1 - MOTOR HOUSING
BSD-3600760016.A8
3600760016
|
£102.57
|
£123.08
|
|
|
2 - STATOR 370W
BSD-3604090003.A18
3604090003
|
£93.88
|
£112.65
|
|
|
3 - ROTOR
BSD-3604220011.A2
3604220011
|
£179.37
|
£215.24
|
|
|
5 - BEARING FLANGE
BSD-3605700005.A162
3605700005
|
£54.42
|
£65.30
|
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A2
3600905039
|
£12.04
|
£14.45
|
|
|
7 - BEARING FLANGE
BSD-3605700007.A62
3605700007
|
£63.50
|
£76.20
|
|
|
8 - GROOVE BALL BEARING DIN 625-7x19x6
BSD-3600905148.A131
3600905148
|
£8.49
|
£10.19
|
|
|
9 - SPACER RING
BSD-2600202013.A152
2600202013
|
£8.67
|
£10.41
|
|
|
10 - SPACER RING
BSD-2600202014.A39
2600202014
|
£11.30
|
£13.56
|
|
|
15 - SPINDLE HOUSING
BSD-3600720000.A0
3600720000
|
£156.22
|
£187.46
|
|
|
26 - PINION
BSD-3606300158.A11
3606300158
|
£45.67
|
£54.80
|
|
|
28 - CLUTCH ELEMENT
BSD-3606334006.A1
3606334006
|
£5.30
|
£6.36
|
|
|
29 - SPACER SLEEVE
BSD-3600300070.A1
3600300070
|
£27.23
|
£32.68
|
|
|
30 - GRINDING SPINDLE
BSD-3603523000.A2
3603523000
|
£156.22
|
£187.46
|
|
|
31 - DISC SPRING
BSD-2600550018.A1
2600550018
|
£2.80
|
£3.36
|
|
|
32 - GROOVE BALL BEARING
BSD-3600900025.A31
3600900025
|
£8.67
|
£10.41
|
|
|
34 - SPACER BUSHING
BSD-3600400001.A0
3600400001
|
£11.30
|
£13.56
|
|
|
35 - ROUND NUT
BSD-3603342009.A127
3603342009
|
£14.91
|
£17.89
|
|
|
36 - COLLET dia 1/4 (6.35 MM)
BSD-2608570080.A2
2608570080
|
-
|
|
|
|
54 - SPACER BUSHING
BSD-3600328021.A8
3600328021
|
-
|
|
|
|
56 - VALVE BODY
BSD-3605190030.A0
3605190030
|
-
|
|
|
|
57 - SILENCER
BSD-3605190014.A0
3605190014
|
-
|
|
|
|
58 - FITTING
BSD-3603458001.A32
3603458001
|
-
|
|
|
|
59 - SINTERED-METAL BUSHING
BSD-3600521000.A21
3600521000
|
-
|
|
|
|
60 - STRAINER
BSD-3600002000.A146
3600002000
|
£3.72
|
£4.47
|
|
|
61 - PLAIN WASHER
BSD-3600101003.A21
3600101003
|
-
|
|
|
|
63 - PRESSURE SPINDLE
BSD-3603123000.A12
3603123000
|
-
|
|
|
|
65 - STRAIGHT PIN 3 H 8x6 DIN 7
BSD-2917500074.A32
2917500074
|
-
|
|
|
|
66 - STRAIGHT PIN
BSD-3604710001.A9
3604710001
|
-
|
|
|
|
68 - BALL III DIN 5401 ST
BSD-1903230529.A0
1903230529
|
-
|
|
|
|
69 - COMPRESSION SPRING
BSD-3604643002.A1
3604643002
|
£2.80
|
£3.36
|
|
|
76 - O-RING 1.8x1.0 MM
BSD-3600210002.A54
3600210002
|
£2.61
|
£3.13
|
|
|
77 - CONTROL LEVER
BSD-3601902000.A11
3601902000
|
-
|
|
|
|
78 - STRAIGHT PIN 3 H 8x20 DIN 7
BSD-2917500081.A4
2917500081
|
-
|
|
|
|
79 - COMPRESSION SPRING
BSD-3604610001.A12
3604610001
|
-
|
|
|
|
80 - CONTROL HOUSING
BSD-3600328001.A6
3600328001
|
-
|
|
|
|
81 - FLYWEIGHT CARRIER
BSD-3602125000.A4
3602125000
|
£27.23
|
£32.68
|
|
|
82 - FLYWEIGHT
BSD-3602190004.A29
3602190004
|
£2.16
|
£2.59
|
|
|
83 - NEEDLE ROLLER A 2x11.8G2DIN5402
BSD-1903201002.A31
1903201002
|
£1.75
|
£2.10
|
|
|
84 - CONTROL SLEEVE
BSD-3600322000.A33
3600322000
|
-
|
|
|
|
85 - COMPRESSION SPRING
BSD-3604613000.A3
3604613000
|
£2.80
|
£3.36
|
|
|
86 - SHIM 0.3 MM
BSD-2600100570.A194
2600100570
|
£1.75
|
£2.10
|
|
|
88 - THREADED BUSHING
BSD-3600361000.A4
3600361000
|
£2.80
|
£3.36
|
|
|
89 - INTERMEDIATE PIECE
BSD-3600516000.A0
3600516000
|
-
|
|
|
|
90 - SILENCER
BSD-3603462000.A187
3603462000
|
£16.41
|
£19.69
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A389
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601119055.A77
3601119055
|
£3.72
|
£4.47
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A571
3603133000
|
£2.61
|
£3.13
|
|
|
98 - REFERENCE PLATE
BSD-3601119237.A3
3601119237
|
£3.72
|
£4.47
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A921
3601119236
|
£3.72
|
£4.47
|
|
|
652 - HOSE FITTING
BSD-2603386002.A46
2603386002
|
£5.30
|
£6.36
|
|
|
653 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A367
2607950511
|
£4.26
|
£5.11
|
|
|
700 - COLLET dia 3 MM
BSD-2608570077.A1
2608570077
|
£21.68
|
£26.01
|
|
|
701 - COLLET dia 1/8 (3.175 MM)
BSD-2608570078.A40
2608570078
|
£33.74
|
£40.49
|
|
|
702 - COLLET dia 1/4 (6.35 MM)
BSD-2608570080.A1
2608570080
|
-
|
|
|
|
703 - COLLET dia 8 MM
BSD-2608570081.A59
2608570081
|
£21.68
|
£26.01
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031035.A2
3607031035
|
£357.27
|
£428.72
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030249.A8
3607030249
|
£33.73
|
£40.48
|
|
|
855 - O-RING 10x2 MM
BSD-1900210306.A71
1900210306
|
£1.75
|
£2.10
|
|
|
881 - ASSEMBLY OF SERVICE PARTS
BSD-3607031036.A0
3607031036
|
£59.53
|
£71.44
|
|
