1 - MOTOR HOUSING
BSD-1615106003.A1
1615106003
|
-
|
|
|
|
2 - POLE SHOE 115V
BSD-1614220015.A0
1614220015
|
-
|
|
|
|
3 - SET SCREW DIN 417-M8x15-5.8
BSD-2912051237.A41
2912051237
|
-
|
|
|
|
4 - ARMATURE 115V
BSD-1614011006.A0
1614011006
|
-
|
|
|
|
5 - MAGNETO BALL BEARING BO17T M DIN 615
BSD-1900900114.A1
1900900114
|
-
|
|
|
|
6 - INTERMEDIATE RING
BSD-1610201001.A2
1610201001
|
-
|
|
|
|
7 - MAGNETO BALL BEARING BO15T M DIN 615
BSD-1900900112.A4
1900900112
|
-
|
|
|
|
8 - SHIM 0.1 MM
BSD-1610101602.A1
1610101602
|
-
|
|
|
|
8 - GUIDE BUSHING
BSD-1610222001.A1
1610222001
|
-
|
|
|
|
8 - SHIM 0.2 MM
BSD-1610101603.A1
1610101603
|
£1.75
|
£2.10
|
|
|
9 - COMMUTATOR END SHIELD
BSD-1615850002.A1
1615850002
|
-
|
|
|
|
10 - RETAINING SNAP RING
BSD-1610220005.A1
1610220005
|
-
|
|
|
|
11 - SEALING CAP
BSD-1615500008.A2
1615500008
|
-
|
|
|
|
11 - SEALING PLATE
BSD-1610051000.A1
1610051000
|
-
|
|
|
|
12 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x25-8.8
BSD-2910141244.A22
2910141244
|
£1.75
|
£2.10
|
|
|
13 - SPRING LOCK WASHER B 8 DIN 127
BSD-2916680009.A133
2916680009
|
-
|
|
|
|
14 - SOCKET HEAD CAP SCREW DIN 84-AM6x15-8.8
BSD-2910021196.A37
2910021196
|
-
|
|
|
|
15 - SPRING WASHER DIN 137-A 6-ST
BSD-2916060007.A28
2916060007
|
£1.75
|
£2.10
|
|
|
17 - BRUSH HOLDER
BSD-1614330004.A0
1614330004
|
-
|
|
|
|
18 - BRUSH HOLDER
BSD-1614330005.A2
1614330005
|
-
|
|
|
|
19 - FLAT KEY
BSD-1612300009.A1
1612300009
|
-
|
|
|
|
21 - SOCKET HEAD CAP SCREW
BSD-1613412000.A1
1613412000
|
-
|
|
|
|
21 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x5-8.8
BSD-2910021081.A1
2910021081
|
-
|
|
|
|
22 - COMPRESSION SPRING
BSD-1614612000.A2
1614612000
|
-
|
|
|
|
23 - RUBBER RING
BSD-1610109000.A1
1610109000
|
-
|
|
|
|
24 - INSULATING WASHER
BSD-1610502002.A0
1610502002
|
-
|
|
|
|
25 - RETAINING RING
BSD-1610119001.A2
1610119001
|
-
|
|
|
|
26 - FLANGED BEARING
BSD-1615805013.A0
1615805013
|
-
|
|
|
|
27 - SEAL RING
BSD-1600108008.A4
1600108008
|
-
|
|
|
|
28 - CYLINDRICAL GEAR Z=33/49
BSD-1616328001.A2
1616328001
|
-
|
|
|
|
29 - MAGNETO BALL BEARING DIN 615-E 10 TM
BSD-1900900118.A3
1900900118
|
-
|
|
|
|
30 - SHIM 0.2 MM
BSD-1610101600.A1
1610101600
|
-
|
|
|
|
30 - SHIM 0.1 MM
BSD-1610101601.A1
1610101601
|
-
|
|
|
|
35 - ECCENTRIC SHAFT
BSD-1616110006.A4
1616110006
|
-
|
|
|
|
36 - ROTARY SHAFT LIP SEAL DIN 6503 20x40x10
BSD-2916730011.A4
2916730011
|
-
|
|
|
|
37 - SPACER BUSHING
BSD-1610322001.A4
1610322001
|
-
|
|
|
|
39 - GROOVE BALL BEARING 6203 DIN 625
BSD-1900900305.A5
1900900305
|
-
|
|
|
|
40 - SHIM 0.1 MM
BSD-1710101610.A4
1710101610
|
-
|
|
|
|
41 - CYLINDRICAL GEAR Z=54
BSD-1616317001.A1
1616317001
|
-
|
|
|
|
42 - WOODRUFF KEY
BSD-1610023001.A1
1610023001
|
-
|
|
|
|
43 - HEX NUT DIN 985-M12X1
BSD-1613313000.A17
1613313000
|
£2.80
|
£3.36
|
|
|
44 - SHIM
BSD-1600101626.A7
