1 - MOTOR HOUSING
BSD-3600760021.A4
3600760021
|
£81.81
|
£98.17
|
|
|
2 - STATOR 120W
BSD-3604090027.A3
3604090027
|
£102.57
|
£123.08
|
|
|
3 - ROTOR
BSD-3604220022.A2
3604220022
|
£195.26
|
£234.31
|
|
|
7 - BEARING FLANGE
BSD-3605700199.A4
3605700199
|
£40.80
|
£48.96
|
|
|
8 - GROOVE BALL BEARING 7x14x5
BSD-1900905030.A35
1900905030
|
£33.74
|
£40.49
|
|
|
9 - SHIM
BSD-3600150001.A5
3600150001
|
£2.16
|
£2.59
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A200
2916011012
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A20
2911061150
|
£2.61
|
£3.13
|
|
|
41 - BALL BEARING 7x19x6
BSD-2600905032.A1670
2600905032
|
£5.30
|
£6.36
|
|
|
43 - THREADED RING
BSD-3603344008.A5
3603344008
|
£14.91
|
£17.89
|
|
|
44 - COLLET JAWS
BSD-3608570000.A4
3608570000
|
£72.18
|
£86.62
|
|
|
46 - BUSHING
BSD-3600311008.A5
3600311008
|
£33.74
|
£40.49
|
|
|
52 - PLAIN WASHER DIN 125-A3.2-ST
BSD-2916011006.A166
2916011006
|
£1.75
|
£2.10
|
|
|
53 - O-RING 2.4x1.9 MM
BSD-2600210007.A19
2600210007
|
£2.16
|
£2.59
|
|
|
54 - COMPRESSION SPRING
BSD-3604611017.A112
3604611017
|
£2.61
|
£3.13
|
|
|
55 - VALVE CONE
BSD-3603132000.A11
3603132000
|
£2.80
|
£3.36
|
|
|
56 - VALVE HOUSING
BSD-3605190158.A2
3605190158
|
£195.26
|
£234.31
|
|
|
57 - HOUSING COVER
BSD-3605500006.A26
3605500006
|
£2.16
|
£2.59
|
|
|
59 - SILENCER
BSD-3607000074.A71
3607000074
|
£23.86
|
£28.63
|
|
|
60 - STRAINER
BSD-3600002001.A76
3600002001
|
£2.61
|
£3.13
|
|
|
61 - SET SCREW M 4x8 DIN 551-5.8
BSD-2912031118.A5
2912031118
|
£1.75
|
£2.10
|
|
|
62 - HEX NUT
BSD-3603458003.A5
3603458003
|
£4.26
|
£5.11
|
|
|
63 - NEEDLE ROLLER
BSD-3603201068.A3
3603201068
|
£2.80
|
£3.36
|
|
|
66 - STRAIGHT PIN
BSD-3603201026.A22
3603201026
|
£7.36
|
£8.83
|
|
|
68 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A499
1903230013
|
£2.16
|
£2.59
|
|
|
69 - COMPRESSION SPRING
BSD-3604611006.A137
3604611006
|
£2.16
|
£2.59
|
|
|
76 - THREADED RING
BSD-3603344003.A95
3603344003
|
£2.61
|
£3.13
|
|
|
77 - CONTROL LEVER
BSD-3601902001.A5
3601902001
|
£6.52
|
£7.83
|
|
|
78 - GROOVED PIN DIN 1475-2x18-ST
BSD-2917700040.A147
2917700040
|
£2.80
|
£3.36
|
|
|
82 - O-RING 20.0x1.0 MM
BSD-3600210012.A6
3600210012
|
£2.80
|
£3.36
|
|
|
86 - COUNTERSUNK-HEAD SCREW M3x10-A2-70 DIN963
BSD-2918000052.A8
2918000052
|
£1.75
|
£2.10
|
|
|
87 - SEALING PLATE
BSD-3600054000.A6
3600054000
|
£2.16
|
£2.59
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A385
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601119055.A91
3601119055
|
£3.72
|
£4.47
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A566
3603133000
|
£2.61
|
£3.13
|
|
|
98 - REFERENCE PLATE
BSD-3601119246.A1
3601119246
|
£3.72
|
£4.47
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A901
3601119236
|
£3.72
|
£4.47
|
|
|
100 - UNION NUT
BSD-3603340018.A11
3603340018
|
£23.86
|
£28.63
|
|
|
101 - COLLET dia 1/4
BSD-2608570072.A3
2608570072
|
£33.74
|
£40.49
|
|
|
652 - HOSE FITTING
BSD-3603386002.A101
3603386002
|
£3.34
|
£4.01
|
|
|
653 - SINGLE-HEAD ENG. WRENCH SW 14
BSD-1907950508.A47
1907950508
|
£14.91
|
£17.89
|
|
|
700 - SILENCER
BSD-3607000074.A72
3607000074
|
£23.86
|
£28.63
|
|
|
703 - SUSPENSION LOOP
BSD-2604720004.A3
2604720004
|
£4.26
|
£5.11
|
|
|
704 - HOSE FITTING
BSD-3607010011.A10
3607010011
|
-
|
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607031313.A4
3607031313
|
£21.52
|
£25.83
|
|
