1 - MOTOR HOUSING
BSD-3605108073.A1
3605108073
|
£37.27
|
£44.72
|
|
|
2 - STATOR 320-400W
BSD-3604090044.A27
3604090044
|
£81.81
|
£98.17
|
|
|
3 - ROTOR
BSD-3604220060.A12
3604220060
|
£63.50
|
£76.20
|
|
|
5 - BEARING FLANGE
BSD-3605700076.A52
3605700076
|
£48.38
|
£58.06
|
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A343
3600905039
|
£12.04
|
£14.45
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A17
1900905028
|
£33.74
|
£40.49
|
|
|
26 - CYLINDRICAL GEAR Z=15
BSD-3606316063.A14
3606316063
|
£37.27
|
£44.72
|
|
|
28 - RING GEAR Z=42
BSD-3606334055.A14
3606334055
|
£21.52
|
£25.83
|
|
|
31 - CYLINDRICAL GEAR Z=15
BSD-3606316059.A6
3606316059
|
-
|
|
|
|
32 - NEEDLE-ROLLER CAGE
BSD-3600913006.A71
3600913006
|
£7.36
|
£8.83
|
|
|
33 - NEEDLE ROLLER
BSD-3603201047.A56
3603201047
|
£1.75
|
£2.10
|
|
|
34 - SHIM 0.20 MM
BSD-2600100586.A4
2600100586
|
£1.75
|
£2.10
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337138.A1
3606337138
|
£72.18
|
£86.62
|
|
|
41 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A6
1900905234
|
£31.64
|
£37.97
|
|
|
42 - NON-WOVEN FABRIC
BSD-3601010028.A12
3601010028
|
-
|
|
|
|
43 - STOP DISC
BSD-3600102021.A3
3600102021
|
£3.72
|
£4.47
|
|
|
44 - O-RING 26.0x1.5 MM
BSD-2600210018.A2
2600210018
|
£3.72
|
£4.47
|
|
|
45 - GEAR HOUSING
BSD-3605125043.A5
3605125043
|
£54.42
|
£65.30
|
|
|
46 - SLOTTED SPRING PIN DIN 1481-1.5x4
BSD-2917760012.A18
2917760012
|
£1.75
|
£2.10
|
|
|
47 - SPIGOT
BSD-3600700033.A29
3600700033
|
£27.23
|
£32.68
|
|
|
48 - RETAINING WASHER
BSD-3600101036.A59
3600101036
|
£4.26
|
£5.11
|
|
|
49 - SILENCER
BSD-3601010010.A126
3601010010
|
£2.16
|
£2.59
|
|
|
51 - UNION NUT
BSD-3603313001.A14
3603313001
|
£14.91
|
£17.89
|
|
|
52 - SPRING RETAINING RING
BSD-3600118008.A2
3600118008
|
£1.75
|
£2.10
|
|
|
56 - FITTING
BSD-3603462007.A9
3603462007
|
£7.36
|
£8.83
|
|
|
57 - SEALING DISK
BSD-3600206005.A53
3600206005
|
£5.30
|
£6.36
|
|
|
60 - STRAINER
BSD-3600002006.A7
3600002006
|
£3.72
|
£4.47
|
|
|
61 - SILENCER
BSD-3603462000.A50
3603462000
|
£16.41
|
£19.69
|
|
|
62 - STRAINER
BSD-3600002005.A41
3600002005
|
£2.80
|
£3.36
|
|
|
65 - O-RING 15x2 MM
BSD-1900210112.A33
1900210112
|
£2.61
|
£3.13
|
|
|
67 - STRAIGHT PIN
BSD-3603201048.A5
3603201048
|
£10.10
|
£12.12
|
|
|
69 - STRAIGHT PIN
BSD-3604710057.A4
3604710057
|
£10.10
|
£12.12
|
|
|
74 - O-RING 23.0x2.0 MM
BSD-3600210032.A29
3600210032
|
£4.75
|
£5.70
|
|
|
75 - O-RING 18x2 MM
BSD-1900210315.A6
1900210315
|
£2.80
|
£3.36
|
|
|
76 - PUSH-BUTTON
BSD-1600A00HZ4.A2
1600A00HZ4
|
£3.72
|
£4.47
|
|
|
77 - PUSH-BUTTON
BSD-1600A00HZ5.A31
1600A00HZ5
|
£3.72
|
£4.47
|
|
|
78 - O-RING 13.0x2.0 MM
BSD-3600210034.A3
3600210034
|
£3.72
|
£4.47
|
|
|
79 - PILOT-VALVE BUSHING
BSD-3600313007.A11
3600313007
|
£45.67
|
£54.80
|
|
|
80 - SEALING PLATE
BSD-3600054004.A18
3600054004
|
£6.52
|
£7.83
|
|
|
81 - CONTROL PISTON
BSD-3608750024.A0
3608750024
|
£4.26
|
£5.11
|
|
|
82 - INTERMEDIATE PIECE
BSD-3600390019.A12
3600390019
|
£10.10
|
£12.12
|
|
|
83 - COMPRESSION SPRING
BSD-3604643013.A3
3604643013
|
£2.16
|
£2.59
|
|
|
84 - CONNECTION COVER
BSD-3605500046.A5
3605500046
|
£4.26
|
£5.11
|
|
|
85 - COMPRESSION SPRING
BSD-3604610027.A12
3604610027
|
£2.61
|
