1 - UPPER HOUSING
BSD-1609350001.A6
1609350001
|
-
|
|
|
|
1/20 - ROLLER
BSD-1609350003.A6
1609350003
|
-
|
|
|
|
1/30 - PUSH-BUTTON
BSD-1609350004.A28
1609350004
|
-
|
|
|
|
1/40 - COMPRESSION SPRING
BSD-1609350005.A6
1609350005
|
-
|
|
|
|
1/50 - MANUFACTURER'S NAMEPLATE
BSD-1601110972.A0
1601110972
|
-
|
|
|
|
3 - NAMEPLATE
BSD-1601110970.A0
1601110970
|
-
|
|
|
|
6 - RAISED CTSK TAPPING SCREW dia6x20 MM
BSD-1609350006.A30
1609350006
|
-
|
|
|
|
7 - OVAL-HEAD SCREW DIN 7985-M5x20-8.8-H
BSD-2910951162.A5
2910951162
|
-
|
|
|
|
8 - OVAL-HEAD SCREW M5x60 MM
BSD-1609350143.A5
1609350143
|
-
|
|
|
|
9 - SEALING CAP
BSD-1609350092.A25
1609350092
|
-
|
|
|
|
10 - INTERMEDIATE HOUSING
BSD-1609350193.A4
1609350193
|
-
|
|
|
|
11/1 - UPPER HOUSING
BSD-1609350002.A16
1609350002
|
-
|
|
|
|
14/1 - PRESSURE SWITCH
BSD-1609350194.A1
1609350194
|
-
|
|
|
|
17 - MOTOR CAPACITOR 25uF.50HZ
BSD-1609350015.A25
1609350015
|
-
|
|
|
|
18 - PLASTIC TUBING
BSD-1609350022.A9
1609350022
|
-
|
|
|
|
18/10 - TUBE MOUNTING
BSD-1609350023.A25
1609350023
|
-
|
|
|
|
18/20 - SEAL
BSD-1609350178.A5
1609350178
|
-
|
|
|
|
18/30 - FLAT SEAL RING
BSD-1609350179.A29
1609350179
|
-
|
|
|
|
18/40 - CUP SEAL
BSD-1609350180.A5
1609350180
|
-
|
|
|
|
19 - INTERMEDIATE HOUSING
BSD-1609350007.A6
1609350007
|
-
|
|
|
|
20 - POWER SUPPLY CORD
BSD-1609350118.A1
1609350118
|
-
|
|
|
|
21 - TAPPING SCREW ST dia3x20 MM
BSD-1609350142.A61
1609350142
|
-
|
|
|
|
22 - STRAIN-RELIEF CLAMP
BSD-1609350025.A9
1609350025
|
-
|
|
|
|
23 - OVAL-HEAD SCREW DIN 7985-M5x8-8.8-Z
BSD-2912311150.A27
2912311150
|
-
|
|
|
|
24 - CORD GUARD
BSD-1609350166.A5
1609350166
|
-
|
|
|
|
28 - SPRING RETAINING RING
BSD-1609350016.A9
1609350016
|
-
|
|
|
|
29 - FAN WHEEL
BSD-1609350017.A27
1609350017
|
-
|
|
|
|
30 - MOTOR 230V/50HZ
BSD-1609350202.A14
1609350202
|
-
|
|
|
|
31 - SPLASH GUARD
BSD-1609350093.A9
1609350093
|
-
|
|
|
|
40 - REPAIR KIT 50HZ
BSD-1609350195.A16
1609350195
|
-
|
|
|
|
41 - THRUST NEEDLE BEARING
BSD-1609350020.A9
1609350020
|
£27.23
|
£32.68
|
|
|
42 - CYLINDER BLOCK
BSD-1609350021.A25
1609350021
|
-
|
|
|
|
42/30 - PARTS SET
BSD-1609350309.A10
1609350309
|
-
|
|
|
|
43 - COMPRESSION SPRING
BSD-1609350027.A25
1609350027
|
-
|
|
|
|
44 - O-RING 80x2 MM
BSD-1609350098.A6
1609350098
|
-
|
|
|
|
45 - PLUG
BSD-1609350308.A53
1609350308
|
-
|
|
|
|
45/10 - PARTS SET dia1.78xdia7.66 MM
BSD-1609350081.A67
1609350081
|
-
|
|
|
|
47 - FILTER SCREEN
BSD-1609350032.A9
1609350032
|
-
|
|
|
|
48 - RETAINING RING
BSD-1609350033.A25
1609350033
|
-
|
|
|
|
49 - RUBBER COLLAR
BSD-1609350035.A9
1609350035
|
-
|
|
|
|
50 - THRUST RING
BSD-1609350036.A27
1609350036
|
-
|
|
|
|
51 - PARTS SET dia1.6xdia15.1 MM
BSD-1609350038.A27
1609350038
|
-
|
|
|
|
52 - PARTS SET dia1.6xdia6.1 MM
