1 - GEAR HOUSING
BSD-3605106029.A1
3605106029
|
-
|
|
|
|
2 - GEAR HOUSING
BSD-3605106030.A0
3605106030
|
-
|
|
|
|
3 - SPLINED SHAFT
BSD-3603161026.A0
3603161026
|
-
|
|
|
|
3 - SPLINED SHAFT
BSD-3603161027.A1
3603161027
|
-
|
|
|
|
4 - HOLLOW SHAFT
BSD-3600700020.A0
3600700020
|
-
|
|
|
|
5 - TOOTHED GEAR
BSD-3606316050.A0
3606316050
|
-
|
|
|
|
6 - TOOTHED SHAFT
BSD-3606309012.A1
3606309012
|
£283.50
|
£340.20
|
|
|
7 - AXLE
BSD-3603000000.A3
3603000000
|
-
|
|
|
|
8 - CYLINDER COVER
BSD-3600365002.A1
3600365002
|
-
|
|
|
|
15 - SHIM
BSD-2600101601.A17
2600101601
|
£1.75
|
£2.10
|
|
|
16 - FRICTION WASHER
BSD-3600000002.A0
3600000002
|
-
|
|
|
|
17 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A619
1903230007
|
£1.75
|
£2.10
|
|
|
19 - RADIAL SEAL 25x32x4 MM
BSD-3600283024.A1
3600283024
|
-
|
|
|
|
20 - NEEDLE BEARING
BSD-1600910017.A9
1600910017
|
-
|
|
|
|
24 - NEEDLE BEARING
BSD-3600917019.A1
3600917019
|
£11.30
|
£13.56
|
|
|
25 - RADIAL SEAL
BSD-3600283022.A1
3600283022
|
-
|
|
|
|
26 - D-GROOVE BALL THR BEARING
BSD-3600929007.A0
3600929007
|
-
|
|
|
|
32 - STRAIGHT PIN 4 H 8x16 DIN 7
BSD-2917500097.A11
2917500097
|
-
|
|
|
|
34 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x45-8.8
BSD-2910141172.A59
2910141172
|
£1.75
|
£2.10
|
|
|
35 - BUSHING
BSD-3600362008.A0
3600362008
|
-
|
|
|
|
36 - RADIAL SEAL
BSD-3600283023.A0
3600283023
|
-
|
|
|
|
37 - SEAL RING
BSD-3600290013.A0
3600290013
|
-
|
|
|
|
38 - BACKUP RING
BSD-3600290014.A1
3600290014
|
-
|
|
|
|
39 - SUPPORTING DISC
BSD-3600101027.A0
3600101027
|
-
|
|
|
|
40 - SUPPORTING DISC 28 X 40 X 0.2
BSD-3600102017.A0
3600102017
|
-
|
|
|
|
42 - PISTON RING
BSD-3600203001.A1
3600203001
|
-
|
|
|
|
55 - STOP DISC
BSD-3600109003.A0
3600109003
|
-
|
|
|
|
56 - SUPPORTING DISC
BSD-3600190005.A1
3600190005
|
-
|
|
|
|
57 - HEX SOCKET HEAD CAP SCREW DIN 912-M4x8-10.9
BSD-2910151118.A1
2910151118
|
-
|
|
|
|
58 - PRESSURE SCREW
BSD-3603490005.A0
3603490005
|
£48.38
|
£58.06
|
|
|
59 - POWER PISTON
BSD-3600320007.A1
3600320007
|
-
|
|
|
|
60 - THRUST RING
BSD-3600220017.A1
3600220017
|
-
|
|
|
|
61 - HEX NUT M 6 DIN 985-8
BSD-2915060004.A8
2915060004
|
-
|
|
|
|
62 - ROLLER THRUST BEARING
BSD-3600920002.A0
3600920002
|
-
|
|
|
|
63 - GROOVED RING
BSD-3600283021.A0
3600283021
|
-
|
|
|
|
64 - MAGNET
BSD-1824542027.A0
1824542027
|
-
|
|
|
|
65 - STOP DISC
BSD-1820109034.A0
1820109034
|
-
|
|
|
|
66 - PLAIN WASHER DIN 433-6.4-ST 50
BSD-2916011013.A10
2916011013
|
£1.75
|
£2.10
|
|
|
67 - POWER PISTON
BSD-3600320008.A0
3600320008
|
-
|
|
|
|
68 - CYLINDER TUBE
BSD-3600700021.A0
3600700021
|
-
|
|
|
|
69 - STOP DISC
BSD-3600109002.A1
3600109002
|
£12.04
|
£14.45
|
|
|
70 - CYLINDER COVER
BSD-3600362007.A1
3600362007
|
-
|
|
|
|
71 - ON-OFF SWITCH
BSD-3607031166.A1
3607031166
|
-
|
|
|
|
73 - PROTECTIVE CAP M 10x1MM
BSD-1900508004.A1
1900508004
|
-
|
|
|
