1/21 - DRIVE BELT
BSD-F016L66677.A15
F016L66677
|
£11.78
|
£14.13
|
|
|
40/3 - COMB
BSD-F016L66697.A9
F016L66697
|
£1.75
|
£2.10
|
|
|
41 - SUPPORT ELEMENT
BSD-F016L67976.A4
F016L67976
|
£1.75
|
£2.10
|
|
|
45 - CARRYING HANDLE
BSD-F016L66654.A13
F016L66654
|
£2.80
|
£3.36
|
|
|
52 - AXLE
BSD-F016L66849.A0
F016L66849
|
£7.36
|
£8.83
|
|
|
55 - CUTTER BLADE 320 MM
BSD-F016L64191.A23
F016L64191
|
£14.75
|
£17.70
|
|
|
59 - HEX SCREW M8x20 MM
BSD-F016T48547.A24
F016T48547
|
£2.61
|
£3.13
|
|
|
61 - AXLE
BSD-F016L66848.A16
F016L66848
|
£7.36
|
£8.83
|
|
|
75/1 - HANDLE
BSD-F016L62792.A4
F016L62792
|
£23.86
|
£28.63
|
|
|
75/4/1 - SWITCH HOUSING
BSD-F016L66234.A12
F016L66234
|
£3.34
|
£4.01
|
|
|
75/4/2 - SWITCH HOUSING
BSD-F016L66235.A88
F016L66235
|
£3.34
|
£4.01
|
|
|
75/4/3 - POSITIONING LEVER
BSD-F016L66238.A25
F016L66238
|
£5.98
|
£7.18
|
|
|
75/4/4 - COMPRESSION SPRING
BSD-F016L66240.A39
F016L66240
|
£1.75
|
£2.10
|
|
|
75/4/5 - LEAF SPRING
BSD-F016L66416.A10
F016L66416
|
£1.66
|
£1.99
|
|
|
75/4/6 - PUSH-BUTTON
BSD-F016F05705.A74
F016F05705
|
£3.75
|
£4.50
|
|
|
75/4/7 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A605
F016T49429
|
£1.75
|
£2.10
|
|
|
75/4/11 - CLAMPING PIECE
BSD-F016F05709.A10
F016F05709
|
£1.75
|
£2.10
|
|
|
75/4/14 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A606
F016T49429
|
£1.75
|
£2.10
|
|
|
78 - BOTTOM HANDLE
BSD-F016L66682.A19
F016L66682
|
£8.67
|
£10.41
|
|
|
79 - BOTTOM HANDLE
BSD-F016L66655.A18
F016L66655
|
£8.67
|
£10.41
|
|
|
80 - COLLECTOR BOX BOTTOM
BSD-F016L66683.A15
F016L66683
|
£14.91
|
£17.89
|
|
|
82 - GUARD FLAP
BSD-F016L66686.A15
F016L66686
|
£4.26
|
£5.11
|
|
|
84 - CARRYING HANDLE
BSD-F016L66685.A18
F016L66685
|
£3.49
|
£4.19
|
|
|
85 - CLOSING SPRING
BSD-F016L66687.A18
F016L66687
|
£1.75
|
£2.10
|
|
|
90 - SPRING
BSD-F016L65773.A25
F016L65773
|
£1.75
|
£2.10
|
|
|
93 - THERMAL PROTECTOR
BSD-F016L65199.A10
F016L65199
|
-
|
|
|
|
96 - BELT TENSIONER
BSD-F016L68711.A1
F016L68711
|
£6.25
|
£7.50
|
|
|
98 - BAFFLE
BSD-F016L66688.A15
F016L66688
|
£5.30
|
£6.36
|
|
|
99 - BALANCE WEIGHTS
BSD-F016L66698.A11
F016L66698
|
£8.67
|
£10.41
|
|
|
108 - BEARING COVER
BSD-F016L66689.A9
F016L66689
|
£1.75
|
£2.10
|
|
|
150 - ROLLER
BSD-F016L66853.A4
F016L66853
|
-
|
|
|
|
151 - ROLLER CARRIER L/H
BSD-F016L66855.A4
F016L66855
|
£2.16
|
£2.59
|
|
|
152 - ROLLER CARRIER R/H
BSD-F016L66856.A0
F016L66856
|
£2.16
|
£2.59
|
|
|
153 - SPINDLE
BSD-F016L66854.A7
F016L66854
|
£5.58
|
£6.70
|
|
|
452 - COMPANY LOGO ROTAK 32 R
BSD-F016L67239.A1
F016L67239
|
£3.72
|
£4.47
|
|
|
455 - STICKER
BSD-F016L67252.A6
F016L67252
|
£2.61
|
£3.13
|
|
|
501 - PLAIN WASHER dia8.15
BSD-F016T48185.A18
F016T48185
|
£3.72
|
£4.47
|
|
|
502 - FLANGE-HEAD SCREW
BSD-F016L68323.A13
F016L68323
|
£1.75
|
£2.10
|
|
|
503 - SECURING CAP dia8 MM
BSD-F016T48990.A81
F016T48990
|
£1.75
|
£2.10
|
|
|
504 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A598
F016T49429
|
£1.75
|
£2.10
|
|
|
505/1 - SCREW M5x8 Csk Hd.
BSD-F016L36542.A54
F016L36542
|
£2.61
|
£3.13
|
|
|
506 - PARTS SET
BSD-F016L66155.A15
F016L66155
|
£2.92
|
£3.50
|
|
|
801 - MOTOR
BSD-F016104035.A15
F016104035
|
£93.88
|
£112.65
|
|
|
801/1/18 - CAP
BSD-F016L64499.A17
F016L64499
|
£1.75
|
£2.10
|
|
|
840 - MOWER DECK
BSD-F016104246.A19
F016104246
|
£31.64
|
£37.97
|
|
|
840/1/2 - BEARING 6002-2RS
BSD-F016L67442.A56
F016L67442
|
£4.22
|
£5.06
|
|
|
843 - MOTOR HOOD
BSD-F016104033.A9
F016104033
|
£21.52
|
£25.83
|
|
|
875/4/8 - CONNECTING CABLE
BSD-F016104088.A10
F016104088
|
£13.41
|
£16.09
|
|
|
875/4/9 - POWER SUPPLY CORD GB 22m 2 x 0.75mm without plug
BSD-F016104085.A17
F016104085
|
£31.64
|
£37.97
|
|
|
875/4/10 - ON-OFF SWITCH
BSD-F016F05717.A94
F016F05717
|
£14.91
|
£17.89
|
|
|
883 - COLLECTOR BOX TOP
BSD-F016104032.A15
F016104032
|
£21.68
|
£26.01
|
|
|
887 - WHEEL
BSD-F016104038.A1
F016104038
|
£7.36
|
£8.83
|
|
|
891 - DRIVE SHAFT
BSD-F016104155.A15
F016104155
|
£14.91
|
£17.89
|
|
|
895 - CABLE CLIP
BSD-F016L66895.A22
F016L66895
|
£1.75
|
£2.10
|
|
