1 - MOTOR HOUSING
BSD-3600760015.A62
3600760015
|
£93.88
|
£112.65
|
|
|
2 - STATOR 370W
BSD-3604090002.A15
3604090002
|
£81.81
|
£98.17
|
|
|
3 - ROTOR
BSD-3604220002.A5
3604220002
|
£93.88
|
£112.65
|
|
|
5 - BEARING FLANGE
BSD-3605700005.A8
3605700005
|
£54.42
|
£65.30
|
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A306
3600905039
|
£12.04
|
£14.45
|
|
|
7 - BEARING FLANGE
BSD-3605700006.A53
3605700006
|
£72.18
|
£86.62
|
|
|
8 - GROOVE BALL BEARING DIN 625-7x19x6
BSD-3600905148.A20
3600905148
|
£8.49
|
£10.19
|
|
|
9 - SPACER RING
BSD-2600202013.A25
2600202013
|
£8.67
|
£10.41
|
|
|
10 - SPACER RING
BSD-2600202014.A171
2600202014
|
£11.30
|
£13.56
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A126
2916011012
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW
BSD-3603450007.A4
3603450007
|
£21.52
|
£25.83
|
|
|
14 - CYLINDRICAL GEAR
BSD-3606316101.A69
3606316101
|
£21.68
|
£26.01
|
|
|
15 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A306
3600913000
|
£4.26
|
£5.11
|
|
|
16 - CYLINDRICAL GEAR
BSD-3606316101.A70
3606316101
|
£21.68
|
£26.01
|
|
|
26 - PINION
BSD-3606300165.A8
3606300165
|
£31.64
|
£37.97
|
|
|
27 - STOP DISC
BSD-3600101001.A76
3600101001
|
£2.61
|
£3.13
|
|
|
28 - RING GEAR Z=49
BSD-3606334000.A97
3606334000
|
£102.57
|
£123.08
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337124.A8
3606337124
|
£102.57
|
£123.08
|
|
|
30 - COMPRESSION SPRING
BSD-3604617000.A55
3604617000
|
£1.75
|
£2.10
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A160
3603201000
|
£1.75
|
£2.10
|
|
|
34 - SHIM WASHER
BSD-3600103002.A101
3600103002
|
£3.72
|
£4.47
|
|
|
35 - RETAINING RING
BSD-3600224000.A101
3600224000
|
£1.75
|
£2.10
|
|
|
36 - GROOVE BALL BEARING 12x28x8
BSD-1900900287.A97
1900900287
|
£21.68
|
£26.01
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337005.A47
3606337005
|
£120.11
|
£144.13
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905069.A56
3600905069
|
£16.41
|
£19.69
|
|
|
43 - SPRING RETAINING RING
BSD-3600119000.A52
3600119000
|
£10.10
|
£12.12
|
|
|
53 - NEEDLE ROLLER DIN 5402-A 2x19.8G5
BSD-3603100026.A0
3603100026
|
£2.16
|
£2.59
|
|
|
54 - REVERSE-TRANSFER LEVER
BSD-3601960000.A9
3601960000
|
£2.16
|
£2.59
|
|
|
55 - SET SCREW
BSD-3603400001.A17
3603400001
|
£2.80
|
£3.36
|
|
|
57 - DAMPING PLATE
BSD-3601015007.A22
3601015007
|
£2.80
|
£3.36
|
|
|
58 - CONNECTION COVER
BSD-3605500014.A4
3605500014
|
£7.36
|
£8.83
|
|
|
59 - FITTING
BSD-3603373002.A13
3603373002
|
£12.04
|
£14.45
|
|
|
60 - STRAINER
BSD-3600002000.A223
3600002000
|
£3.72
|
£4.47
|
|
|
61 - THREADED RING
BSD-3603340005.A2
3603340005
|
£4.26
|
£5.11
|
|
|
63 - STRAIGHT PIN
BSD-3604710029.A8
3604710029
|
£12.04
|
£14.45
|
|
|
65 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-4.8
BSD-2910001134.A13
2910001134
|
£1.75
|
£2.10
|
|
|
66 - STRAIGHT PIN
BSD-3604710051.A3
3604710051
|
£10.10
|
£12.12
|
|
|
68 - BALL 8 MM III DIN 5401 ST
BSD-1903230524.A21
1903230524
|
