Bosch AVR 1100 / 3600H8A130 / CH 230 Volt Spare Parts

Bosch AVR 1100 / 3600H8A130 / CH 230 Volt Spare Parts
An exploded drawing and listing for the Bosch AVR 1100 / 3600H8A130 / CH 230 Volt
Ex VAT Inc VAT
39/2 - WING NUT BSD-F016L66136.A78 F016L66136 £4.26 £5.11
39/3 - TRUNNION BSD-F016L65389.A10 F016L65389 -
40/1 - CHASSIS BSD-F016L67969.A3 F016L67969 £30.28 £36.33
40/2 - ADJUSTING LEVER BSD-F016L66356.A4 F016L66356 -
40/3 - GUARD FLAP BSD-F016L66359.A2 F016L66359 £14.91 £17.89
40/4 - SPRING BSD-F016L66363.A4 F016L66363 £1.95 £2.34
43 - MOTOR HOOD BSD-F016L66357.A1 F016L66357 £16.74 £20.09
55/1 - ROTOR SHAFT BSD-F016L66661.A2 F016L66661 £14.72 £17.67
55/2 - BEARING 6002-2RS BSD-F016L67442.A69 F016L67442 £4.22 £5.06
55/3 - PULLEY BSD-F016L66390.A1 F016L66390 £9.49 £11.39
55/4 - BLADE HOLDER BSD-F016L66386.A1 F016L66386 £16.41 £19.69
55/5 - KNIFE BSD-F016L66388.A1 F016L66388 £3.72 £4.47
55/6 - SLOTTED SPRING PIN BSD-F016L66389.A1 F016L66389 £1.75 £2.10
55/7 - END CAP BSD-F016L66387.A1 F016L66387 £10.82 £12.99
55/8 - SHIELD BSD-F016L66613.A3 F016L66613 £3.34 £4.01
64 - RATCHET CAP 9 MM BSD-F016F05700.A61 F016F05700 £1.95 £2.34
75/1 - HANDLE BSD-F016L66351.A1 F016L66351 £21.68 £26.01
75/4/1 - SWITCH HOUSING BSD-F016L66234.A1 F016L66234 £3.34 £4.01
75/4/2 - SWITCH HOUSING BSD-F016L66235.A99 F016L66235 £3.34 £4.01
75/4/4 - COMPRESSION SPRING BSD-F016L66240.A49 F016L66240 £1.75 £2.10
75/4/5 - LEAF SPRING BSD-F016L66416.A0 F016L66416 £1.66 £1.99
75/4/6 - PUSH-BUTTON BSD-F016F05705.A84 F016F05705 £3.75 £4.50
75/4/7 - SELF-CUTTING SCREW 4x19 MM BSD-F016T49429.A681 F016T49429 £1.75 £2.10
75/4/11 - CLAMPING PIECE BSD-F016F05709.A1 F016F05709 £1.75 £2.10
75/14 - SELF-CUTTING SCREW 4x19 MM BSD-F016T49429.A680 F016T49429 £1.75 £2.10
75/27 - CABLE CLIP BSD-F016L90575.A3 F016L90575 £1.75 £2.10
78 - BOTTOM HANDLE BSD-F016L66398.A2 F016L66398 £11.78 £14.13
80 - COLLECTION BOX BSD-F016F05711.A1 F016F05711 £19.46 £23.35
83/02 - HANDLE BSD-F016L66441.A11 F016L66441 £4.75 £5.70
83/03 - LATCH BSD-F016F05680.A0 F016F05680 £1.95 £2.34
89 - AXLE 9 MM BSD-F016L66365.A1 F016L66365 £8.67 £10.41
90 - GRILLE L/H BSD-F016L66358.A5 F016L66358 £8.49 £10.19
91 - GRILLE R/H BSD-F016L66360.A5 F016L66360 £10.10 £12.12
92 - DRIVE BELT BSD-F016L66343.A4 F016L66343 £11.78 £14.13
93 - BEARING CLAMP BSD-F016L66376.A0 F016L66376 £2.33 £2.80
94 - BEARING CLAMP BSD-F016L66375.A4 F016L66375 -
98 - CLAMPING PIECE BSD-F016L66342.A0 F016L66342 £3.34 £4.01
99 - AIR FILTER BSD-F016L66749.A1 F016L66749 £3.80 £4.56
452 - COMPANY LOGO BSD-F016L66212.A1 F016L66212 £6.61 £7.93
455 - STICKER BSD-F016L66401.A0 F016L66401 £2.61 £3.13
500 - SELF-CUTTING SCREW 4x19 MM BSD-F016T49429.A682 F016T49429 £1.75 £2.10
801 - MOTOR BSD-F016104192.A5 F016104192 £88.07 £105.68
801/3 - SPRING BSD-F016L66344.A0 F016L66344 £1.75 £2.10
801/802 - TENSIONER ARM BSD-F016104000.A1 F016104000 £5.87 £7.04
839/3 - BOLT M6x50 BSD-F016L59277.A37 F016L59277 £3.80 £4.56
855 - CUTTER BSD-F016104190.A1 F016104190 £81.81 £98.17
875/4/10 - ON-OFF SWITCH BSD-F016F05717.A72 F016F05717 £14.91 £17.89
875/4/808 - POWER SUPPLY CORD CH BSD-F016104359.A3 F016104359 £21.52 £25.83
875/4/809 - CONNECTION CABLE BSD-F016105348.A3 F016105348 -
875/18 - CONTROL BAR BSD-F016103913.A1 F016103913 -
883 - COVER BSD-F016F05681.A1 F016F05681 £19.46 £23.35
884 - THERMAL PROTECTOR BSD-F016104025.A1 F016104025 -
887 - WHEEL BSD-F016103908.A13 F016103908 £7.78 £9.33
