26 - PINION
BSD-3606300063.A2
3606300063
|
-
|
|
|
|
27 - STOP DISC
BSD-3600101004.A25
3600101004
|
£2.61
|
£3.13
|
|
|
28 - RING GEAR Z=46/35
BSD-3606334013.A7
3606334013
|
£410.78
|
£492.94
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337107.A2
3606337107
|
£218.41
|
£262.09
|
|
|
30 - CYLINDRICAL GEAR Z=20
BSD-3606316051.A0
3606316051
|
£33.74
|
£40.49
|
|
|
31 - NEEDLE-ROLLER ASSEMBLY
BSD-3600910000.A82
3600910000
|
£4.26
|
£5.11
|
|
|
32 - NEEDLE ROLLER
BSD-3603201005.A67
3603201005
|
£2.80
|
£3.36
|
|
|
34 - NEEDLE ROLLER
BSD-3603201031.A45
3603201031
|
£2.61
|
£3.13
|
|
|
35 - GROOVE BALL BEARING 25x37x7
BSD-3600905001.A69
3600905001
|
£31.64
|
£37.97
|
|
|
36 - PLANETARY-GEAR CARRIER
BSD-3606337100.A0
3606337100
|
£195.26
|
£234.31
|
|
|
37 - CYLINDRICAL GEAR
BSD-3606316105.A8
3606316105
|
£37.27
|
£44.72
|
|
|
38 - SPACER RING
BSD-3600101012.A0
3600101012
|
£18.96
|
£22.75
|
|
|
39 - GROOVE BALL BEARING 6303-2RS1
BSD-3608870382.A26
3608870382
|
£31.64
|
£37.97
|
|
|
40 - THREADED RING
BSD-3603344060.A11
3603344060
|
£23.86
|
£28.63
|
|
|
41 - RADIAL SEAL
BSD-3600283010.A0
3600283010
|
£18.96
|
£22.75
|
|
|
42 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A73
2916650008
|
£1.75
|
£2.10
|
|
|
43 - O-RING 45x2.5 MM
BSD-1900210345.A5
1900210345
|
-
|
|
|
|
44 - CYLINDRICAL GEAR
BSD-3606316109.A3
3606316109
|
£21.68
|
£26.01
|
|
|
45 - PLANETARY-GEAR CARRIER
BSD-3606337045.A14
3606337045
|
£195.26
|
£234.31
|
|
|
47 - THRUST BEARING DISC
BSD-1610101608.A7
1610101608
|
£2.16
|
£2.59
|
|
|
48 - STOP DISC
BSD-3600100006.A7
3600100006
|
£5.58
|
£6.70
|
|
|
49 - NEEDLE ROLLER
BSD-3603201030.A2
3603201030
|
£2.80
|
£3.36
|
|
|
50 - GROOVE BALL BEARING
BSD-3600905103.A7
3600905103
|
£23.86
|
£28.63
|
|
|
60 - O-RING 15.0x1.0 MM
BSD-3600210054.A0
3600210054
|
£4.26
|
£5.11
|
|
|
95 - NAMEPLATE
BSD-3601106045.A0
3601106045
|
-
|
|
|
|
650 - PROTECTIVE CAP
BSD-3600508003.A8
3600508003
|
£2.61
|
£3.13
|
|