£2.80
|
£3.36
|
|
|
69 - COMPRESSION SPRING
BSD-3604643007.A0
3604643007
|
£2.80
|
£3.36
|
|
|
71 - CONTROL PISTON
BSD-3608750010.A9
3608750010
|
£33.74
|
£40.49
|
|
|
72 - COILED SPRING PIN 2x12 DIN 7343
BSD-2917800037.A11
2917800037
|
£2.16
|
£2.59
|
|
|
73 - VALVE CONE
BSD-3603203012.A5
3603203012
|
£16.41
|
£19.69
|
|
|
74 - COMPRESSION SPRING
BSD-3604611002.A13
3604611002
|
£2.80
|
£3.36
|
|
|
75 - INTERMEDIATE PIECE
BSD-3600290003.A7
3600290003
|
£63.50
|
£76.20
|
|
|
76 - SEALING PLATE
BSD-3601015006.A0
3601015006
|
£2.61
|
£3.13
|
|
|
77 - CONTROL LEVER
BSD-3602033002.A2
3602033002
|
£8.67
|
£10.41
|
|
|
78 - STRAIGHT PIN DIN 6325-3M6x32
BSD-2917550088.A3
2917550088
|
£1.75
|
£2.10
|
|
|
79 - STUD
BSD-3603412001.A6
3603412001
|
£2.80
|
£3.36
|
|
|
80 - COMPRESSION SPRING
BSD-3604643010.A18
3604643010
|
£2.61
|
£3.13
|
|
|
92 - REFERENCE PLATE
BSD-3601110574.A96
3601110574
|
£2.61
|
£3.13
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A52
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601119055.A43
3601119055
|
£3.72
|
£4.47
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1462
3601119236
|
£3.72
|
£4.47
|
|
|
100 - HOUSING
BSD-3605125029.A7
3605125029
|
£135.25
|
£162.30
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445030.A38
3606445030
|
£102.57
|
£123.08
|
|
|
102 - DRIVE SHAFT
BSD-3606122008.A87
3606122008
|
£120.11
|
£144.13
|
|
|
103 - COILED SPRING PIN DIN 7343-2x5
BSD-2917800033.A22
2917800033
|
£1.75
|
£2.10
|
|
|
107 - COMPRESSION SPRING
BSD-3604610003.A24
3604610003
|
£3.72
|
£4.47
|
|
|
108 - COMPRESSION SPRING
BSD-3604610002.A133
3604610002
|
£3.72
|
£4.47
|
|
|
109 - COMPRESSION SPRING
BSD-3604619004.A48
3604619004
|
£6.52
|
£7.83
|
|
|
110 - RETAINING RING
BSD-3604601001.A156
3604601001
|
£2.16
|
£2.59
|
|
|
111 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A350
1903230007
|
£1.75
|
£2.10
|
|
|
115 - SEALING PLATE
BSD-3609992353.A21
3609992353
|
£2.80
|
£3.36
|
|
|
116 - ADJUSTING DISC
BSD-3600134000.A48
3600134000
|
£2.80
|
£3.36
|
|
|
118 - LOCKING BOLT
BSD-3603150203.A159
3603150203
|
£45.67
|
£54.80
|
|
|
119 - COUPLING PLATE
BSD-3600114001.A41
3600114001
|
£18.96
|
£22.75
|
|
|
120 - ROUND NUT
BSD-3603301004.A60
3603301004
|
£21.68
|
£26.01
|
|
|
121 - STRAIGHT PIN 37.0 MM
BSD-3603201025.A20
3603201025
|
£5.58
|
£6.70
|
|
|
122 - ROLLER THRUST BEARING
BSD-3600921000.A131
3600921000
|
£6.52
|
£7.83
|
|
|
124 - SUPPORT DISC
BSD-3600101002.A99
3600101002
|
£2.16
|
£2.59
|
|
|
127 - BALL DIN 5401-5 G28
BSD-1903230009.A327
1903230009
|
£1.75
|
£2.10
|
|
|
128 - BALL DIN 5401-6 G28
BSD-1903230011.A249
1903230011
|
£2.61
|
£3.13
|
|
|
131 - SPRING RETAINING RING 16x1 MM. DIN 472
BSD-2916660003.A73
2916660003
|
£1.75
|
£2.10
|
|
|
132 - SET SCREW
BSD-3603400001.A16
3603400001
|
£2.80
|
£3.36
|
|
|
138 - STRAIGHT PIN DIN 6325-5M2.5x12
BSD-2917530057.A38
2917530057
|
£1.75
|
£2.10
|
|
|
139 - SPINDLE HOUSING
BSD-3605106008.A6
3605106008
|
£179.37
|
£215.24
|