1600101626
|
-
|
|
|
|
45 - GEAR COVER R 3/4
BSD-1615808001.A3
1615808001
|
-
|
|
|
|
45 - GEAR COVER M 27x2 MM
BSD-1615808005.A2
1615808005
|
-
|
|
|
|
46 - CLAMPING RING
BSD-1613344001.A2
1613344001
|
-
|
|
|
|
47 - STRAIGHT PIN 4x5MM
BSD-2917500391.A1
2917500391
|
-
|
|
|
|
48 - HEX SOCKET HEAD CAP SCREW DIN 912-M 8x60-8.8
BSD-2910140258.A0
2910140258
|
-
|
|
|
|
49 - HEX SOCKET HEAD CAP SCREW DIN 912-M 8x50-8.8
BSD-2910141254.A4
2910141254
|
-
|
|
|
|
50 - SPRING LOCK WASHER B 8 DIN 127
BSD-2916680009.A134
2916680009
|
-
|
|
|
|
51 - LUBRIC. HEAD
BSD-1617401000.A2
1617401000
|
-
|
|
|
|
52 - HANDLE
BSD-1610763001.A3
1610763001
|
-
|
|
|
|
60 - HANDLE
BSD-1615132002.A5
1615132002
|
-
|
|
|
|
62 - EXTENSION SPRING
BSD-1614650000.A9
1614650000
|
-
|
|
|
|
64 - CONTROL LEVER
BSD-1611321005.A2
1611321005
|
-
|
|
|
|
65 - SET SCREW DIN 417-M6x18-5.8
BSD-2912051199.A1
2912051199
|
-
|
|
|
|
66 - BEARING BOLT
BSD-1603103002.A4
1603103002
|
-
|
|
|
|
67 - COILED SPRING PIN DIN 1481-4x18
BSD-2917760098.A17
2917760098
|
-
|
|
|
|
68 - CONTROL LEVER
BSD-1612098001.A5
1612098001
|
-
|
|
|
|
70 - LATCH
BSD-1612305000.A1
1612305000
|
-
|
|
|
|
71 - BEARING BOLT
BSD-1613103000.A0
1613103000
|
-
|
|
|
|
72 - STUD M 6x12 DIN 417-5.8
BSD-2912051193.A4
2912051193
|
-
|
|
|
|
73 - COILED SPRING
BSD-1614651000.A4
1614651000
|
-
|
|
|
|
74 - CONTROL LEVER
BSD-1612026900.A0
1612026900
|
-
|
|
|
|
75 - CONTROL LEVER
BSD-1612026001.A2
1612026001
|
-
|
|
|
|
76 - COILED SPRING PIN DIN 1481-4x18
BSD-2917760098.A16
2917760098
|
-
|
|
|
|
77 - STRAIGHT PIN 6 H 8x28 DIN 7
BSD-2917500154.A4
2917500154
|
-
|
|
|
|
78 - SEALING CAP
BSD-1615500058.A0
1615500058
|
-
|
|
|
|
79 - POWER SUPPLY CORD
BSD-1614461007.A0
1614461007
|
-
|
|
|
|
79 - POWER SUPPLY CORD
BSD-1614461010.A2
1614461010
|
-
|
|
|
|
80 - CONNECTOR PLUG
BSD-1614482003.A0
1614482003
|
-
|
|
|
|
81 - GROMMET
BSD-1600703013.A50
1600703013
|
-
|
|
|
|
81 - RUBBER BUSHING
BSD-1610306002.A2
1610306002
|
-
|
|
|
|
82 - POWER SUPPLY CORD
BSD-6288375150.A1
6288375150
|
-
|
|
|
|
83 - GROMMET
BSD-1610703011.A1
1610703011
|
£14.91
|
£17.89
|
|
|
84 - FASTENING CLAMP
BSD-1601302002.A4
1601302002
|
-
|
|
|
|
85 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A864
2910021125
|
£1.75
|
£2.10
|
|
|
86 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A179
2915011005
|
£1.75
|
£2.10
|
|
|
87 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A931
2916690003
|
£1.75
|
£2.10
|
|
|
88 - SPACER BUSHING
BSD-1610300027.A0
1610300027
|
-
|
|
|
|
89 - PLAIN WASHER
BSD-1600102006.A11
1600102006
|
£2.16
|
£2.59
|
|
|
90 - GROMMET
BSD-1600328027.A5
1600328027
|
-
|
|
|
|
91 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A863
2910021125
|
£1.75
|
£2.10
|
|
|
92 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A932
2916690003
|
£1.75
|
£2.10
|
|
|
93 - PLAIN WASHER
