1 - MOTOR HOUSING
BSD-1609310260.A1
1609310260
|
-
|
|
|
|
3 - MANUFACTURER'S NAMEPLATE
BSD-1609310208.A1
1609310208
|
-
|
|
|
|
4 - NEEDLE-ROLLER BEARING
BSD-1609310206.A0
1609310206
|
-
|
|
|
|
6 - GRINDING SPINDLE
BSD-1609310270.A0
1609310270
|
-
|
|
|
|
7 - GUIDE BUSHING
BSD-1609310286.A1
1609310286
|
-
|
|
|
|
8 - STOP RING
BSD-1609310176.A0
1609310176
|
-
|
|
|
|
9 - GROOVE BALL BEARING 6200 DIN 625
BSD-1900900301.A0
1900900301
|
-
|
|
|
|
10 - SPRING RETAINING RING DIN 471-10x1MM-FSt
BSD-2916650001.A167
2916650001
|
£2.61
|
£3.13
|
|
|
11 - STOP RING
BSD-1609310181.A0
1609310181
|
-
|
|
|
|
12 - CARRIER
BSD-1609310217.A1
1609310217
|
-
|
|
|
|
13 - GROOVE BALL BEARING
BSD-3600900026.A0
3600900026
|
£5.01
|
£6.01
|
|
|
14 - BEARING FLANGE
BSD-1609310235.A1
1609310235
|
-
|
|
|
|
15 - STATOR
BSD-1609310224.A1
1609310224
|
-
|
|
|
|
16 - SLOTTED SPRING PIN 2x8 DIN 1481
BSD-2917760035.A1
2917760035
|
-
|
|
|
|
17 - ROTOR
BSD-1609310223.A0
1609310223
|
-
|
|
|
|
18 - SET OF CLUTCH PLATES
BSD-3609202A03.A2
3609202A03
|
£18.96
|
£22.75
|
|
|
19 - BEARING FLANGE
BSD-1609310240.A0
1609310240
|
-
|
|
|
|
20 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A158
1900905015
|
£30.42
|
£36.51
|
|
|
21 - SEAL RING
BSD-1609310157.A1
1609310157
|
-
|
|
|
|
25 - VALVE HOUSING
BSD-1609310262.A2
1609310262
|
-
|
|
|
|
31 - NEEDLE ROLLER A 3x17.8 G2 DIN 5402
BSD-1903201045.A2
1903201045
|
-
|
|
|
|
32 - CONTROL LEVER
BSD-1609310271.A2
1609310271
|
-
|
|
|
|
33 - NAMEPLATE
BSD-1601104578.A5
1601104578
|
-
|
|
|
|
34 - ROUND-HEAD GROOVED PIN
BSD-1609310358.A8
1609310358
|
-
|
|
|
|
35 - NEEDLE ROLLER A 3x23.8 G2 DIN 5402
BSD-1903201047.A2
1903201047
|
-
|
|
|
|
36 - BALL
BSD-1609310156.A2
1609310156
|
-
|
|
|
|
37 - COMPRESSION SPRING
BSD-1609310185.A0
1609310185
|
-
|
|
|
|
38 - SEAL RING
BSD-1609310011.A0
1609310011
|
-
|
|
|
|
39 - SCREW PLUG
BSD-1609310001.A3
1609310001
|
-
|
|
|
|
40 - HOSE FITTING
BSD-1609310043.A6
1609310043
|
-
|
|
|
|
41 - FITTING
BSD-1609310147.A1
1609310147
|
-
|
|
|
|
42 - SEAL RING
BSD-1609310154.A1
1609310154
|
-
|
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A931
3601119236
|
£3.72
|
£4.47
|
|
|
650 - SINGLE-HEAD ENG. WRENCH SW 14
BSD-1907950508.A60
1907950508
|
£14.91
|
£17.89
|
|
|
651 - COLLET dia 6 MM
BSD-1608570061.A0
1608570061
|
-
|
|
|
|
703 - UNION NUT
BSD-3603340018.A0
3603340018
|
£23.86
|
£28.63
|
|
|
704 - COLLET dia 3 MM
BSD-1608570059.A8
1608570059
|
-
|
|
|
|
704 - COLLET dia 1/8
BSD-2608570070.A7
2608570070
|
-
|
|
|
|
704 - COLLET dia 6 MM
BSD-2608570071.A2
2608570071
|
£23.07
|
£27.68
|
|
