1 - MOTOR HOUSING
BSD-3605108056.A7
3605108056
|
£21.52
|
£25.83
|
|
|
2 - STATOR 220-320W
BSD-3604090034.A3
3604090034
|
£21.68
|
£26.01
|
|
|
3 - ROTOR
BSD-3604220039.A2
3604220039
|
£81.81
|
£98.17
|
|
|
5 - BEARING FLANGE
BSD-3605700065.A5
3605700065
|
£10.10
|
£12.12
|
|
|
6 - GROOVE BALL BEARING 8x22x7
BSD-1600905011.A663
1600905011
|
£5.58
|
£6.70
|
|
|
7 - BEARING FLANGE
BSD-3605700064.A2
3605700064
|
£11.30
|
£13.56
|
|
|
8 - GROOVE BALL BEARING 7x14x5
BSD-1900905030.A47
1900905030
|
£33.74
|
£40.49
|
|
|
9 - O-RING 4.0x1.0 MM
BSD-3600210015.A56
3600210015
|
£3.72
|
£4.47
|
|
|
10 - NEEDLE ROLLER A 2x11.8G2DIN5402
BSD-1903201002.A38
1903201002
|
£1.75
|
£2.10
|
|
|
11 - SILENCER
BSD-3601010020.A3
3601010020
|
-
|
|
|
|
12 - SHIM
BSD-3600100030.A13
3600100030
|
£1.75
|
£2.10
|
|
|
27 - SHIM 0.2 MM
BSD-1610101603.A5
1610101603
|
£1.75
|
£2.10
|
|
|
30 - SPACER RING
BSD-3600209003.A11
3600209003
|
£5.58
|
£6.70
|
|
|
31 - CYLINDRICAL GEAR Z=14
BSD-3606316093.A78
3606316093
|
£2.61
|
£3.13
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A60
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A349
3603201000
|
£1.75
|
£2.10
|
|
|
34 - RETAINING SNAP RING
BSD-3600400008.A8
3600400008
|
£18.96
|
£22.75
|
|
|
35 - NEEDLE ROLLER A 3x15.8G2DIN5402
BSD-1903201044.A58
1903201044
|
£2.33
|
£2.80
|
|
|
37 - SHIM 0.3 MM
BSD-1600101618.A67
1600101618
|
£2.61
|
£3.13
|
|
|
38 - DRIVE SHAFT
BSD-3603050005.A3
3603050005
|
£48.38
|
£58.06
|
|
|
39 - CYLINDRICAL GEAR Z=14
BSD-3606316073.A2
3606316073
|
£2.61
|
£3.13
|
|
|
41 - GROOVE BALL BEARING
BSD-3600900011.A8
3600900011
|
£27.23
|
£32.68
|
|
|
42 - O-RING 28x2 MM
BSD-1900210327.A3
1900210327
|
£4.26
|
£5.11
|
|
|
43 - O-RING 30x2.5 MM
BSD-1900210131.A94
1900210131
|
£4.26
|
£5.11
|
|
|
45 - SHIM
BSD-2600102036.A57
2600102036
|
£2.61
|
£3.13
|
|
|
46 - TRANSMISSION CASE
BSD-3605125033.A5
3605125033
|
£23.86
|
£28.63
|
|
|
47 - GROOVE BALL BEARING
BSD-3600905015.A5
3600905015
|
£16.41
|
£19.69
|
|
|
48 - THREADED BUSHING
BSD-3600390003.A40
3600390003
|
£12.04
|
£14.45
|
|
|
56 - FITTING
BSD-3603462011.A7
3603462011
|
£14.91
|
£17.89
|
|
|
57 - VALVE BUSHING
BSD-3600209004.A0
3600209004
|
£2.16
|
£2.59
|
|
|
60 - STRAINER
BSD-3600002006.A38
3600002006
|
£3.72
|
£4.47
|
|
|
61 - SILENCER
BSD-2607000179.A12
2607000179
|
£8.67
|
£10.41
|
|
|
65 - O-RING 15x2 MM
BSD-1900210112.A174
1900210112
|
£2.61
|
£3.13
|
|
|
67 - STRAIGHT PIN
BSD-3603201043.A11
3603201043
|
£2.16
|
£2.59
|
|
|
69 - SHIM WASHER
BSD-3600105001.A40
3600105001
|
£1.75
|
£2.10
|
|
|
74 - O-RING 12.0x2.0 MM
BSD-1610210233.A47
1610210233
|
£2.80
|
£3.36
|
|
|
75 - VALVE SPOOL
BSD-3608750031.A3
3608750031
|
£14.91
|
£17.89
|
|
|
77 - PUSH-BUTTON
BSD-3602053003.A18
3602053003
|
£2.61
|
£3.13
|
|
|
78 - COUNTERSUNK-HEAD SCREW M 3x10 DIN 963-5.8
BSD-2910771052.A20
2910771052
|
-
|
|
|
|
79 - CONTROL LEVER
BSD-3602000000.A2
3602000000
|
£2.80
|
£3.36
|
|
|
83 - COMPRESSION SPRING
BSD-3604643012.A19
3604643012
|
£1.75
|
£2.10
|
|
|
88 - SILENCER
BSD-3601010006.A0
3601010006
|
£1.75
|
£2.10
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A561
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601119055.A158
3601119055
|
£3.72
|
£4.47
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A314
3601119236
|
£3.72
|
£4.47
|
|
|
652 - HOSE FITTING
BSD-2603386002.A101
2603386002
|
£5.30
|
£6.36
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030244.A27
3607030244
|
£23.86
|
£28.63
|
|
|
808 - ASSEMBLY OF SERVICE PARTS
BSD-3607031322.A11
3607031322
|
£63.50
|
£76.20
|
|
|
810 - VALVE SPOOL
BSD-3608750030.A3
3608750030
|
£33.74
|
£40.49
|
|
|
840 - O-RING
BSD-3607010005.A11
3607010005
|
-
|
|
|
|
844 - PARTS SET
BSD-3607010026.A28
3607010026
|
£8.67
|
£10.41
|
|
|
868 - VALVE CONE
BSD-3607030354.A20
3607030354
|
£14.91
|
£17.89
|
|
