1 - HANDLE COVER
BSD-2605104442.A3
2605104442
|
-
|
|
|
|
2 - FIELD 230V
BSD-2604220538.A9
2604220538
|
-
|
|
|
|
3 - ARMATURE 230-240V
BSD-2604011018.A6
2604011018
|
-
|
|
|
|
3/50 - FAN
BSD-2606610079.A7
2606610079
|
-
|
|
|
|
4 - SWITCH
BSD-2607200260.A355
2607200260
|
£11.30
|
£13.56
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A178
2600703017
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2180
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118413.A2
2601118413
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A331
1607328028
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING
BSD-2600905034.A57
2600905034
|
£13.12
|
£15.75
|
|
|
16 - BRUSH PLATE
BSD-2604337118.A68
2604337118
|
£23.86
|
£28.63
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1713
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1820
2603490022
|
£1.75
|
£2.10
|
|
|
28 - HEX NUT DIN 934-M 5-m-8
BSD-2915011006.A159
2915011006
|
-
|
|
|
|
32 - CONTACT SPRING
BSD-2601329057.A245
2601329057
|
-
|
|
|
|
35 - HEX SOCKET HEAD CAP SCREW DIN 6912-M6x16-8.8
BSD-2910370197.A11
2910370197
|
-
|
|
|
|
36 - RUBBER BUFFER
BSD-1603100036.A17
1603100036
|
£1.75
|
£2.10
|
|
|
38 - CONNECTING CABLE L=115 MM
BSD-2604448109.A86
2604448109
|
£1.75
|
£2.10
|
|
|
39 - CABLE L=233 MM
BSD-1614431010.A6
1614431010
|
£3.72
|
£4.47
|
|
|
41 - CABLE L=103MM
BSD-2604448140.A19
2604448140
|
£1.32
|
£1.58
|
|
|
43 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A641
2603490023
|
£1.75
|
£2.10
|
|
|
44 - SEAL STRIP
BSD-2602380003.A18
2602380003
|
£1.32
|
£1.58
|
|
|
45 - DAMPING PLATE
BSD-2601022000.A267
2601022000
|
£1.75
|
£2.10
|
|
|
48 - PUSHER
BSD-2608005043.A29
2608005043
|
£1.75
|
£2.10
|
|
|
50 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A962
1907950006
|
£4.26
|
£5.11
|
|
|
51 - FRICTION RING
BSD-2600206011.A0
2600206011
|
-
|
|
|
|
733 - BACKING PAD dia 115 MM
BSD-2608601065.A9
2608601065
|
£9.62
|
£11.54
|
|
|
733 - BACKING PAD dia 115 MM
BSD-2608601064.A9
2608601064
|
£11.37
|
£13.64
|
|
|
733 - BACKING PAD dia 115 MM
BSD-2608601066.A9
2608601066
|
£8.74
|
£10.49
|
|
|
754 - DUST BAG
BSD-2605411067.A9
2605411067
|
£6.12
|
£7.34
|
|
|
754 - DUST BAG
BSD-2605411068.A30
2605411068
|
£13.99
|
£16.79
|
|
|
754 - DUST BAG
BSD-2605411096.A20
2605411096
|
£18.37
|
£22.04
|
|
|
790 - AUXILIARY HANDLE
BSD-2602026057.A7
2602026057
|
-
|
|
|
|
805 - POWER SUPPLY CORD EU 2.65m 2 x 1.0mm H05 RN-F
BSD-1607000388.A124
1607000388
|
£12.04
|
£14.45
|
|
|
808 - NAMEPLATE
BSD-2601119267.A0
2601119267
|
-
|
|
|
|
813 - CARTRIDGE BEARING
BSD-2605805005.A21
2605805005
|
£4.75
|
£5.70
|
|
|
816/04 - CARBON-BRUSH SET
BSD-2604321905.A35
2604321905
|
£11.30
|
£13.56
|
|
|
816/05 - COMPRESSION SPRING
BSD-2604610026.A30
2604610026
|
£2.61
|
£3.13
|
|
|
816/06 - RATCHET CAP
BSD-2601329051.A0
2601329051
|
£2.33
|
£2.80
|
|
|
816/06 - RATCHET CAP
BSD-2601322013.A506
2601322013
|
£1.75
|
£2.10
|
|
|
826 - FAN
BSD-2606610900.A0
2606610900
|
-
|
|
|
