2 - BRUSH HOLDER
BSD-1604336008.A226
1604336008
|
£21.52
|
£25.83
|
|
3 - FIELD 220V
BSD-1604220109.A9
1604220109
|
-
|
|
|
4 - ARMATURE 220V
BSD-1604011223.A14
1604011223
|
-
|
|
|
6 - SPIRAL SPRING
BSD-1604652015.A434
1604652015
|
£2.80
|
£3.36
|
|
8 - SEALING CAP
BSD-1605500089.A79
1605500089
|
-
|
|
|
9 - HANDLE
BSD-1605132083.A8
1605132083
|
-
|
|
|
12 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A461
3600703011
|
£2.80
|
£3.36
|
|
13/01 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.5mm H07RN-F
BSD-1604460203.A60
1604460203
|
£33.74
|
£40.49
|
|
14 - SUPPRESSION FILTER
BSD-1607328034.A174
1607328034
|
£4.26
|
£5.11
|
|
15 - FASTENING CLAMP
BSD-1601302013.A555
1601302013
|
£1.75
|
£2.10
|
|
19/00/08 - FELT WASHER
BSD-1600205019.A84
1600205019
|
£1.75
|
£2.10
|
|
20 - BEARING COVER
BSD-1605808054.A266
1605808054
|
-
|
|
|
21 - COVER DISC
BSD-1600102012.A266
1600102012
|
-
|
|
|
23 - SEALING DISK
BSD-1600108055.A97
1600108055
|
£1.75
|
£2.10
|
|
24 - BEARING FLANGE
BSD-1607000229.A110
1607000229
|
-
|
|
|
27 - NEEDLE BEARING dia22x11.3 MM
BSD-1600910010.A280
1600910010
|
£45.67
|
£54.80
|
|
28 - RUBBER RING 10 MM
BSD-1600206014.A37
1600206014
|
£1.75
|
£2.10
|
|
29 - AIR-DEFLECTOR RING
BSD-1600502007.A30
1600502007
|
-
|
|
|
30 - SPRING RETAINING RING DIN 472 38X1.5MM
BSD-2916660017.A46
2916660017
|
£4.26
|
£5.11
|
|
31 - NAMEPLATE
BSD-160111A3H3.A3823
160111A3H3
|
£2.61
|
£3.13
|
|
32 - ROTARY SHAFT LIP SEAL
BSD-1600290008.A91
1600290008
|
£2.61
|
£3.13
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A142
1600190004
|
-
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A141
1600190005
|
£1.32
|
£1.58
|
|
35 - TAB WASHER
BSD-1601030022.A403
1601030022
|
£1.75
|
£2.10
|
|
36 - RUBBER BUSHING
BSD-1600502006.A121
1600502006
|
£1.75
|
£2.10
|
|
38 - MANUFACTURER'S NAMEPLATE
BSD-1601110003.A252
1601110003
|
-
|
|
|
40 - SPRING WASHER dia27.5x38.4 MM
BSD-1600150007.A11
1600150007
|
£1.75
|
£2.10
|
|
50 - GROOVE BALL BEARING 6203-2 Z DIN 625
BSD-1900905227.A55
1900905227
|
-
|
|
|
51 - RETAINING RING dia22 MM
BSD-2916620011.A149
2916620011
|
£1.75
|
£2.10
|
|
52 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A143
1900905234
|
£31.64
|
£37.97
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A63
1600900029
|
-
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A302
2910021118
|
£1.75
|
£2.10
|
|
55 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A55
2910211006
|
£1.75
|
£2.10
|
|
55 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A156
2910021050
|
£1.75
|
£2.10
|
|
56 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A9
2916060003
|
£1.32
|
£1.58
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-8.8
BSD-2910021157.A28
2910021157
|
£1.32
|
£1.58
|
|
58 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A105
2915011005
|
£1.75
|
£2.10
|
|
59 - TAPPING SCREW B4.8x57.5 MM
BSD-1603429000.A61
1603429000
|
£1.75
|
£2.10
|
|
60 - TAPPING SCREW DIN 7971-ST4.8x25-F
BSD-2910211036.A33
2910211036
|
£1.75
|
£2.10
|
|
60/01 - SOCKET HEAD CAP SCREW DIN 84-AM5x16-8.8
BSD-2910021158.A61
2910021158
|
£1.32
|
£1.58
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-8.8
BSD-2910021162.A28
2910021162
|
-
|
|
|
62 - HEX NUT M12x1.5 MM
BSD-1603300009.A8
1603300009
|
£1.75
|
£2.10
|
|
63 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A149
1603435006
|
-
|
|
|
63 - SOCKET HEAD CAP SCREW DIN 84-BM5x82
BSD-1603410001.A146
1603410001
|
-
|
|
|
64 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A91
2916680006
|
-
|
|
|
65 - SPRING WASHER DIN 137-A4
BSD-1600150006.A741
1600150006
|
-
|
|
|
66 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A303
2910021118
|
£1.75
|
£2.10
|
|
68 - SOCKET HEAD CAP SCREW DIN 84-AM6x15-8.8
BSD-2910021196.A23
2910021196
|
-
|
|
|
79 - SOCKET-TERMINAL STRIP 1x1.5 MM/2
BSD-1901091012.A0
1901091012
|
£5.30
|
£6.36
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A1449
1602025022
|
£13.41
|
£16.09
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1332
1602025030
|
£18.96
|
£22.75
|
|
651 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A302
2607950511
|
£4.26
|
£5.11
|
|
651 - SINGLE-HEAD ENG. WRENCH SW19
BSD-1907950511.A114
1907950511
|
£11.78
|
£14.13
|
|
652/00/02 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x20-8.8
BSD-2910141242.A151
2910141242
|
£1.75
|
£2.10
|
|
653 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A296
1907950007
|
£5.30
|
£6.36
|
|
654 - CLAMPING-FLANGE dia45 MM
BSD-2600501006.A155
2600501006
|
£16.43
|
£19.72
|
|
655 - ROUND NUT M14
BSD-2603345004.A142
2603345004
|
£6.52
|
£7.83
|
|
702 - TENSIONER PARTS SET
BSD-1607000030.A17
1607000030
|
-
|
|
|
712 - PARTS SET dia180 MM
BSD-1607000176.A44
1607000176
|
-
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A85
1607014103
|
£14.91
|
£17.89
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-1605108902.A30
1605108902
|
-
|
|
|
804 - BEVEL GEAR Z=52
BSD-1606333147.A4
1606333147
|
-
|
|
|
805 - BEVEL GEAR Z=17
BSD-1606333148.A17
1606333148
|
-
|
|
|
809 - SWITCH
BSD-1607200064.A1
1607200064
|
£40.80
|
£48.96
|
|
809/00/04 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A120
2910091118
|
£1.75
|
£2.10
|
|