BSD-1609350039.A9
1609350039
|
-
|
|
|
|
53 - CYLINDER HEAD
BSD-1609350028.A9
1609350028
|
-
|
|
|
|
54 - PARTS SET dia1.78xdia11.11 MM
BSD-1609350029.A25
1609350029
|
-
|
|
|
|
55 - CUP SEAL
BSD-1609350037.A9
1609350037
|
-
|
|
|
|
56/50 - PARTS SET dia2x10 MM
BSD-1609350065.A76
1609350065
|
-
|
|
|
|
59 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x65-8.8
BSD-2910141218.A29
2910141218
|
£2.61
|
£3.13
|
|
|
60 - VALVE HOUSING
BSD-1609350196.A1
1609350196
|
-
|
|
|
|
62 - FLOW THROTTLE
BSD-1609350197.A16
1609350197
|
-
|
|
|
|
63 - PRESSURE MODULATION VALVE
BSD-1609350063.A9
1609350063
|
-
|
|
|
|
63/10 - PARTS SET dia2.4xdia12.3 MM
BSD-1609350177.A29
1609350177
|
-
|
|
|
|
64 - PLUG
BSD-1609350306.A24
1609350306
|
-
|
|
|
|
64/10 - PARTS SET dia2.4xdia16.6 MM
BSD-1609350140.A5
1609350140
|
-
|
|
|
|
65 - PRESSURE GAUGE
BSD-1609350307.A10
1609350307
|
-
|
|
|
|
65/10 - PARTS SET dia2xdia6 MM
BSD-1609350175.A29
1609350175
|
-
|
|
|
|
66 - PLUG
BSD-1609350308.A52
1609350308
|
-
|
|
|
|
66/10 - PARTS SET dia1.78xdia7.66 MM
BSD-1609350081.A66
1609350081
|
-
|
|
|
|
68 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x35-8.8
BSD-2910141207.A48
2910141207
|
-
|
|
|
|
70 - HOUSING BASE
BSD-1609350041.A25
1609350041
|
-
|
|
|
|
70/20 - FOAM PANEL
BSD-1609350068.A9
1609350068
|
-
|
|
|
|
71 - CASING FOOT
BSD-1609350069.A25
1609350069
|
-
|
|
|
|
72 - OVAL-HEAD SCREW DIN 7985-M6x20-8.8-Z
BSD-2912311201.A28
2912311201
|
-
|
|
|
|
73 - SEAL KIT
BSD-1609350044.A9
1609350044
|
-
|
|
|
|
74 - REPAIR KIT
BSD-1609350045.A25
1609350045
|
-
|
|
|
|
76 - PACKING SLEEVE
BSD-1609350066.A9
1609350066
|
-
|
|
|
|
76/10 - PARTS SET dia2x10 MM
BSD-1609350065.A78
1609350065
|
-
|
|
|
|
78 - INLET CONNECTOR
BSD-1609350067.A25
1609350067
|
-
|
|
|
|
650 - HANDLE
BSD-1609350199.A33
1609350199
|
-
|
|
|
|
650/12 - CONNECTING TUBE
BSD-1609350089.A27
1609350089
|
-
|
|
|
|
650/15 - TAPPING SCREW ST dia3x20 MM
BSD-1609350142.A62
1609350142
|
-
|
|
|
|
650/18 - PLASTIC HOSE L=9 M. MAX. 150 BAR
BSD-1609350504.A6
1609350504
|
-
|
|
|
|
650/18 - PLASTIC HOSE L=9 M. MAX. 150 BAR
BSD-1609350504.A7
1609350504
|
-
|
|
|
|
650/18/12 - PARTS SET dia2xdia11 MM
BSD-1609350074.A2
1609350074
|
-
|
|
|
|
650/18/17 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A488
1609350078
|
-
|
|
|
|
650/19 - REPAIR KIT
BSD-1609350080.A1
1609350080
|
-
|
|
|
|
650/20 - PARTS SET
BSD-1609350176.A5
1609350176
|
-
|
|
|
|
650/40 - GUIDE SLEEVE
BSD-1609350198.A1
1609350198
|
-
|
|
|
|
651 - HIGH PRESS CLEAN NOZZLE
BSD-1609350186.A0
1609350186
|
-
|
|
|
|
651/10 - NOZZLE RETAINING NUT
BSD-1609350145.A30
1609350145
|
-
|
|
|
|
651/11 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A490
1609350078
|
-
|
|
|
|
651/20 - PARTS SET dia2.0xdia18.0 MM
BSD-1609350182.A7
