1 - MOTOR HOUSING
BSD-3605108070.A9
3605108070
|
£33.74
|
£40.49
|
|
|
2 - STATOR 400W
BSD-3604090046.A17
3604090046
|
£102.57
|
£123.08
|
|
|
3 - ROTOR
BSD-3604220076.A0
3604220076
|
£156.22
|
£187.46
|
|
|
5 - BEARING FLANGE
BSD-3605700084.A2
3605700084
|
£45.67
|
£54.80
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A2
1900905028
|
£33.74
|
£40.49
|
|
|
15 - SPINDLE HOUSING
BSD-3605108068.A2
3605108068
|
£11.30
|
£13.56
|
|
|
35 - ROUND NUT
BSD-3603342009.A0
3603342009
|
£14.91
|
£17.89
|
|
|
36 - COLLET dia 1/4 (6.35 MM)
BSD-2608570080.A32
2608570080
|
-
|
|
|
|
40 - RUBBER RING
BSD-1600206025.A714
1600206025
|
£2.16
|
£2.59
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905043.A4
3600905043
|
£33.74
|
£40.49
|
|
|
42 - O-RING 33.0x2.0 MM
BSD-2600210019.A28
2600210019
|
£1.75
|
£2.10
|
|
|
43 - COLLET JAWS
BSD-3608570003.A7
3608570003
|
£120.11
|
£144.13
|
|
|
44 - O-RING 26.0x1.5 MM
BSD-2600210018.A15
2600210018
|
£3.72
|
£4.47
|
|
|
45 - O-RING 18.77x1.78 MM
BSD-3600210082.A2
3600210082
|
£2.16
|
£2.59
|
|
|
47 - SPIGOT
BSD-3600700032.A7
3600700032
|
£21.68
|
£26.01
|
|
|
49 - SILENCER
BSD-3601010006.A75
3601010006
|
£1.75
|
£2.10
|
|
|
51 - UNION NUT
BSD-3603313001.A16
3603313001
|
£14.91
|
£17.89
|
|
|
53 - NEEDLE ROLLER
BSD-3603201050.A31
3603201050
|
£1.75
|
£2.10
|
|
|
54 - COMPRESSION SPRING
BSD-3604611006.A22
3604611006
|
£2.16
|
£2.59
|
|
|
55 - VALVE CONE
BSD-3603132000.A69
3603132000
|
£2.80
|
£3.36
|
|
|
56 - FITTING
BSD-3603458008.A30
3603458008
|
£8.67
|
£10.41
|
|
|
57 - SEALING DISK
BSD-3600206006.A17
3600206006
|
-
|
|
|
|
60 - STRAINER
BSD-3600002000.A254
3600002000
|
£3.72
|
£4.47
|
|
|
61 - O-RING 10x2 MM
BSD-1900210306.A197
1900210306
|
£1.75
|
£2.10
|
|
|
64 - PLAIN WASHER DIN 125-A3.2-ST
BSD-2916011006.A17
2916011006
|
£1.75
|
£2.10
|
|
|
65 - O-RING 2.4x1.9 MM
BSD-2600210007.A74
2600210007
|
£2.16
|
£2.59
|
|
|
66 - O-RING 16x1.25 MM
BSD-3600210036.A64
3600210036
|
£2.16
|
£2.59
|
|
|
68 - BALL DIN 5401-9.5MM-III-ST
BSD-1903230528.A5
1903230528
|
£1.75
|
£2.10
|
|
|
69 - COMPRESSION SPRING
BSD-3604616008.A12
3604616008
|
-
|
|
|
|
70 - SILENCER
BSD-3600105002.A17
3600105002
|
£10.10
|
£12.12
|
|
|
71 - VALVE PISTON
BSD-3608750028.A18
3608750028
|
£5.58
|
£6.70
|
|
|
72 - O-RING
BSD-1900210307.A7
1900210307
|
£4.26
|
£5.11
|
|
|
73 - CENTRIFUGAL GOVERNOR
BSD-3607021013.A1
3607021013
|
£31.64
|
£37.97
|
|
|
77 - CONTROL LEVER
BSD-3601902003.A6
3601902003
|
£72.18
|
£86.62
|
|
|
78 - GROOVED PIN DIN 1475-2x18-ST
BSD-2917700040.A41
2917700040
|
£2.80
|
£3.36
|
|
|
80 - SEALING PLATE
BSD-3600054004.A26
3600054004
|
£6.52
|
£7.83
|
|
|
82 - INTERMEDIATE PIECE
BSD-3608750027.A2
3608750027
|
£14.91
|
£17.89
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A0
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110039.A16
3601110039
|
£5.30
|
£6.36
|
|
|
98 - REFERENCE PLATE
BSD-3601119250.A1
3601119250
|
-
|
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1403
3601119236
|
£3.72
|
£4.47
|
|
|
652 - HOSE FITTING
BSD-2603386002.A225
2603386002
|
£5.30
|
£6.36
|
|
|
654 - SINGLE-HEAD ENG. WRENCH SW 14
BSD-1907950508.A158
1907950508
|
£14.91
|
£17.89
|
|
|
655 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A875
2607950511
|
£4.26
|
£5.11
|
|
|
660 - SUSPENSION LOOP
BSD-3604720004.A121
3604720004
|
£2.80
|
£3.36
|
|
|
802 - MOTOR
BSD-3607030183.A0
3607030183
|
£357.27
|
£428.72
|
|
|
804 - ROTOR LAMELLA
BSD-3607030049.A4
3607030049
|
£21.68
|
£26.01
|
|
|
815 - SPINDLE HOUSING
BSD-3607030052.A4
3607030052
|
£16.41
|
£19.69
|
|
|
856 - ASSEMBLY OF SERVICE PARTS
BSD-3607030033.A10
3607030033
|
£31.64
|
£37.97
|
|
|
859 - HOLDING BELT
BSD-3604710062.A69
3604710062
|
£1.75
|
£2.10
|
|
|
877 - CONTROL LEVER
BSD-3607030051.A0
3607030051
|
£45.67
|
£54.80
|
|
|
882 - ASSEMBLY OF SERVICE PARTS
BSD-3607030368.A1
3607030368
|
£37.27
|
£44.72
|
|
|
899 - AIR HOSE
BSD-3607000027.A17
3607000027
|
£33.74
|
£40.49
|
|
