022
|
£6.52
|
£7.83
|
|
|
30 - SHIM 0.5 MM
BSD-2600101048.A61
2600101048
|
£1.75
|
£2.10
|
|
|
32 - SHIM 0.5 MM
BSD-2600101077.A0
2600101077
|
£1.75
|
£2.10
|
|
|
33 - FORK LEVER
BSD-2601923012.A47
2601923012
|
£4.26
|
£5.11
|
|
|
35 - BEARING BOLT
BSD-2603105091.A2
2603105091
|
£2.61
|
£3.13
|
|
|
36 - SHIM 0.5 MM
BSD-2600100588.A2
2600100588
|
£1.75
|
£2.10
|
|
|
37 - COUNTERWEIGHT
BSD-2601098060.A0
2601098060
|
£9.49
|
£11.39
|
|
|
38 - NEEDLE ROLLER 4x15.8 MM
BSD-1903201054.A9
1903201054
|
£1.75
|
£2.10
|
|
|
40 - LIFTING ROD
BSD-2600780147.A11
2600780147
|
-
|
|
|
|
41 - PLAIN BEARING
BSD-2605801038.A39
2605801038
|
£5.30
|
£6.36
|
|
|
42 - COMPRESSION SPRING
BSD-160461201E.A54
160461201E
|
£1.75
|
£2.10
|
|
|
43 - NEEDLE ROLLER
BSD-2603201089.A47
2603201089
|
£5.58
|
£6.70
|
|
|
44 - BEARING BOLT
BSD-2603105084.A9
2603105084
|
£2.16
|
£2.59
|
|
|
45 - BASE PLATE
BSD-2601098081.A2
2601098081
|
-
|
|
|
|
46 - PROFILE BEADING
BSD-2602317037.A9
2602317037
|
-
|
|
|
|
47 - FIXING PLATE
BSD-2600040003.A5
2600040003
|
£2.16
|
£2.59
|
|
|
49 - BASE PLATE
BSD-2601098050.A2
2601098050
|
-
|
|
|
|
50 - THREAD-FORMING TAP. SCREW
BSD-2603421014.A90
2603421014
|
£1.75
|
£2.10
|
|
|
51 - THREADED FITTING
BSD-2603349011.A0
2603349011
|
£5.58
|
£6.70
|
|
|
52 - STRAIGHT PIN 4M 6x10 N31A
BSD-2917850094.A1
2917850094
|
£1.75
|
£2.10
|
|
|
53 - TENSIONING LEVER
BSD-2602098016.A0
2602098016
|
£8.67
|
£10.41
|
|
|
54 - CAP-HANDLE
BSD-2600591013.A0
2600591013
|
-
|
|
|
|
58 - ROLLER LEVER
BSD-2601321051.A3
2601321051
|
-
|
|
|
|
59 - STRAIGHT PIN
BSD-2609002725.A48
2609002725
|
£1.75
|
£2.10
|
|
|
60 - SEALING PLATE
BSD-2601015077.A55
2601015077
|
£1.75
|
£2.10
|
|
|
64 - RATCHET CAP
BSD-2600590006.A1024
2600590006
|
£1.75
|
£2.10
|
|
|
65 - LOCKING ELEMENT
BSD-2601038111.A33
2601038111
|
-
|
|
|
|
67 - INDEXING DISK
BSD-2602026096.A2
2602026096
|
-
|
|
|
|
69 - SCREW 4x16
BSD-2603490022.A712
2603490022
|
£1.75
|
£2.10
|
|
|
71 - HANDLE COVER
BSD-2608040148.A4
2608040148
|
-
|
|
|
|
75 - COVERING HOOD
BSD-2605510169.A2
2605510169
|
-
|
|
|
|
78 - LOCKING PIN
BSD-2603105088.A26
2603105088
|
£1.75
|
£2.10
|
|
|
80 - SPEED GOVERNOR 230V
BSD-2607233051.A2
2607233051
|
-
|
|
|
|
207 - CABLE CLIP
BSD-2601035001.A741
2601035001
|
£1.75
|
£2.10
|
|
|
219 - SCREW 4x16
BSD-2603490022.A711
2603490022
|
£1.75
|
£2.10
|
|
|
801 - HOUSING SECTION
BSD-2605104788.A0
2605104788
|
-
|
|
|
|
808 - REFERENCE PLATE
BSD-2601117232.A0
2601117232
|
-
|
|
|
|
816/070 - CARBON-BRUSH SET
BSD-2604321925.A3
2604321925
|
£8.67
|
£10.41
|
|
|
826 - BEARING BRACKET
BSD-2605807936.A11
2605807936
|
-
|
|
|
|
827 - ECCENTRIC COG WHEEL
BSD-2606320904.A7
2606320904
|
-
|
|
|
|
834 - SPRING RETAINING RING DIN 471-4x0.4-FSt
BSD-2916640001.A42
2916640001
|
£1.75
|
£2.10
|
|
|
839 - SPRING RETAINING RING DIN 471-8x0.8 FSt
BSD-2916640005.A52
2916640005
|
£1.75
|
£2.10
|
|
|
891 - CROSS RECESSED-HEAD SCREW M3x5
BSD-2603410046.A168
2603410046
|
£2.16
|
£2.59
|
|
|
895 - LOCK
BSD-2601320027.A5
2601320027
|
£2.80
|
£3.36
|
|
