2 - BRUSH HOLDER
BSD-1604336008.A222
1604336008
|
£21.52
|
£25.83
|
|
|
3 - FIELD 110-115V
BSD-1604220217.A1
1604220217
|
-
|
|
|
|
3/8 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A132
1901350003
|
£1.75
|
£2.10
|
|
|
6 - SPIRAL SPRING
BSD-1604652015.A425
1604652015
|
£2.80
|
£3.36
|
|
|
8 - SEALING CAP
BSD-1605500089.A71
1605500089
|
-
|
|
|
|
9 - PARTS SET
BSD-1607000187.A12
1607000187
|
-
|
|
|
|
12 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A19
1600703009
|
£5.58
|
£6.70
|
|
|
13 - POWER SUPPLY CORD GB 110V 4.15m 2 x 2.5mm H07 RN-F
BSD-1604460202.A7
1604460202
|
£45.67
|
£54.80
|
|
|
17 - COVER PLATE
BSD-1601037006.A140
1601037006
|
-
|
|
|
|
19/8 - FELT WASHER
BSD-1600205019.A75
1600205019
|
£1.75
|
£2.10
|
|
|
19/10 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A165
2910021050
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A273
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A276
1600102012
|
-
|
|
|
|
23 - SEALING DISK
BSD-1600108055.A87
1600108055
|
£1.75
|
£2.10
|
|
|
27 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A262
2600910001
|
£4.26
|
£5.11
|
|
|
28 - RUBBER RING 7 MM
BSD-1600206020.A652
1600206020
|
£1.75
|
£2.10
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600502017.A38
1600502017
|
-
|
|
|
|
30 - SPRING RETAINING RING DIN 472 38X1.5MM
BSD-2916660017.A56
2916660017
|
£4.26
|
£5.11
|
|
|
32 - ROTARY SHAFT LIP SEAL 18.7 MM
BSD-1600290013.A164
1600290013
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A133
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A150
1600190005
|
£1.32
|
£1.58
|
|
|
35 - TAB WASHER
BSD-1601030022.A388
1601030022
|
£1.75
|
£2.10
|
|
|
36 - RUBBER RING
BSD-1600206015.A80
1600206015
|
£2.16
|
£2.59
|
|
|
40 - SPRING WASHER dia27.5x38.4 MM
BSD-1600150007.A18
1600150007
|
£1.75
|
£2.10
|
|
|
50 - GROOVE BALL BEARING 17x40x12
BSD-1900905281.A83
1900905281
|
£31.64
|
£37.97
|
|
|
52 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A155
1900905234
|
£31.64
|
£37.97
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A70
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A292
2910021118
|
£1.75
|
£2.10
|
|
|
55/1 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A54
2910211021
|
£1.75
|
£2.10
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A352
2910011157
|
-
|
|
|
|
58 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A554
2910211020
|
£2.16
|
£2.59
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A336
2910011162
|
£1.75
|
£2.10
|
|
|
62 - HEX NUT
BSD-1603300018.A40
1603300018
|
-
|
|
|
|
63 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A142
1603435006
|
-
|
|
|
|
69 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A508
2910211011
|
£1.75
|
£2.10
|
|
|
100 - GROOVED RING
BSD-1600390011.A30
1600390011
|
-
|
|
|
|
150 - END SPLICE DIN 46 228-A2.5-7
BSD-1900452003.A25
1900452003
|
£2.61
|
£3.13
|
|
|
151 - HOLDING BELT
BSD-1604700002.A16
1604700002
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A96
1607014103
|
£14.91
|
£17.89
|
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-1605108902.A17
1605108902
|
-
|
|
|
|
803/2 - TERMINAL LUG
BSD-1601353003.A43
1601353003
|
-
|
|
|
|
804 - CROWN GEAR Z=55
BSD-1606333208.A34
1606333208
|
-
|
|
|
|
805 - BEVEL GEAR
BSD-1606333220.A0
1606333220
|
-
|
|
|
|
809/10 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A125
2910091118
|
£1.75
|
£2.10
|
|
|
813 - PARTS SET
BSD-1607000161.A65
1607000161
|
-
|
|
|
|
817 - BEARING FLANGE
BSD-1607000229.A119
1607000229
|
-
|
|
|
|
830 - ARMATURE 110-115V
BSD-1604011125.A1
1604011125
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3811
160111A3H3
|
£2.61
|
£3.13
|
|