BSD-2330100002.A3
2330100002
|
-
|
|
|
|
94 - FIXING PLATE
BSD-1600136001.A11
1600136001
|
-
|
|
|
|
95 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A105
2910021118
|
£1.75
|
£2.10
|
|
|
96 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A925
2916690003
|
£1.75
|
£2.10
|
|
|
100 - ON-OFF SWITCH
BSD-1617200005.A1
1617200005
|
-
|
|
|
|
101 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A104
2910021118
|
£1.75
|
£2.10
|
|
|
102 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A926
2916690003
|
£1.75
|
£2.10
|
|
|
103 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A415
2910110120
|
£1.75
|
£2.10
|
|
|
104 - SPRING WASHER DIN 137-A4
BSD-1600150006.A833
1600150006
|
-
|
|
|
|
105 - PLAIN WASHER A 4.3 DIN 125-ST
BSD-2916010410.A303
2916010410
|
-
|
|
|
|
106 - INSULATING PLATE
BSD-1611007006.A1
1611007006
|
-
|
|
|
|
107 - INSULATING PLATE
BSD-1611006003.A4
1611006003
|
-
|
|
|
|
108 - INSULATING CAP
BSD-1610583001.A0
1610583001
|
-
|
|
|
|
109 - GROMMET
BSD-1610306012.A0
1610306012
|
-
|
|
|
|
110 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x25-8.8
BSD-2910141244.A24
2910141244
|
£1.75
|
£2.10
|
|
|
111 - SPRING LOCK WASHER B 8 DIN 127
BSD-2916680009.A139
2916680009
|
-
|
|
|
|
112 - HOUSING COVER
BSD-1615500004.A1
1615500004
|
-
|
|
|
|
113 - SEALING DISK
BSD-1611015000.A1
1611015000
|
-
|
|
|
|
114 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x15-8.8
BSD-2910141237.A6
2910141237
|
-
|
|
|
|
115 - SPRING WASHER A 8 DIN 137-ST
BSD-2916060008.A7
2916060008
|
-
|
|
|
|
120 - CONNECTING ROD
BSD-1612001010.A4
1612001010
|
-
|
|
|
|
121 - NEEDLE-ROLLER BEARING
BSD-1610910000.A1
1610910000
|
-
|
|
|
|
121 - GROOVE BALL BEARING 12x32x10
BSD-1900900302.A83
1900900302
|
-
|
|
|
|
122 - ADAPTOR PLATE
BSD-1610142001.A4
1610142001
|
-
|
|
|
|
122 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A773
2916660013
|
£2.16
|
£2.59
|
|
|
123 - SPLIT PIN DIN 94-4x22-ST
BSD-1904681520.A1
1904681520
|
-
|
|
|
|
123 - HEX NUT DIN 985-M12X1
BSD-1613313000.A20
1613313000
|
£2.80
|
£3.36
|
|
|
123 - CYL. ROLLER BEARING
BSD-3607020263.A1
3607020263
|
£68.42
|
£82.10
|
|
|
123 - SPRING RETAINING RING DIN 472-26x1.2 MM
BSD-2916660010.A22
2916660010
|
£1.75
|
£2.10
|
|
|
124 - HAMMER PISTON
BSD-1618700005.A4
1618700005
|
-
|
|
|
|
125 - PISTON PIN
BSD-1613124012.A4
1613124012
|
-
|
|
|
|
126 - GUIDE PLATE
BSD-1611030002.A1
1611030002
|
-
|
|
|
|
127 - COMPRESSION SPRING dia 36 MM
BSD-1614624004.A1
1614624004
|
-
|
|
|
|
127 - COMPRESSION SPRING
BSD-1614624002.A2
1614624002
|
-
|
|
|
|
128 - STRIKER
BSD-1618710011.A4
1618710011
|
-
|
|
|
|
128 - STRIKER
BSD-1618710009.A1
1618710009
|
-
|
|
|
|
129 - GUIDE TUBE
BSD-1615806005.A1
1615806005
|
-
|
|
|
|
130 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x30-8.8
BSD-2910141246.A6
2910141246
|
-
|
|
|
|
131 - SPRING LOCK WASHER B 8 DIN 127