1609350182
|
-
|
|
|
|
651/30 - PARTS SET dia1.78xdia18.77 MM
BSD-1609350181.A31
1609350181
|
-
|
|
|
|
652 - FOAM SPRAY DEVICE
BSD-1609350047.A9
1609350047
|
-
|
|
|
|
652/10 - SINGLE-ORIFICE NOZZLE
BSD-1609350104.A28
1609350104
|
-
|
|
|
|
652/60 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A489
1609350078
|
-
|
|
|
|
652/90 - PARTS SET
BSD-1609350115.A29
1609350115
|
-
|
|
|
|
653 - CLEANING PIN
BSD-1609350124.A11
1609350124
|
-
|
|
|
|
676 - HOSE COUPLING
BSD-1609350049.A1
1609350049
|
-
|
|
|
|
676/76 - GASKET dia15xdia24x3=3/4
BSD-1609351002.A180
1609351002
|
-
|
|
|
|
676/77 - HOSE CLAMP
BSD-1609350070.A9
1609350070
|
-
|
|
|
|
678 - TAP CONNECTION PIECE 3/4
BSD-0600800001.A9
0600800001
|
-
|
|
|
|
678/10 - GASKET dia15xdia24x4.5=3/4
BSD-1609351029.A94
1609351029
|
£1.75
|
£2.10
|
|
|
700 - FLEXIBLE CONNECTION L=7 M
BSD-2609200276.A6
2609200276
|
-
|
|
|
|
700/10 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A496
1609350078
|
-
|
|
|
|
701 - HIGH PRESS CLEAN NOZZLE
BSD-1609350187.A17
1609350187
|
-
|
|
|
|
701/10 - NOZZLE CARRIER
BSD-1609350190.A1
1609350190
|
-
|
|
|
|
701/11 - REPAIR KIT
BSD-1609350191.A16
1609350191
|
-
|
|
|
|
701/12 - CONNECTING TUBE
BSD-1609350090.A9
1609350090
|
-
|
|
|
|
701/13 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A497
1609350078
|
-
|
|
|
|
701/20 - PARTS SET dia2xdia37 MM
BSD-1609350084.A1
1609350084
|
-
|
|
|
|
701/30 - PARTS SET dia1.78xdia34.65 MM
BSD-1609350184.A29
1609350184
|
-
|
|
|
|
702 - EXTENSION TUBE
BSD-1609350053.A9
1609350053
|
-
|
|
|
|
702/80 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A495
1609350078
|
-
|
|
|
|
703 - CLEANING BRUSH
BSD-1609350156.A35
1609350156
|
-
|
|
|
|
703/20 - GASKET dia15xdia24x3=3/4
BSD-1609351002.A181
1609351002
|
-
|
|
|
|
703/30 - ADAPTER
BSD-1609350159.A10
1609350159
|
-
|
|
|
|
703/40 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A498
1609350078
|
-
|
|
|
|
704 - ROTARY CLEANING BRUSH
BSD-1609350126.A26
1609350126
|
-
|
|
|
|
704/20 - GASKET dia15xdia24x3=3/4
BSD-1609351002.A182
1609351002
|
-
|
|
|
|
704/30 - CONNECTING PIECE
BSD-1609351014.A64
1609351014
|
£21.52
|
£25.83
|
|
|
704/40 - ADAPTER
BSD-1609350159.A11
1609350159
|
-
|
|
|
|
704/50 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A494
1609350078
|
-
|
|
|
|
705 - PIPE CLEANING SET L=7 M
BSD-1609350054.A31
1609350054
|
-
|
|
|
|
705/1 - PIPE CLEANING SET L=15 M
BSD-1609350055.A9
1609350055
|
-
|
|
|
|
705/10 - PIPE NOZZLE
BSD-1609350137.A15
1609350137
|
-
|
|
|
|
705/20 - PARTS SET dia1.6xdia10 MM
BSD-1609350088.A9
1609350088
|
-
|
|
|
|
705/60 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A493
1609350078
|
-
|
|
|
|
706 - PIPE CLEANING SET L=7 M
BSD-1609350056.A25
1609350056
|
-
|
|
|
|
