2 - BRUSH HOLDER
BSD-1604336008.A214
1604336008
|
£21.52
|
£25.83
|
|
|
3 - FIELD 100V
BSD-1604220216.A1
1604220216
|
-
|
|
|
|
3/8 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A127
1901350003
|
£1.75
|
£2.10
|
|
|
6 - SPIRAL SPRING
BSD-1604652015.A428
1604652015
|
£2.80
|
£3.36
|
|
|
8 - SEALING CAP
BSD-1605500089.A75
1605500089
|
-
|
|
|
|
9 - HANDLE
BSD-1605132093.A51
1605132093
|
-
|
|
|
|
11 - SEAL
BSD-1600113002.A38
1600113002
|
£1.75
|
£2.10
|
|
|
12 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A464
3600703011
|
£2.80
|
£3.36
|
|
|
13 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.5mm H07RN-F
BSD-1604460203.A62
1604460203
|
£33.74
|
£40.49
|
|
|
14 - SUPPRESSION FILTER
BSD-1607328034.A166
1607328034
|
£4.26
|
£5.11
|
|
|
15 - FASTENING CLAMP
BSD-1601302013.A560
1601302013
|
£1.75
|
£2.10
|
|
|
17 - COVER PLATE
BSD-1601037009.A18
1601037009
|
-
|
|
|
|
17 - COVER PLATE
BSD-1601037006.A136
1601037006
|
-
|
|
|
|
19 - CONTROL LEVER
BSD-1602026058.A41
1602026058
|
-
|
|
|
|
19/8 - FELT WASHER
BSD-1600205019.A72
1600205019
|
£1.75
|
£2.10
|
|
|
19/10 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A161
2910021050
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A276
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A271
1600102012
|
-
|
|
|
|
22 - GRINDING SPINDLE M14. L=101 MM
BSD-1603523090.A117
1603523090
|
-
|
|
|
|
23 - SEALING DISK
BSD-1600108055.A92
1600108055
|
£1.75
|
£2.10
|
|
|
25 - GROMMET
BSD-1600306001.A139
1600306001
|
£2.61
|
£3.13
|
|
|
27 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A266
2600910001
|
£4.26
|
£5.11
|
|
|
28 - RUBBER RING 7 MM
BSD-1600206020.A649
1600206020
|
£1.75
|
£2.10
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600502017.A40
1600502017
|
-
|
|
|
|
30 - SPRING RETAINING RING DIN 472 38X1.5MM
BSD-2916660017.A60
2916660017
|
£4.26
|
£5.11
|
|
|
32 - ROTARY SHAFT LIP SEAL 18.7 MM
BSD-1600290013.A167
1600290013
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A130
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A153
1600190005
|
£1.32
|
£1.58
|
|
|
35 - TAB WASHER
BSD-1601030022.A392
1601030022
|
£1.75
|
£2.10
|
|
|
36 - RUBBER RING
BSD-1600206015.A83
1600206015
|
£2.16
|
£2.59
|
|
|
38 - MANUFACTURER'S NAMEPLATE
BSD-1601110003.A259
1601110003
|
-
|
|
|
|
40 - SPRING WASHER dia27.5x38.4 MM
BSD-1600150007.A23
1600150007
|
£1.75
|
£2.10
|
|
|
50 - GROOVE BALL BEARING 17x40x12
BSD-1900905281.A87
1900905281
|
£31.64
|
£37.97
|
|
|
52 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A151
1900905234
|
£31.64
|
£37.97
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A76
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A297
2910021118
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A58
2910211006
|
£1.75
|
£2.10
|
|
|
56 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A133
2916011005
|
£1.75
|
£2.10
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A350
2910011157
|
-
|
|
|
|
58 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A559
2910211020
|
£2.16
|
£2.59
|
|
|
60 - TAPPING SCREW DIN 7971-ST4.8x25-F
BSD-2910211036.A23
2910211036
|
£1.75
|
£2.10
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A338
2910011162
|
£1.75
|
£2.10
|
|
|
62 - HEX NUT
BSD-1603300018.A35
1603300018
|
-
|
|
|
|
63 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A144
1603435006
|
-
|
|
|
|
66 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A153
2910021122
|
£2.16
|
£2.59
|
|
|
69 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A512
2910211011
|
£1.75
|
£2.10
|
|
|
100 - GROOVED RING
BSD-1600390011.A27
1600390011
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A93
1607014103
|
£14.91
|
£17.89
|
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-1605108902.A21
1605108902
|
-
|
|
|
|
803 - CONNECTING CABLE
BSD-1604440004.A81
1604440004
|
-
|
|
|
|
803/2 - TERMINAL LUG
BSD-1601353003.A36
1601353003
|
-
|
|
|
|
804 - CROWN GEAR Z=52
BSD-1606333198.A5
1606333198
|
-
|
|
|
|
805 - BEVEL GEAR Z=16. dia 10 MM
BSD-1606333217.A5
1606333217
|
-
|
|
|
|
809/10 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A130
2910091118
|
£1.75
|
£2.10
|
|
|
813 - PARTS SET
BSD-1607000161.A70
1607000161
|
-
|
|
|
|
816 - PARTS SET
BSD-1607000905.A0
1607000905
|
-
|
|
|
|
817 - BEARING FLANGE
BSD-1607000229.A121
1607000229
|
-
|
|
|
|
830 - ARMATURE 100-110V
BSD-1604011127.A0
1604011127
|
-
|
|
|
|
831 - ON-OFF SWITCH
BSD-1607200097.A7
1607200097
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3816
160111A3H3
|
£2.61
|
£3.13
|
|
