2 - POLE SHOE 220V
BSD-1614220093.A0
1614220093
|
-
|
|
|
|
2/40 - TERMINAL LUG
BSD-1901250003.A0
1901250003
|
-
|
|
|
|
2/50 - BLADE TERMINAL
BSD-2601355011.A0
2601355011
|
-
|
|
|
|
4 - SWITCH
BSD-2607200110.A7
2607200110
|
-
|
|
|
|
5 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A508
1607000386
|
£21.52
|
£25.83
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A738
3600703011
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A51
1601302014
|
£2.61
|
£3.13
|
|
|
8 - NAMEPLATE
BSD-1611104001.A0
1611104001
|
-
|
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110465.A0
1611110465
|
-
|
|
|
|
12 - HOUSING COVER
BSD-1615500280.A10
1615500280
|
-
|
|
|
|
13 - GEAR HOUSING
BSD-1615806052.A0
1615806052
|
-
|
|
|
|
14 - HANDLE COVER
BSD-1615132024.A20
1615132024
|
-
|
|
|
|
15 - FAN
BSD-1616610052.A46
1616610052
|
-
|
|
|
|
17 - RUBBER RING
BSD-1610206017.A45
1610206017
|
-
|
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522005.A0
1610522005
|
-
|
|
|
|
20 - BEARING PEDESTAL
BSD-1615820087.A15
1615820087
|
-
|
|
|
|
21 - BEVEL GEAR Z=38
BSD-1616333013.A0
1616333013
|
-
|
|
|
|
24 - CRANKSHAFT
BSD-1613124023.A0
1613124023
|
-
|
|
|
|
25 - ECCENTRIC BOLT
BSD-1613180002.A0
1613180002
|
-
|
|
|
|
28 - SUPPRESSION FILTER
BSD-1617328020.A0
1617328020
|
-
|
|
|
|
30 - SHIM 0.2 MM
BSD-1610132004.A15
1610132004
|
-
|
|
|
|
31 - CONNECTING ROD
BSD-1612001030.A15
1612001030
|
-
|
|
|
|
34 - HAMMER PISTON
BSD-1618700051.A15
1618700051
|
-
|
|
|
|
35 - GUIDE TUBE
BSD-1610408001.A0
1610408001
|
-
|
|
|
|
36 - STRIKER
BSD-1618710045.A0
1618710045
|
-
|
|
|
|
37 - SUPPORTING DISC 2.0 MM
BSD-1610102021.A0
1610102021
|
-
|
|
|
|
38 - DAMPING SLEEVE
BSD-1610506016.A0
1610506016
|
-
|
|
|
|
39 - DAMPING RING
BSD-1610290005.A0
1610290005
|
-
|
|
|
|
40 - GUIDE BUSHING
BSD-1610326010.A0
1610326010
|
-
|
|
|
|
42 - STRIKER PIN
BSD-1613124033.A0
1613124033
|
-
|
|
|
|
43 - TOOLHOLDER
BSD-1618597038.A0
1618597038
|
-
|
|
|
|
46 - STRAIGHT PIN
BSD-1613101004.A0
1613101004
|
-
|
|
|
|
50 - BRUSH HOLDER
BSD-1604336017.A91
1604336017
|
£7.36
|
£8.83
|
|
|
51 - SPIRAL SPRING
BSD-1604652006.A232
1604652006
|
£1.75
|
£2.10
|
|
|
52 - HOUSING COVER
BSD-1615500281.A24
1615500281
|
-
|
|
|
|
58 - SEALING FRAME
BSD-1611015025.A0
1611015025
|
-
|
|
|
|
64 - O-RING 45x2.5MM
BSD-1900210145.A25
1900210145
|
£1.75
|
£2.10
|
|
|
65 - INTERMEDIATE RING
BSD-1610300051.A21
1610300051
|
-
|
|
|
|
68 - DAMPING RING
BSD-1610210034.A0
1610210034
|
£1.75
|
£2.10
|
|
|
69 - O-RING 18.0x3.0 MM
BSD-1610210058.A164
1610210058
|
£2.61
|
£3.13
|
|
|
72 - ROTARY SHAFT LIP SEAL dia13.8xdia26x7.5 MM
BSD-1610283014.A31
1610283014
|
-
|
|
|
|
73 - O-RING 32.0x5.5 MM
BSD-1610210059.A0
1610210059
|
-
|
|
|
|
75 - NEEDLE BEARING dia14xdia22x13 MM
BSD-1610910056.A42
1610910056
|
-
|
|
|
|
76 - NEEDLE BEARING
