Bosch GSR 1080-LI / 3601JA8900 / EU 10.8 Volt Spare Parts

An exploded drawing and listing for the Bosch GSR 1080-LI / 3601JA8900 / EU 10.8 Volt

	Ex VAT	Inc VAT
1 - HOUSING BSD-2609100955.A7 2609100955	£18.96	£22.75
4 - ELECTRONICS MODULE BSD-2609199614.A0 2609199614	£45.67	£54.80
5 - BUTTON BSD-2609100698.A7 2609100698	£2.80	£3.36
9 - MANUFACTURER'S NAMEPLATE GSR 1080 LI BSD-2609133194.A0 2609133194	£2.33	£2.80
25 - KEYLESS CHUCK 13 MM BSD-2609111225.A7 2609111225	£37.27	£44.72
32 - SWITCHOVER UNIT BSD-2609199336.A1 2609199336	£3.72	£4.47
45 - GEAR BOX BSD-2609199337.A7 2609199337	£45.67	£54.80
46 - COMPRESSION SPRING BSD-1609280477.A54 1609280477	£1.75	£2.10
91 - SLIDE-IN ACCU PACKAGE BBS MR Alpha 10.8V BSD-2607336731.A1 2607336731	£58.76	£70.51
101 - TORX FLAT-HEAD SCREW 3x16 BSD-2609110201.A90 2609110201	£2.16	£2.59
107 - COUNTERSUNK-HEAD SCREW BSD-2609111314.A4 2609111314	£1.75	£2.10
653 - BATTERY CHARGER EU 230/10.8-18V. 30 MIN BSD-2607225727.A2 2607225727	£51.22	£61.47
802 - DC MOTOR 10.8 V BSD-2609199366.A1 2609199366	£31.64	£37.97
808 - NAMEPLATE BSD-2609135925.A0 2609135925	£2.61	£3.13

Attribute Name	Value
Brand	Bosch
