2 - BRUSH HOLDER
BSD-1604336008.A192
1604336008
|
£21.52
|
£25.83
|
|
|
3 - FIELD 110-115V
BSD-1604220217.A2
1604220217
|
-
|
|
|
|
6 - SPIRAL SPRING
BSD-1604652015.A449
1604652015
|
£2.80
|
£3.36
|
|
|
8 - SEALING CAP
BSD-1605500089.A86
1605500089
|
-
|
|
|
|
10 - ON-OFF SWITCH
BSD-1607200089.A4
1607200089
|
-
|
|
|
|
12 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A15
1600703009
|
£5.58
|
£6.70
|
|
|
13 - POWER SUPPLY CORD GB 110V 4.15m 2 x 2.5mm H07 RN-F
BSD-1604460202.A3
1604460202
|
£45.67
|
£54.80
|
|
|
14 - SUPPRESSION FILTER
BSD-1607328034.A139
1607328034
|
£4.26
|
£5.11
|
|
|
15 - FASTENING CLAMP
BSD-1601302013.A565
1601302013
|
£1.75
|
£2.10
|
|
|
17 - COVER PLATE
BSD-1601037006.A155
1601037006
|
-
|
|
|
|
19/8 - FELT WASHER
BSD-1600205019.A107
1600205019
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A249
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A222
1600102012
|
-
|
|
|
|
22 - GRINDING SPINDLE M14. L=101 MM
BSD-1603523090.A98
1603523090
|
-
|
|
|
|
23 - SEALING DISK
BSD-1600108055.A140
1600108055
|
£1.75
|
£2.10
|
|
|
27 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A225
2600910001
|
£4.26
|
£5.11
|
|
|
28 - RUBBER RING 7 MM
BSD-1600206020.A642
1600206020
|
£1.75
|
£2.10
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600502017.A12
1600502017
|
-
|
|
|
|
30 - SPRING RETAINING RING DIN 472 38X1.5MM
BSD-2916660017.A17
2916660017
|
£4.26
|
£5.11
|
|
|
32 - ROTARY SHAFT LIP SEAL 18.7 MM
BSD-1600290013.A155
1600290013
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A88
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A195
1600190005
|
£1.32
|
£1.58
|
|
|
35 - TAB WASHER
BSD-1601030022.A427
1601030022
|
£1.75
|
£2.10
|
|
|
36 - RUBBER RING
BSD-1600206015.A94
1600206015
|
£2.16
|
£2.59
|
|
|
38 - MANUFACTURER'S NAMEPLATE
BSD-1601110003.A217
1601110003
|
-
|
|
|
|
40 - SPRING WASHER dia27.5x38.4 MM
BSD-1600150007.A48
1600150007
|
£1.75
|
£2.10
|
|
|
50 - GROOVE BALL BEARING 17x40x12
BSD-1900905203.A24
1900905203
|
-
|
|
|
|
52 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A202
1900905234
|
£31.64
|
£37.97
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A25
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A252
2910021118
|
£1.75
|
£2.10
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A314
2910011157
|
-
|
|
|
|
58 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A538
2910211020
|
£2.16
|
£2.59
|
|
|
59 - TAPPING SCREW B4.8x57.5 MM
BSD-1603429000.A25
1603429000
|
£1.75
|
£2.10
|
|
|
60 - TAPPING SCREW B4.8x57.5 MM
BSD-1603429000.A26
1603429000
|
£1.75
|
£2.10
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A373
2910011162
|
£1.75
|
£2.10
|
|
|
62 - HEX NUT
BSD-1603300018.A20
1603300018
|
-
|
|
|
|
63 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A129
1603435006
|
-
|
|
|
|
66 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A181
2910021122
|
£2.16
|
£2.59
|
|
|
66 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A563
2910211018
|
£1.75
|
£2.10
|
|
|
69 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A446
2910211011
|
£1.75
|
£2.10
|
|
|
78 - END SPLICE A 4-9 DIN 46 228
BSD-1900452004.A15
1900452004
|
-
|
|
|
|
100 - GROOVED RING
BSD-1600390011.A50
1600390011
|
-
|
|
|
|
150 - END SPLICE DIN 46 228-A2.5-7
BSD-1900452003.A13
1900452003
|
£2.61
|
£3.13
|
|
|
151 - HOLDING BELT
BSD-1604700002.A19
1604700002
|
-
|
|
|
|
650/1 - AUXILIARY HANDLE M14
BSD-1602025022.A1514
1602025022
|
£13.41
|
£16.09
|
|
|
650/1 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1267
1602025030
|
£18.96
|
£22.75
|
|
|
652 - PROTECTIVE COVER dia230 MM
BSD-1605510198.A19
1605510198
|
-
|
|
|
|
652/2 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x20-8.8
BSD-2910141242.A128
2910141242
|
£1.75
|
£2.10
|
|
|
703/10 - STRAP-SHAPED HANDLE
BSD-1600793004.A1
1600793004
|
-
|
|
|
|
703/11 - HEX SCREW M14x16x1.5 MM
BSD-2603450007.A426
2603450007
|
£5.58
|
£6.70
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A107
1607014103
|
£14.91
|
£17.89
|
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-1605108902.A4
1605108902
|
-
|
|
|
|
804 - CROWN GEAR Z=59
BSD-1606333200.A7
1606333200
|
-
|
|
|
|
805 - BEVEL GEAR Z=14. dia 10 MM
BSD-1606333218.A7
1606333218
|
-
|
|
|
|
809 - SWITCH KIT
BSD-1607000034.A263
1607000034
|
-
|
|
|
|
809/10 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A98
2910091118
|
£1.75
|
£2.10
|
|
|
816 - PARTS SET
BSD-1607000905.A22
1607000905
|
-
|
|
|
|
830 - ARMATURE 110V
BSD-1604011132.A2
1604011132
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3801
160111A3H3
|
£2.61
|
£3.13
|
|