|
|
140 - RETAINING RING 14 DIN 9045
BSD-2916600008.A25
2916600008
|
£2.80
|
£3.36
|
|
|
141 - UNION NUT
BSD-3603342002.A0
3603342002
|
£16.41
|
£19.69
|
|
|
142 - RETAINING RING DIN 9045-24
BSD-2916600013.A5
2916600013
|
-
|
|
|
|
143 - THREADED RING
BSD-3603344011.A6
3603344011
|
£10.10
|
£12.12
|
|
|
144 - ROTARY SHAFT LIP SEAL 8X12X3
BSD-3600283034.A9
3600283034
|
£5.58
|
£6.70
|
|
|
145 - GROOVE BALL BEARING
BSD-1280905004.A27
1280905004
|
£31.64
|
£37.97
|
|
|
146 - SUPPORT DISC
BSD-3600100096.A10
3600100096
|
£18.96
|
£22.75
|
|
|
147 - NEEDLE BEARING dia8xdia12x10 MM
BSD-1610910057.A188
1610910057
|
£2.80
|
£3.36
|
|
|
148 - ROLLER THRUST BEARING
BSD-3600929003.A42
3600929003
|
£21.52
|
£25.83
|
|
|
149 - BEARING SLEEVE
BSD-3600300006.A1
3600300006
|
-
|
|
|
|
150 - BEVEL GEAR SET
BSD-3608871840.A2
3608871840
|
£283.50
|
£340.20
|
|
|
152 - BEARING FLANGE
BSD-3603462006.A5
3603462006
|
£48.38
|
£58.06
|
|
|
153 - RADIAL SEAL
BSD-3600283013.A7
3600283013
|
£10.10
|
£12.12
|
|
|
154 - NEEDLE BEARING dia 12 MM
BSD-2600914016.A27
2600914016
|
£3.72
|
£4.47
|
|
|
155 - SUPPORT DISC
BSD-3600101015.A2
3600101015
|
£13.12
|
£15.75
|
|
|
156 - ROLLER THRUST BEARING
BSD-3600929005.A6
3600929005
|
£18.96
|
£22.75
|
|
|
157 - NEEDLE BEARING
BSD-9001140359.A43
9001140359
|
£6.52
|
£7.83
|
|
|
158 - BEARING BOLT
BSD-3603120003.A7
3603120003
|
£37.27
|
£44.72
|
|
|
159 - SHIM
BSD-3600102010.A4
3600102010
|
£2.61
|
£3.13
|
|
|
159 - SHIM
BSD-3600102012.A4
3600102012
|
£2.61
|
£3.13
|
|
|
160 - GUIDE SLEEVE
BSD-3600320016.A34
3600320016
|
£14.91
|
£17.89
|
|
|
161 - COMPRESSION SPRING
BSD-1604611004.A25
1604611004
|
£2.80
|
£3.36
|
|
|
162 - PRESSURE SPINDLE
BSD-1603124060.A54
1603124060
|
£5.58
|
£6.70
|
|
|
652 - HOSE FITTING
BSD-2603386002.A272
2603386002
|
£5.30
|
£6.36
|
|
|
657 - ANGLE PIECE
BSD-3601329007.A68
3601329007
|
£4.26
|
£5.11
|
|
|
703 - HOSE FITTING dia 8 MM
BSD-3603386001.A103
3603386001
|
£16.41
|
£19.69
|
|
|
707 - OFFSET SCREWDRIVER DIN 911 SW10
BSD-1907950009.A52
1907950009
|
£21.68
|
£26.01
|
|
|
708 - SINGLE-HEAD ENG. WRENCH DIN 894 SW24
BSD-1907950513.A70
1907950513
|
£16.41
|
£19.69
|
|
|
712 - HEXAGON-SOCKET KEY
BSD-3607950001.A241
3607950001
|
£2.80
|
£3.36
|
|
|
758 - SILENCER
BSD-3603462000.A110
3603462000
|
£16.41
|
£19.69
|
|
|
759 - SILENCER
BSD-3607000073.A155
3607000073
|
£18.96
|
£22.75
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031018.A22
3607031018
|
£410.78
|
£492.94
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030248.A72
3607030248
|
£31.64
|
£37.97
|
|
|
821 - ASSEMBLY OF SERVICE PARTS
BSD-3607031087.A106
3607031087
|
£12.04
|
£14.45
|
|
|
839 - ANGLE SCREWDRIVER HEAD
BSD-3607020041.A8
3607020041
|
£1006.71
|
£1208.05
|
|
|
851 - ASSEMBLY OF SERVICE PARTS
BSD-3607031159.A1
3607031159
|
£195.26
|
£234.31
|
|
|
856 - VALVE BODY
BSD-3607031174.A1
3607031174
|
£500.46
|
£600.55
|
|
|
856 - SPARE VALVE BODY
BSD-3607031151.A1
3607031151
|
£283.50
|
£340.20
|
|