£3.13
|
|
|
88 - VALVE CONE
BSD-3600250002.A9
3600250002
|
£8.67
|
£10.41
|
|
|
89 - HOLDING PIN
BSD-3603105003.A1
3603105003
|
£8.67
|
£10.41
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A159
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110038.A28
3601110038
|
£5.30
|
£6.36
|
|
|
98 - SCREENING RING
BSD-3600521002.A8
3600521002
|
£2.80
|
£3.36
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1320
3601119236
|
£3.72
|
£4.47
|
|
|
100 - CONTROL HOUSING
BSD-3605125042.A1
3605125042
|
£81.81
|
£98.17
|
|
|
101 - ROTOR
BSD-3604220068.A3
3604220068
|
£156.22
|
£187.46
|
|
|
102 - ROTOR LAMELLA
BSD-3601165018.A3
3601165018
|
£72.18
|
£86.62
|
|
|
103 - CARRIER
BSD-3606445036.A1
3606445036
|
£156.22
|
£187.46
|
|
|
105 - THROTTLE SCREW
BSD-3603412002.A1
3603412002
|
£14.91
|
£17.89
|
|
|
106 - DRIVE SHAFT
BSD-3606455034.A0
3606455034
|
£93.88
|
£112.65
|
|
|
107 - SPRING RETAINING RING DIN 472-25x1.2MM
BSD-2916660009.A164
2916660009
|
£2.16
|
£2.59
|
|
|
109 - COMPRESSION SPRING
BSD-3604643015.A7
3604643015
|
£4.26
|
£5.11
|
|
|
110 - O-RING 2.5x1.0 MM
BSD-3600210045.A7
3600210045
|
£2.16
|
£2.59
|
|
|
111 - O-RING 34.0x2.5 MM
BSD-3600210046.A0
3600210046
|
£8.67
|
£10.41
|
|
|
112 - O-RING 10x2 MM
BSD-1280210725.A5
1280210725
|
£3.72
|
£4.47
|
|
|
113 - O-RING 21.0x1.5 MM
BSD-3600210060.A7
3600210060
|
£2.16
|
£2.59
|
|
|
114 - O-RING 4.0x1.5 MM
BSD-3600210064.A0
3600210064
|
£2.61
|
£3.13
|
|
|
115 - SCREW PLUG
BSD-3603414012.A6
3603414012
|
£5.30
|
£6.36
|
|
|
116 - COMPRESSION SPRING
BSD-3604610029.A3
3604610029
|
£2.16
|
£2.59
|
|
|
118 - WORKING CYLINDER 400W
BSD-3604090047.A3
3604090047
|
£306.65
|
£367.98
|
|
|
119 - POWER PISTON
BSD-3600313009.A6
3600313009
|
£21.68
|
£26.01
|
|
|
123 - BUSHING
BSD-3600322004.A6
3600322004
|
£21.68
|
£26.01
|
|
|
124 - RETAINING RING
BSD-3600118007.A2
3600118007
|
£2.16
|
£2.59
|
|
|
125 - STOP DISC
BSD-3600114011.A7
3600114011
|
£18.96
|
£22.75
|
|
|
127 - RETAINING RING
BSD-3600224001.A33
3600224001
|
£3.72
|
£4.47
|
|
|
129 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A286
1903230007
|
£1.75
|
£2.10
|
|
|
130 - STOP DISC
BSD-3600101042.A2
3600101042
|
£13.12
|
£15.75
|
|
|
131 - COMPRESSION SPRING
BSD-3604615001.A41
3604615001
|
£2.61
|
£3.13
|
|
|
132 - CLAMPING SLEEVE
BSD-3600311015.A0
3600311015
|
£31.64
|
£37.97
|
|
|
134 - PLAIN WASHER
BSD-3600101055.A55
3600101055
|
£12.04
|
£14.45
|
|
|
652 - HOSE FITTING
BSD-2603386002.A197
2603386002
|
£5.30
|
£6.36
|
|
|
655 - SCREWDRIVER
BSD-1907959023.A1
1907959023
|
£4.75
|
£5.70
|
|
|
703 - SUSPENSION LOOP
BSD-3601923002.A2
3601923002
|
-
|
|
|
|
800 - ASSEMBLY OF SERVICE PARTS
BSD-3607030119.A6
3607030119
|
£102.57
|
£123.08
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607030113.A1
3607030113
|
£283.50
|
£340.20
|
|
|
804 - ROTOR LAMELLA
BSD-3607030030.A19
3607030030
|
£31.64
|
£37.97
|
|
|
807 - ASSEMBLY OF SERVICE PARTS
BSD-3607030117.A1
3607030117
|
-
|
|
|
|
861 - ASSEMBLY OF SERVICE PARTS
BSD-3607030112.A2
3607030112
|
-
|
|
|
|
868 - VALVE CONE
BSD-3608750042.A8
3608750042
|
£6.52
|
£7.83
|
|
|
882 - ASSEMBLY OF SERVICE PARTS
BSD-3607030114.A2
3607030114
|
-
|
|
|
|
899 - OIL 1000 ML
BSD-3605430008.A2
3605430008
|
£27.23
|
£32.68
|
|
