1 - MOTOR HOUSING
BSD-3600760006.A5
3600760006
|
£63.50
|
£76.20
|
|
|
2 - STATOR 180W
BSD-3604090011.A62
3604090011
|
£81.81
|
£98.17
|
|
|
3 - ROTOR
BSD-3604220009.A41
3604220009
|
£72.18
|
£86.62
|
|
|
5 - BEARING FLANGE
BSD-3605700015.A20
3605700015
|
£45.67
|
£54.80
|
|
|
6 - BALL BEARING 7x19x6
BSD-2600905032.A1256
2600905032
|
£5.30
|
£6.36
|
|
|
7 - BEARING FLANGE
BSD-3605700016.A48
3605700016
|
£59.53
|
£71.44
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A88
1900905028
|
£33.74
|
£40.49
|
|
|
11 - PLAIN WASHER DIN 433-5.3-ST
BSD-2916011011.A255
2916011011
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A151
2911061150
|
£2.61
|
£3.13
|
|
|
26 - PINION Z=6
BSD-3606300010.A14
3606300010
|
£16.74
|
£20.09
|
|
|
27 - STOP DISC
BSD-3600101047.A29
3600101047
|
£2.16
|
£2.59
|
|
|
28 - RING GEAR
BSD-3606334004.A17
3606334004
|
£40.80
|
£48.96
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A384
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A12
3603201000
|
£1.75
|
£2.10
|
|
|
36 - GROOVE BALL BEARING 12x21x5
BSD-3600905002.A157
3600905002
|
£16.41
|
£19.69
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337019.A0
3606337019
|
£81.81
|
£98.17
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316104.A9
3606316104
|
£21.68
|
£26.01
|
|
|
41 - GROOVE BALL BEARING 6001 Y DIN 625 FD150
BSD-1900900271.A7
1900900271
|
-
|
|
|
|
44 - THREADED BUSHING
BSD-3600390003.A61
3600390003
|
£12.04
|
£14.45
|
|
|
45 - RADIAL SEAL
BSD-3600283000.A8
3600283000
|
-
|
|
|
|
46 - THREADED RING
BSD-3603344004.A41
3603344004
|
£14.91
|
£17.89
|
|
|
56 - CONNECTION HOUSING
BSD-3605190018.A1
3605190018
|
-
|
|
|
|
57 - PROTECTIVE CAP
BSD-1820516004.A1
1820516004
|
-
|
|
|
|
66 - STRAIGHT PIN
BSD-3603201009.A4
3603201009
|
£5.58
|
£6.70
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A241
160111A3HF
|
£3.72
|
£4.47
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A20
3603133000
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1906
3601119236
|
£3.72
|
£4.47
|
|
|
700 - HOSE FITTING
BSD-3603386002.A64
3603386002
|
£3.34
|
£4.01
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031048.A15
3607031048
|
-
|
|
|
|
804 - PARTS SET
BSD-3607030256.A37
3607030256
|
£30.42
|
£36.51
|
|
