1 - MOTOR HOUSING
BSD-3605108066.A17
3605108066
|
£31.64
|
£37.97
|
|
2 - STATOR 400W
BSD-3604090046.A55
3604090046
|
£102.57
|
£123.08
|
|
3 - ROTOR
BSD-3604220060.A5
3604220060
|
£63.50
|
£76.20
|
|
5 - BEARING FLANGE
BSD-3605700076.A44
3605700076
|
£48.38
|
£58.06
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A196
3600905039
|
£12.04
|
£14.45
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A253
1900905028
|
£33.74
|
£40.49
|
|
26 - CYLINDRICAL GEAR Z=15
BSD-3606316063.A10
3606316063
|
£37.27
|
£44.72
|
|
28 - RING GEAR Z=42
BSD-3606334055.A1
3606334055
|
£21.52
|
£25.83
|
|
31 - CYLINDRICAL GEAR Z=15
BSD-3606316059.A11
3606316059
|
-
|
|
|
32 - NEEDLE-ROLLER CAGE
BSD-3600913006.A49
3600913006
|
£7.36
|
£8.83
|
|
33 - NEEDLE ROLLER
BSD-3603201047.A38
3603201047
|
£1.75
|
£2.10
|
|
34 - SHIM 0.20 MM
BSD-2600100586.A85
2600100586
|
£1.75
|
£2.10
|
|
37 - THREADED BUSHING
BSD-3600360005.A1
3600360005
|
-
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337142.A0
3606337142
|
-
|
|
|
40 - O-RING 32.0x1.5 MM
BSD-3600210057.A21
3600210057
|
£2.61
|
£3.13
|
|
41 - GROOVE BALL BEARING
BSD-3600905027.A8
3600905027
|
£16.41
|
£19.69
|
|
43 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A620
2916660013
|
£2.16
|
£2.59
|
|
44 - O-RING 26.0x1.5 MM
BSD-2600210018.A107
2600210018
|
£3.72
|
£4.47
|
|
45 - GEAR HOUSING
BSD-3605125048.A0
3605125048
|
-
|
|
|
47 - SPIGOT
BSD-3600700033.A0
3600700033
|
£27.23
|
£32.68
|
|
49 - SILENCER
BSD-3601010006.A3
3601010006
|
£1.75
|
£2.10
|
|
50 - RETAINING WASHER
BSD-3600101036.A44
3600101036
|
£4.26
|
£5.11
|
|
52 - GROOVE BALL BEARING 15x32x9
BSD-1900905122.A196
1900905122
|
£10.10
|
£12.12
|
|
53 - SHIM 0.2 MM
BSD-1610101603.A3
1610101603
|
£1.75
|
£2.10
|
|
56 - FITTING
BSD-3603462007.A52
3603462007
|
£7.36
|
£8.83
|
|
57 - SEALING DISK
BSD-3600206005.A46
3600206005
|
£5.30
|
£6.36
|
|
60 - STRAINER
BSD-3600002006.A22
3600002006
|
£3.72
|
£4.47
|
|
62 - STRAINER
BSD-3600002005.A26
3600002005
|
£2.80
|
£3.36
|
|
65 - O-RING 15x2 MM
BSD-1900210112.A170
1900210112
|
£2.61
|
£3.13
|
|
67 - STRAIGHT PIN
BSD-3603201048.A8
3603201048
|
£10.10
|
£12.12
|
|
74 - O-RING 23.0x2.0 MM
BSD-3600210032.A25
3600210032
|
£4.75
|
£5.70
|
|
75 - O-RING 18x2 MM
BSD-1900210315.A7
1900210315
|
£2.80
|
£3.36
|
|
76 - PUSH-BUTTON
BSD-1600A00HZ4.A32
1600A00HZ4
|
£3.72
|
£4.47
|
|
77 - PUSH-BUTTON
BSD-1600A00HZ5.A1
1600A00HZ5
|
£3.72
|
£4.47
|
|
79 - PILOT-VALVE BUSHING
BSD-3600313008.A19
3600313008
|
£2.80
|
£3.36
|
|
82 - INTERMEDIATE PIECE
BSD-3600390018.A2
3600390018
|
£5.30
|
£6.36
|
|
83 - COMPRESSION SPRING
BSD-3604643013.A33
3604643013
|
£2.16
|
£2.59
|
|
84 - CONNECTION COVER
BSD-3605500046.A8
3605500046
|
£4.26
|
£5.11
|
|
95 - NAMEPLATE
BSD-160111A3HF.A571
160111A3HF
|
£3.72
|
£4.47
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110038.A0
3601110038
|
£5.30
|
£6.36
|
|
97 - GROOVED NAIL
BSD-3603133000.A467
3603133000
|
£2.61
|
£3.13
|
|
99 - REFERENCE PLATE
BSD-3601119236.A322
3601119236
|
£3.72
|
£4.47
|
|
650 - SILENCER
BSD-3603462000.A145
3603462000
|
£16.41
|
£19.69
|
|
652 - HOSE FITTING
BSD-2603386002.A90
2603386002
|
£5.30
|
£6.36
|
|
653 - SUPPORT CLAMP
BSD-3608040002.A6
3608040002
|
£72.18
|
£86.62
|
|
654 - AUXILIARY HANDLE M14
BSD-1602025022.A1324
1602025022
|
£13.41
|
£16.09
|
|
654/1 - AUXILIARY HANDLE dia48 MM
BSD-3602025007.A2
3602025007
|
£27.23
|
£32.68
|
|
654/2 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1180
1602025030
|
£18.96
|
£22.75
|
|
655 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A568
1607950061
|
£5.42
|
£6.50
|
|
656 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A193
2607950511
|
£4.26
|
£5.11
|
|
657 - PROTECTING COVER
BSD-2601329036.A0
2601329036
|
-
|
|
|
658 - BACKING PAD
BSD-3608601009.A1
3608601009
|
-
|
|
|
700 - SILENCER
BSD-3607000073.A99
3607000073
|
£18.96
|
£22.75
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607030039.A3
3607030039
|
£283.50
|
£340.20
|
|
804 - ROTOR LAMELLA
BSD-3607030030.A84
3607030030
|
£31.64
|
£37.97
|
|
868 - VALVE CONE
BSD-3608750042.A21
3608750042
|
£6.52
|
£7.83
|
|
882 - ASSEMBLY OF SERVICE PARTS
BSD-3607030040.A1
3607030040
|
£21.52
|
£25.83
|
|
