5 - COMPRESSION SPRING
BSD-2604611037.A28
2604611037
|
-
|
|
|
6 - PRESSURE SPINDLE
BSD-2603126006.A17
2603126006
|
-
|
|
|
7 - NEEDLE BEARING
BSD-2600914013.A21
2600914013
|
£5.58
|
£6.70
|
|
8 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A799
2600910001
|
£4.26
|
£5.11
|
|
9 - GROOVED NAIL
BSD-3603133000.A364
3603133000
|
£2.61
|
£3.13
|
|
10 - DEPTH-GAUGE
BSD-2600460007.A28
2600460007
|
-
|
|
|
10 - DEPTH-GAUGE
BSD-2600460008.A3
2600460008
|
£16.96
|
£20.35
|
|
10 - DEPTH-GAUGE
BSD-2600460009.A22
2600460009
|
-
|
|
|
11 - STOP SPRING
BSD-2604601012.A31
2604601012
|
£2.52
|
£3.02
|
|
12 - BUSHING
BSD-2600499002.A20
2600499002
|
-
|
|
|
14 - SEAL RING
BSD-2600283012.A1
2600283012
|
£2.80
|
£3.36
|
|
16 - MANUFACTURER'S NAMEPLATE
BSD-2601110099.A37
2601110099
|
-
|
|
|
17 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A712
2600914010
|
£2.80
|
£3.36
|
|
19 - SHIM 0.3 MM
BSD-2600100607.A705
2600100607
|
£1.75
|
£2.10
|
|
20 - BALL BEARING 8x22x7
BSD-1900905029.A286
1900905029
|
£21.52
|
£25.83
|
|
21 - SEAL BUSHING
BSD-2600300049.A79
2600300049
|
-
|
|
|
22 - FELT DISC
BSD-2600108000.A207
2600108000
|
-
|
|
|
23 - CUPPED WASHER
BSD-2600500030.A71
2600500030
|
-
|
|
|
24 - SPRING RETAINING RING
BSD-2600119000.A68
2600119000
|
£1.75
|
£2.10
|
|
25 - STICKER
BSD-2601110171.A1
2601110171
|
-
|
|
|
26 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A769
2603490023
|
£1.75
|
£2.10
|
|
27 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A97
2916690003
|
£1.75
|
£2.10
|
|
28 - SCREW AND WASHER ASSEMBLY DIN 84-BM 4x35-Z4-8.8
BSD-2914501027.A53
2914501027
|
-
|
|
|
29 - COVER DISC
BSD-2601328041.A29
2601328041
|
-
|
|
|
32 - CHANGE-OVER SWITCH
BSD-2607200114.A19
2607200114
|
-
|
|
|
33 - ARMATURE 220V
BSD-2604010533.A15
2604010533
|
-
|
|
|
34 - FIELD 220V
BSD-2604222302.A1
2604222302
|
-
|
|
|
36 - HOUSING COVER
BSD-2605132042.A11
2605132042
|
-
|
|
|
36 - HOUSING COVER
BSD-2605132017.A43
2605132017
|
-
|
|
|
37 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A718
2912401020
|
£2.16
|
£2.59
|
|
38 - BALL BEARING 7x22x7
BSD-1900905018.A890
1900905018
|
£18.96
|
£22.75
|
|
40 - ON-OFF SWITCH
BSD-2607200065.A36
2607200065
|
-
|
|
|
41 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A438
2603410023
|
-
|
|
|
42 - SUPPRESSION CAPACITOR
BSD-2607329102.A19
2607329102
|
-
|
|
|
43 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A318
2910611019
|
£2.80
|
£3.36
|
|
44 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1247
2600703012
|
£2.80
|
£3.36
|
|
46 - CABLE CLIP
BSD-2601035001.A374
2601035001
|
£1.75
|
£2.10
|
|
47 - TAPPING SCREW 2.2x6.5
BSD-2603435016.A70
2603435016
|
-
|
|
|
48 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A184
2914501011
|
£1.75
|
£2.10
|
|
49 - SPIRAL SPRING
BSD-2604652003.A31
2604652003
|
-
|
|
|
52 - SCREWDRIVER BLADE NR.2.1/4
BSD-1608521004.A18
1608521004
|
-
|
|
|
53 - RETAINING RING
BSD-2604601004.A558
2604601004
|
£1.75
|
£2.10
|
|
55 - SUPPRESSOR BOX
BSD-2604465026.A51
2604465026
|
-
|
|
|
56 - SUPPRESSOR BOX
BSD-2604465027.A14
2604465027
|
-
|
|
|
57 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A358
1903201042
|
£2.16
|
£2.59
|
|
58 - COMPRESSION SPRING
BSD-2604611026.A218
2604611026
|
-
|
|
|
61 - SHIM
BSD-2600150004.A168
2600150004
|
£2.16
|
£2.59
|
|
62 - SHIM 0.3 MM
BSD-2600101023.A159
2600101023
|
£1.75
|
£2.10
|
|
62 - SHIM 0.2 MM
BSD-2600101022.A461
2600101022
|
£1.75
|
£2.10
|
|
62 - SHIM 0.5 MM
BSD-2600101020.A188
2600101020
|
£1.75
|
£2.10
|
|
63 - CABLE
BSD-2604411524.A9
2604411524
|
-
|
|
|
65 - STICKER
BSD-2601110230.A95
2601110230
|
-
|
|
|
67 - CENTERING SLEEVE
BSD-2600409013.A41
2600409013
|
-
|
|
|
68 - FAN
BSD-2606610021.A30
2606610021
|
-
|
|
|
69 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A341
1900452012
|
£1.75
|
£2.10
|
|
95 - STICKER
BSD-1601110265.A157
1601110265
|
-
|
|
|
800 - MOTOR HOUSING
BSD-2605104954.A56
2605104954
|
-
|
|
|
801 - GEAR HOUSING
BSD-2605806957.A18
2605806957
|
-
|
|
|
802 - BEARING FLANGE
BSD-2605700925.A11
2605700925
|
-
|
|
|
803 - TOOTHED SHAFT Z=25/41
BSD-2606311901.A10
2606311901
|
-
|
|
|
804 - COUPLING HALF Z= 24
BSD-2606490904.A6
2606490904
|
-
|
|
|
806 - COUPLING HALF
BSD-2606490905.A6
2606490905
|
-
|
|
|
811 - CARBON-BRUSH SET
BSD-2604320902.A161
2604320902
|
-
|
|
|
835 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A34
1607000227
|
£23.86
|
£28.63
|
|
888 - NAMEPLATE
BSD-160111A3H3.A795
160111A3H3
|
£2.61
|
£3.13
|
|
