4 - PIN
BSD-3609202153.A0
3609202153
|
-
|
|
|
5 - VALVE SEAT
BSD-3609202154.A0
3609202154
|
-
|
|
|
6 - VALVE BODY
BSD-3609202155.A0
3609202155
|
-
|
|
|
7 - COMPRESSION SPRING
BSD-3609202156.A0
3609202156
|
-
|
|
|
7/1 - RETAINING RING
BSD-3609202157.A0
3609202157
|
-
|
|
|
8 - FITTING
BSD-3609202158.A0
3609202158
|
-
|
|
|
8/1 - PLATE
BSD-3609202159.A0
3609202159
|
-
|
|
|
10 - O-RING
BSD-3609202161.A0
3609202161
|
-
|
|
|
11 - CHANGE-OVER SWITCH
BSD-3609202162.A0
3609202162
|
-
|
|
|
12 - KNURLED DISC
BSD-3609202120.A0
3609202120
|
£5.30
|
£6.36
|
|
13 - SCREW
BSD-3609202121.A1
3609202121
|
£3.72
|
£4.47
|
|
14 - LUBRICATING NIPPLE
BSD-3609202122.A0
3609202122
|
-
|
|
|
15 - SEAL
BSD-3609202166.A0
3609202166
|
£5.30
|
£6.36
|
|
16 - RETAINING RING
BSD-3609202167.A0
3609202167
|
-
|
|
|
17 - MINIATURE BALL BEARING
BSD-3609202168.A0
3609202168
|
-
|
|
|
18 - COVER
BSD-3609202169.A0
3609202169
|
£116.15
|
£139.38
|
|
19 - ROTOR
BSD-3609202170.A0
3609202170
|
-
|
|
|
20 - SET OF CLUTCH PLATES
BSD-3609202171.A0
3609202171
|
£40.80
|
£48.96
|
|
21 - CYLINDER
BSD-3609202172.A0
3609202172
|
-
|
|
|
22 - STRAIGHT PIN
BSD-3609202173.A0
3609202173
|
-
|
|
|
23 - STRAIGHT PIN
BSD-3609202174.A0
3609202174
|
-
|
|
|
24 - COVER
BSD-3609202175.A0
3609202175
|
£116.15
|
£139.38
|
|
25 - MINIATURE BALL BEARING
BSD-3609202176.A0
3609202176
|
£21.42
|
£25.71
|
|
26 - DISC SPRING
BSD-3609202177.A0
3609202177
|
-
|
|
|
28 - PIN
BSD-3609202179.A0
3609202179
|
-
|
|
|
30 - PLAIN WASHER
BSD-3609202180.A0
3609202180
|
-
|
|
|
31 - HAMMER PISTON
BSD-3609202181.A0
3609202181
|
-
|
|
|
33 - REAMED LINING
BSD-3609202183.A0
3609202183
|
-
|
|
|
34 - SEAL
BSD-3609202184.A0
3609202184
|
£5.30
|
£6.36
|
|
35 - REAMED LINING
BSD-3609202185.A0
3609202185
|
-
|
|
|
37 - PLAIN WASHER
BSD-3609202187.A0
3609202187
|
-
|
|
|
38 - SCREW
BSD-3609202188.A0
3609202188
|
-
|
|
|
43 - SPRING LOCK WASHER
BSD-3609202250.A0
3609202250
|
-
|
|
|
44 - O-RING
BSD-3609202251.A0
3609202251
|
-
|
|
|
45 - BALL
BSD-3609202124.A0
3609202124
|
-
|
|
|
46 - COMPRESSION SPRING
BSD-3609202119.A1
3609202119
|
-
|
|
|
47 - CENTRAL MUFFLER
BSD-3609202286.A0
3609202286
|
£16.74
|
£20.09
|
|
60 - NAMEPLATE
BSD-3609201443.A0
3609201443
|
-
|
|
|
61 - MANUFACTURER'S NAMEPLATE
BSD-3609201447.A0
3609201447
|
-
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A341
3601119236
|
£3.72
|
£4.47
|
|
650 - HOSE NIPPLE
BSD-3609202242.A0
3609202242
|
-
|
|
|
651 - KEY
BSD-3609202190.A1
3609202190
|
-
|
|
|
700 - SERVICE KIT
BSD-3609202271.A0
3609202271
|
-
|
|
|
700/20 - STRAIGHT PIN
BSD-3609202191.A0
3609202191
|
-
|
|
|
700/30 - COMPRESSION SPRING
BSD-3609202192.A0
3609202192
|
-
|
|
|
701 - HANGTAG
BSD-3609202280.A0
3609202280
|
-
|
|
|
702 - HANGTAG
BSD-3609202281.A0
3609202281
|
-
|
|
|
703 - GREASE GUN
BSD-3609202133.A2
3609202133
|
-
|
|
|
800 - SERVICE KIT
BSD-3609202266.A0
3609202266
|
-
|
|
|
801 - SERVICE KIT
BSD-3609202267.A0
3609202267
|
£41.62
|
£49.95
|
|
802 - SERVICE KIT
BSD-3609202268.A0
3609202268
|
-
|
|
|
803 - SERVICE KIT
BSD-3609202269.A0
3609202269
|
-
|
|
|
804 - SERVICE KIT
BSD-3609202270.A0
3609202270
|
-
|
|
|
808 - SERVICE KIT
BSD-3609202272.A0
3609202272
|
-
|
|
|
