1 - MOTOR HOUSING
BSD-3605108073.A3
3605108073
|
£37.27
|
£44.72
|
|
|
2 - STATOR 320-400W
BSD-3604090044.A22
3604090044
|
£81.81
|
£98.17
|
|
|
3 - ROTOR
BSD-3604220060.A10
3604220060
|
£63.50
|
£76.20
|
|
|
5 - BEARING FLANGE
BSD-3605700076.A49
3605700076
|
£48.38
|
£58.06
|
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A341
3600905039
|
£12.04
|
£14.45
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A14
1900905028
|
£33.74
|
£40.49
|
|
|
26 - CYLINDRICAL GEAR Z=15
BSD-3606316063.A19
3606316063
|
£37.27
|
£44.72
|
|
|
28 - RING GEAR Z=42
BSD-3606334055.A9
3606334055
|
£21.52
|
£25.83
|
|
|
31 - CYLINDRICAL GEAR Z=15
BSD-3606316059.A1
3606316059
|
-
|
|
|
|
32 - NEEDLE-ROLLER CAGE
BSD-3600913006.A65
3600913006
|
£7.36
|
£8.83
|
|
|
33 - NEEDLE ROLLER
BSD-3603201047.A57
3603201047
|
£1.75
|
£2.10
|
|
|
34 - SHIM 0.20 MM
BSD-2600100586.A8
2600100586
|
£1.75
|
£2.10
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337138.A6
3606337138
|
£72.18
|
£86.62
|
|
|
41 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A1
1900905234
|
£31.64
|
£37.97
|
|
|
42 - NON-WOVEN FABRIC
BSD-3601010028.A11
3601010028
|
-
|
|
|
|
43 - STOP DISC
BSD-3600102021.A8
3600102021
|
£3.72
|
£4.47
|
|
|
44 - O-RING 26.0x1.5 MM
BSD-2600210018.A7
2600210018
|
£3.72
|
£4.47
|
|
|
45 - GEAR HOUSING
BSD-3605125043.A6
3605125043
|
£54.42
|
£65.30
|
|
|
46 - SLOTTED SPRING PIN DIN 1481-1.5x4
BSD-2917760012.A21
2917760012
|
£1.75
|
£2.10
|
|
|
47 - SPIGOT
BSD-3600700033.A30
3600700033
|
£27.23
|
£32.68
|
|
|
48 - RETAINING WASHER
BSD-3600101036.A54
3600101036
|
£4.26
|
£5.11
|
|
|
49 - SILENCER
BSD-3601010010.A128
3601010010
|
£2.16
|
£2.59
|
|
|
51 - UNION NUT
BSD-3603313001.A8
3603313001
|
£14.91
|
£17.89
|
|
|
52 - SPRING RETAINING RING
BSD-3600118008.A7
3600118008
|
£1.75
|
£2.10
|
|
|
56 - FITTING
BSD-3603462007.A5
3603462007
|
£7.36
|
£8.83
|
|
|
57 - SEALING DISK
BSD-3600206005.A60
3600206005
|
£5.30
|
£6.36
|
|
|
60 - STRAINER
BSD-3600002006.A2
3600002006
|
£3.72
|
£4.47
|
|
|
61 - SILENCER
BSD-3603462000.A54
3603462000
|
£16.41
|
£19.69
|
|
|
62 - STRAINER
BSD-3600002005.A42
3600002005
|
£2.80
|
£3.36
|
|
|
65 - O-RING 15x2 MM
BSD-1900210112.A39
1900210112
|
£2.61
|
£3.13
|
|
|
67 - STRAIGHT PIN
BSD-3603201048.A4
3603201048
|
£10.10
|
£12.12
|
|
|
69 - STRAIGHT PIN
BSD-3604710057.A3
3604710057
|
£10.10
|
£12.12
|
|
|
74 - O-RING 23.0x2.0 MM
BSD-3600210032.A28
3600210032
|
£4.75
|
£5.70
|
|
|
75 - O-RING 18x2 MM
BSD-1900210315.A5
1900210315
|
£2.80
|
£3.36
|
|
|
76 - PUSH-BUTTON
BSD-1600A00HZ4.A1
1600A00HZ4
|
£3.72
|
£4.47
|
|
|
77 - PUSH-BUTTON
BSD-1600A00HZ5.A32
1600A00HZ5
|
£3.72
|
£4.47
|
|
|
78 - O-RING 13.0x2.0 MM
BSD-3600210034.A4
3600210034
|
£3.72
|
£4.47
|
|
|
79 - PILOT-VALVE BUSHING
BSD-3600313007.A9
3600313007
|
£45.67
|
£54.80
|
|
|
80 - SEALING PLATE
BSD-3600054004.A23
3600054004
|
£6.52
|
£7.83
|
|
|
81 - CONTROL PISTON
BSD-3608750024.A2
3608750024
|
£4.26
|
£5.11
|
|
|
82 - INTERMEDIATE PIECE
BSD-3600390019.A13
3600390019
|
£10.10
|
£12.12
|
|
|
83 - COMPRESSION SPRING
BSD-3604643013.A4
3604643013
|
£2.16
|
£2.59
|
|
|
84 - CONNECTION COVER
BSD-3605500046.A4
3605500046
