1 - MOTOR HOUSING
BSD-3605108023.A0
3605108023
|
-
|
|
|
|
2 - STATOR 370W
BSD-3604090003.A87
3604090003
|
£93.88
|
£112.65
|
|
|
3 - ROTOR
BSD-3604220010.A1
3604220010
|
-
|
|
|
|
7 - COVER DISC
BSD-3600132000.A0
3600132000
|
-
|
|
|
|
8 - BALL BEARING 7x19x6
BSD-2600905032.A412
2600905032
|
£5.30
|
£6.36
|
|
|
55 - O-RING 10x3 MM
BSD-1900210108.A0
1900210108
|
£11.30
|
£13.56
|
|
|
60 - STRAINER
BSD-3600002000.A224
3600002000
|
£3.72
|
£4.47
|
|
|
61 - PLAIN WASHER
BSD-1600100011.A0
1600100011
|
-
|
|
|
|
66 - STRAIGHT PIN
BSD-3604710009.A0
3604710009
|
-
|
|
|
|
67 - CONTROL LEVER
BSD-3602053001.A46
3602053001
|
£2.80
|
£3.36
|
|
|
68 - BALL dia9 MM
BSD-3603230004.A82
3603230004
|
£3.72
|
£4.47
|
|
|
69 - COMPRESSION SPRING
BSD-3604643004.A1
3604643004
|
-
|
|
|
|
72 - STRAIGHT PIN 3M6x24 DIN 7-C35K
BSD-2917610083.A88
2917610083
|
£1.75
|
£2.10
|
|
|
73 - STRAIGHT PIN
BSD-3604710023.A1
3604710023
|
-
|
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A56
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A247
1601110481
|
£2.16
|
£2.59
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A240
3603133000
|
£2.61
|
£3.13
|
|
|
98 - SET SCREW DIN 913-M6x16-45H
BSD-2912041197.A0
2912041197
|
£1.75
|
£2.10
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1439
3601119236
|
£3.72
|
£4.47
|
|
|
101 - CLAMPING RING
BSD-3603462002.A0
3603462002
|
-
|
|
|
|
102 - GROOVE BALL BEARING 6300-Z/C3 DIN 625
BSD-1900905315.A5
1900905315
|
£31.64
|
£37.97
|
|
|
103 - BEARING COVER
BSD-3605500005.A1
3605500005
|
-
|
|
|
|
104 - HEX NUT
BSD-3603315000.A0
3603315000
|
-
|
|
|
|
105 - ROUND NUT WITH 2 HOLES
BSD-3603340001.A0
3603340001
|
-
|
|
|
|
106 - PROTECTIVE COVER
BSD-3605510007.A2
3605510007
|
£12.04
|
£14.45
|
|
|
107 - O-RING 30x4 MM
BSD-2510210622.A0
2510210622
|
-
|
|
|
|
108 - GROOVED NAIL 3x4 DIN 1476 ST
BSD-2917721072.A0
2917721072
|
-
|
|
|
|
652 - HOSE FITTING
BSD-3603386003.A4
3603386003
|
-
|
|
|
|
653 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A494
1907950006
|
£4.26
|
£5.11
|
|
|
654 - PIN-TYPE FACE-WRENCH
BSD-1609310098.A0
1609310098
|
£21.42
|
£25.71
|
|
|
655 - SILENCER
BSD-3603462000.A91
3603462000
|
£16.41
|
£19.69
|
|
|
700 - ROUND NUT
BSD-3603340004.A0
3603340004
|
-
|
|
|
|
701 - COLLET JAWS
BSD-3608570003.A2
3608570003
|
£120.11
|
£144.13
|
|
|
750 - SILENCER
BSD-3607000073.A180
3607000073
|
£18.96
|
£22.75
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030248.A92
3607030248
|
£31.64
|
£37.97
|
|