BSD-1610910069.A15
1610910069
|
-
|
|
|
|
77 - NEEDLE BEARING dia8xdia12x10 MM
BSD-1610910057.A40
1610910057
|
£2.80
|
£3.36
|
|
|
79 - GROOVE BALL BEARING DIN 625 6000J C5
BSD-1900900278.A1
1900900278
|
-
|
|
|
|
80 - GROOVE BALL BEARING 10x26x8
BSD-1610905002.A25
1610905002
|
-
|
|
|
|
81 - LUBRICATING FELT
BSD-1610205003.A19
1610205003
|
-
|
|
|
|
83 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2952
2603410001
|
£1.75
|
£2.10
|
|
|
84 - TAPPING SCREW B 4.8x68 MM
BSD-1613412001.A17
1613412001
|
£1.75
|
£2.10
|
|
|
85 - TAPPING SCREW B4.8x45 MM
BSD-1603412005.A4
1603412005
|
-
|
|
|
|
86 - TAPPING SCREW DIN 7971-BZ4.8x32
BSD-2910211037.A125
2910211037
|
£1.75
|
£2.10
|
|
|
87 - TAPPING SCREW DIN 7971-B 3.9x22
BSD-2910211221.A7
2910211221
|
-
|
|
|
|
88 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A453
2910211018
|
£1.75
|
£2.10
|
|
|
89 - TAPPING SCREW DIN 7971-BZ3.9x9.5
BSD-2910211017.A143
2910211017
|
-
|
|
|
|
90 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A100
2910141166
|
£1.75
|
£2.10
|
|
|
92 - COUNTERSUNK-HEAD SCREW
BSD-1613421000.A0
1613421000
|
-
|
|
|
|
94 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A85
2910021118
|
£1.75
|
£2.10
|
|
|
95 - SOCKET HEAD CAP SCREW DIN 84-BM4x30-8.8
BSD-2910021134.A162
2910021134
|
£1.75
|
£2.10
|
|
|
99 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x40-8.8
BSD-2910141170.A107
2910141170
|
£2.61
|
£3.13
|
|
|
100 - TAPPING SCREW BZ 3.9x19 DIN 7972
BSD-2910601120.A25
2910601120
|
-
|
|
|
|
102 - STRAIGHT PIN RIKO 6325-8m6x40
BSD-2917550184.A0
2917550184
|
-
|
|
|
|
103 - COMPRESSION SPRING
BSD-1614616004.A6
1614616004
|
-
|
|
|
|
104 - PROTECTION SLEEVE
BSD-1610499004.A31
1610499004
|
-
|
|
|
|
105 - RUBBER RING dia42xdia4.5x10 MM
BSD-1610206016.A0
1610206016
|
£1.75
|
£2.10
|
|
|
108 - REFERENCE PLATE
BSD-1611110466.A0
1611110466
|
-
|
|
|
|
112 - PROTECTIVE CAP
BSD-1610590000.A0
1610590000
|
-
|
|
|
|
113 - RETAINING RING 26 DIN 9045
BSD-2916601014.A52
2916601014
|
-
|
|
|
|
120 - AUXILIARY HANDLE M8
BSD-1612025019.A126
1612025019
|
£6.52
|
£7.83
|
|
|
121 - SUPPORT CLAMP
BSD-1618040077.A40
1618040077
|
-
|
|
|
|
122 - STUD BOLT M8
BSD-1613521001.A1
1613521001
|
£5.58
|
£6.70
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316003.A7
1611316003
|
£2.61
|
£3.13
|
|
|
124 - STRAIGHT PIN
BSD-1613100012.A5
1613100012
|
£2.61
|
£3.13
|
|
|
130 - STICKER
BSD-1601110265.A359
1601110265
|
-
|
|
|
|
135 - REFERENCE PLATE
BSD-1611110387.A52
1611110387
|
£1.75
|
£2.10
|
|
|
650 - CARRYING CASE
BSD-1615438091.A0
1615438091
|
-
|
|
|
|
802 - CARBON-BRUSH SET
BSD-1617014106.A0
1617014106
|
£21.52
|
£25.83
|
|
|
810 - PARTS SET
BSD-1617000082.A8
1617000082
|
-
|
|
|
|
813 - AUXILIARY HANDLE
BSD-1612025020.A43
1612025020
|
£26.12
|
£31.35
|
|
|
830 - ARMATURE 220-230V
BSD-1614010027.A4
1614010027
|
-
|
|
|