|
£4.26
|
£5.11
|
|
|
85 - COMPRESSION SPRING
BSD-3604610027.A11
3604610027
|
£2.61
|
£3.13
|
|
|
88 - VALVE CONE
BSD-3600250002.A10
3600250002
|
£8.67
|
£10.41
|
|
|
89 - HOLDING PIN
BSD-3603105003.A2
3603105003
|
£8.67
|
£10.41
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A158
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110038.A29
3601110038
|
£5.30
|
£6.36
|
|
|
98 - SCREENING RING
BSD-3600521002.A7
3600521002
|
£2.80
|
£3.36
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1319
3601119236
|
£3.72
|
£4.47
|
|
|
100 - CONTROL HOUSING
BSD-3605125042.A2
3605125042
|
£81.81
|
£98.17
|
|
|
101 - ROTOR
BSD-3604220083.A0
3604220083
|
£179.37
|
£215.24
|
|
|
102 - ROTOR LAMELLA
BSD-3601165020.A0
3601165020
|
£93.88
|
£112.65
|
|
|
103 - CARRIER
BSD-3606445036.A2
3606445036
|
£156.22
|
£187.46
|
|
|
105 - THROTTLE SCREW
BSD-3603412002.A2
3603412002
|
£14.91
|
£17.89
|
|
|
106 - OUTPUT SHAFT
BSD-3606455032.A3
3606455032
|
£68.42
|
£82.10
|
|
|
107 - SPRING RETAINING RING DIN 472-25x1.2MM
BSD-2916660009.A163
2916660009
|
£2.16
|
£2.59
|
|
|
109 - COMPRESSION SPRING
BSD-3604643015.A6
3604643015
|
£4.26
|
£5.11
|
|
|
110 - O-RING 2.5x1.0 MM
BSD-3600210045.A6
3600210045
|
£2.16
|
£2.59
|
|
|
111 - O-RING 34.0x2.5 MM
BSD-3600210046.A1
3600210046
|
£8.67
|
£10.41
|
|
|
112 - O-RING 10x2 MM
BSD-1280210725.A6
1280210725
|
£3.72
|
£4.47
|
|
|
113 - O-RING 21.0x1.5 MM
BSD-3600210060.A6
3600210060
|
£2.16
|
£2.59
|
|
|
114 - O-RING 4.0x1.5 MM
BSD-3600210064.A1
3600210064
|
£2.61
|
£3.13
|
|
|
115 - SCREW PLUG
BSD-3603414012.A5
3603414012
|
£5.30
|
£6.36
|
|
|
116 - COMPRESSION SPRING
BSD-3604610033.A0
3604610033
|
£1.95
|
£2.34
|
|
|
118 - WORKING CYLINDER
BSD-3604090051.A0
3604090051
|
£263.33
|
£316.00
|
|
|
119 - POWER PISTON
BSD-3600313009.A5
3600313009
|
£21.68
|
£26.01
|
|
|
120 - GUIDE SLEEVE
BSD-3600320016.A20
3600320016
|
£14.91
|
£17.89
|
|
|
121 - COMPRESSION SPRING
BSD-1604611004.A32
1604611004
|
£2.80
|
£3.36
|
|
|
122 - PRESSURE SPINDLE
BSD-1603124060.A58
1603124060
|
£5.58
|
£6.70
|
|
|
123 - BUSHING
BSD-3600322004.A5
3600322004
|
£21.68
|
£26.01
|
|
|
124 - RETAINING RING
BSD-3600118007.A3
3600118007
|
£2.16
|
£2.59
|
|
|
125 - STOP DISC
BSD-3600114011.A6
3600114011
|
£18.96
|
£22.75
|
|
|
652 - HOSE FITTING
BSD-2603386002.A198
2603386002
|
£5.30
|
£6.36
|
|
|
655 - SCREWDRIVER
BSD-1907959023.A2
1907959023
|
£4.75
|
£5.70
|
|
|
703 - SUSPENSION LOOP
BSD-3604923002.A0
3604923002
|
-
|
|
|
|
800 - ASSEMBLY OF SERVICE PARTS
BSD-3607030119.A5
3607030119
|
£102.57
|
£123.08
|
|
|
801 - IMPACT MECHANISM
BSD-3607030205.A1
3607030205
|
-
|
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607030113.A2
3607030113
|
£283.50
|
£340.20
|
|
|
804 - ROTOR LAMELLA
BSD-3607030030.A20
3607030030
|
£31.64
|
£37.97
|
|
|
807 - ASSEMBLY OF SERVICE PARTS
BSD-3607030117.A2
3607030117
|
-
|
|
|
|
861 - ASSEMBLY OF SERVICE PARTS
BSD-3607030112.A1
3607030112
|
-
|
|
|
|
868 - VALVE CONE
BSD-3608750042.A7
3608750042
|
£6.52
|
£7.83
|
|
|
882 - ASSEMBLY OF SERVICE PARTS
BSD-3607030114.A1
3607030114
|
-
|
|
|
|
899 - OIL 1000 ML
BSD-3605430008.A3
3605430008
|
£27.23
|
£32.68
|
|