706/60 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A492
1609350078
|
-
|
|
|
|
707 - JET PIPE
BSD-1609350057.A9
1609350057
|
-
|
|
|
|
707/10 - NOZZLE RETAINING NUT
BSD-1609350136.A25
1609350136
|
-
|
|
|
|
707/60 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A491
1609350078
|
-
|
|
|
|
708 - SPACER
BSD-1609350119.A25
1609350119
|
-
|
|
|
|
708/10 - CLAMP SCREW
BSD-1609350120.A15
1609350120
|
-
|
|
|
|
708/20 - CLAMPING PIECE
BSD-1609350121.A25
1609350121
|
-
|
|
|
|
708/30 - WHEEL
BSD-1609350122.A15
1609350122
|
-
|
|
|
|
708/40 - SEALING CAP
BSD-1609350123.A25
1609350123
|
-
|
|
|
|
709 - SAND BLAST EQUIPMENT
BSD-1609350188.A0
1609350188
|
-
|
|
|
|
709/10 - NOZZLE-HOLDER ASSEMBLY
BSD-1609350146.A10
1609350146
|
-
|
|
|
|
709/11 - SUCTION CONNECTION PIECE
BSD-1609350135.A14
1609350135
|
-
|
|
|
|
709/12 - CONNECTING TUBE
BSD-1609350192.A0
1609350192
|
-
|
|
|
|
709/13 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A499
1609350078
|
-
|
|
|
|
709/20 - OVAL-HEAD SCREW DIN 7985-M4x20-8.8-Z
BSD-2912311130.A14
2912311130
|
-
|
|
|
|
709/30 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A453
2915011005
|
£1.75
|
£2.10
|
|
|
709/40 - TAPPING SCREW DIN7981-ST2.9x9.5C-Z
BSD-2912401005.A1
2912401005
|
£1.75
|
£2.10
|
|
|
709/50 - NOZZLE
BSD-1609350134.A30
1609350134
|
-
|
|
|
|
709/60 - PARTS SET dia2xdia11 MM
BSD-1609350074.A1
1609350074
|
-
|
|
|
|
710 - EQUIPMENT TROLLEY
BSD-2608005050.A28
2608005050
|
-
|
|
|
|
710/40 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x25-8.8
BSD-2910141203.A101
2910141203
|
£1.75
|
£2.10
|
|
|
710/50 - WING NUT DIN 1709 BM 6 VERZINKT
BSD-2915191106.A26
2915191106
|
-
|
|
|
|
710/60 - WHEEL dia200 MM
BSD-1609351088.A79
1609351088
|
£12.04
|
£14.45
|
|
|
711 - INJECTOR
BSD-1609350128.A9
1609350128
|
-
|
|
|
|
711/10/10 - PARTS SET dia2x10 MM
BSD-1609350065.A74
1609350065
|
-
|
|
|
|
711/20 - REPAIR KIT
BSD-1609350169.A27
1609350169
|
-
|
|
|
|
711/30 - DOSING UNIT
BSD-1609350170.A7
1609350170
|
-
|
|
|
|
711/40 - HOSE
BSD-1609350171.A27
1609350171
|
£10.82
|
£12.99
|
|
|
711/50 - HOSE CLAMP
BSD-1609350172.A7
1609350172
|
-
|
|
|
|
712 - NON-RETURN VALVE
BSD-1609350060.A5
1609350060
|
-
|
|
|
|
712/10 - GASKET dia15xdia24x3=3/4
BSD-1609351002.A179
1609351002
|
-
|
|
|
|
713 - CLEANING AGENT 1x0.55 LITER
BSD-1609350153.A6
1609350153
|
-
|
|
|
|
714 - CLEANING AGENT 1x2.5 LITER
BSD-1609350155.A7
1609350155
|
-
|
|
|
|
715 - WAX 1x0.55 LITER
BSD-1609350161.A31
1609350161
|
-
|
|
|
|
716 - WAX 1x2.5 LITER
BSD-1609350162.A9
1609350162
|
-
|
|
|
|
717 - EXTENSION TUBE 410 MM
BSD-1609350164.A33
1609350164
|
-
|
|
|
|
717/60 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A500
1609350078
|
-
|
|
|
|
898 - CONTAINER 0.55 LITER. 12 STCK.
BSD-1609350189.A11
1609350189
|
-
|
|
|