BSD-2916680009.A138
2916680009
|
-
|
|
|
|
132 - SHIM
BSD-1611038005.A4
1611038005
|
-
|
|
|
|
133 - INTERMEDIATE FLANGE
BSD-1615700003.A1
1615700003
|
-
|
|
|
|
133 - PRESS-IN SOCKET
BSD-1610300017.A0
1610300017
|
-
|
|
|
|
134 - O-RING 60x4 MM
BSD-1900210156.A6
1900210156
|
£8.67
|
£10.41
|
|
|
135 - FLANGED BEARING
BSD-1615805033.A3
1615805033
|
-
|
|
|
|
136 - HEX SOCKET HEAD CAP SCREW M 8x50 DIN 912-8.8
BSD-2910140254.A4
2910140254
|
-
|
|
|
|
137 - HEX NUT DIN 934 M 8
BSD-2915011109.A5
2915011109
|
-
|
|
|
|
138 - SPRING LOCK WASHER B 8 DIN 127
BSD-2916680009.A140
2916680009
|
-
|
|
|
|
139 - TOOLHOLDER
BSD-1618597005.A4
1618597005
|
-
|
|
|
|
140 - DAMPING RING
BSD-1610306007.A2
1610306007
|
-
|
|
|
|
141 - DAMPING RING
BSD-1610206003.A1
1610206003
|
-
|
|
|
|
141 - PLAIN WASHER
BSD-1610103009.A2
1610103009
|
-
|
|
|
|
142 - FELT STRIP
BSD-1611005001.A1
1611005001
|
-
|
|
|
|
142 - BUSHING
BSD-1610501010.A0
1610501010
|
-
|
|
|
|
143 - RETAINING BRACKET
BSD-1618045011.A4
1618045011
|
-
|
|
|
|
143 - RETAINING BRACKET
BSD-1618045015.A1
1618045015
|
-
|
|
|
|
151 - GROOVED NAIL DIN 1476 3x10
BSD-2917721036.A1
2917721036
|
-
|
|
|
|
160 - ROUND-NOSED PLIERS
BSD-1617954000.A1
1617954000
|
-
|
|
|
|
161 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A200
1907950007
|
£5.30
|
£6.36
|
|
|
162 - CARBON-BRUSH SET
BSD-1617014101.A1
1617014101
|
-
|
|
|
|
163 - GREASE GUN
BSD-1615437500.A9
1615437500
|
-
|
|
|
|
164 - HOOK WRENCH
BSD-1907950562.A1
1907950562
|
-
|
|
|
|
165 - LIFTING PIN
BSD-1613101000.A1
1613101000
|
-
|
|
|
|
200 - SPRING STRUT
BSD-1618180000.A1
1618180000
|
-
|
|
|
|
201 - SUPPORT TUBE
BSD-1610760008.A5
1610760008
|
-
|
|
|
|
202 - CONTROL LEVER
BSD-1612123001.A1
1612123001
|
-
|
|
|
|
203 - COMPRESSION SPRING
BSD-1614615000.A1
1614615000
|
-
|
|
|
|
204 - SUPPORT TUBE
BSD-1610700012.A3
1610700012
|
-
|
|
|
|
205 - GUIDE TUBE
BSD-1610760009.A0
1610760009
|
-
|
|
|
|
206 - STUD BOLT
BSD-1613523002.A3
1613523002
|
-
|
|
|
|
207 - SLOTTED SPRING PIN
BSD-2917760179.A1
2917760179
|
-
|
|
|
|
208 - CLAMPING SADDLE
BSD-1618040002.A4
1618040002
|
-
|
|
|
|
209 - CLAMPING SADDLE
BSD-1618040001.A1
1618040001
|
-
|
|
|
|
210 - CLAMPING PIECE
BSD-1618040004.A1
1618040004
|
-
|
|
|
|
211 - INSULATING PLATE
BSD-1611035002.A1
1611035002
|
-
|
|
|
|
212 - GROOVED NAIL DIN 1477-4x10-ST
BSD-2917740094.A1
2917740094
|
-
|
|
|
|
213 - HEX SOCKET HEAD CAP SCREW M 12x70 DIN 912-10.9
BSD-2910150356.A3
2910150356
|
-
|
|
|
|
214 - SPRING LOCK WASHER
BSD-2916690009.A2
2916690009
|
-
|
|
|
|
215 - PIVOT PIN
BSD-1610700000.A2
1610700000
|
-
|
|
|
|
216 - SPLIT PIN DIN 94-5x36-ST
BSD-1904681650.A4
1904681650
|
-
|
|
|
|
217 - OFFSET SCREWDRIVER DIN 911 SW10
BSD-1907950009.A144
1907950009
|
£21.68
|
£26.01
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3053
160111A3H3
|
£2.61
|
£3.13
|
|
