1 - MOTOR HOUSING
BSD-3605108145.A36
3605108145
|
£27.23
|
£32.68
|
|
|
2 - POLE SHOE 100V
BSD-1604220180.A0
1604220180
|
-
|
|
|
|
2/4 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A341
1901350003
|
£1.75
|
£2.10
|
|
|
3 - ARMATURE 100-110V
BSD-1604010144.A0
1604010144
|
-
|
|
|
|
4 - SWITCH
BSD-1607200076.A14
1607200076
|
£120.11
|
£144.13
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1384
3600703011
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A887
1601302014
|
£2.61
|
£3.13
|
|
|
9 - STICKER
BSD-1601110046.A45
1601110046
|
£1.75
|
£2.10
|
|
|
11 - SUPPRESSION CAPACITOR
BSD-1607328024.A6
1607328024
|
-
|
|
|
|
11/2 - TERMINAL LUG
BSD-1601353003.A223
1601353003
|
-
|
|
|
|
12 - O-RING 66.0x3.0 MM
BSD-1600210005.A134
1600210005
|
£2.80
|
£3.36
|
|
|
18 - SPIRAL SPRING
BSD-1604652006.A75
1604652006
|
£1.75
|
£2.10
|
|
|
19 - TAB WASHER
BSD-1601030022.A5
1601030022
|
£1.75
|
£2.10
|
|
|
20 - INTERMEDIATE RING
BSD-1600502011.A248
1600502011
|
£2.61
|
£3.13
|
|
|
21 - BALL BEARING 7x19x6
BSD-2600905032.A856
2600905032
|
£5.30
|
£6.36
|
|
|
22 - SEALING CAP
BSD-3605500063.A23
3605500063
|
£4.26
|
£5.11
|
|
|
23 - AIR-DEFLECTOR RING
BSD-1600502015.A41
1600502015
|
-
|
|
|
|
24 - INTERMEDIATE RING
BSD-1600202034.A26
1600202034
|
-
|
|
|
|
25 - INTERMEDIATE RING
BSD-1600206018.A24
1600206018
|
-
|
|
|
|
26 - INTERMEDIATE HOUSING
BSD-1605820198.A2
1605820198
|
-
|
|
|
|
27 - RETAINING RING 35 DIN 9045
BSD-2916600018.A4
2916600018
|
£1.75
|
£2.10
|
|
|
28 - GROOVE BALL BEARING
BSD-1600905003.A18
1600905003
|
-
|
|
|
|
29 - FELT DISC
BSD-1600108003.A121
1600108003
|
£1.32
|
£1.58
|
|
|
30 - NEEDLE BEARING
BSD-1600910013.A196
1600910013
|
£5.58
|
£6.70
|
|
|
31 - CYLINDRICAL GEAR Z=50
BSD-1606317078.A17
1606317078
|
£31.64
|
£37.97
|
|
|
32/2 - STRAIGHT PIN 5 H 8x18 DIN 7
BSD-2917500121.A160
2917500121
|
£1.75
|
£2.10
|
|
|
33 - SHIM 0.5 MM
BSD-1600102003.A24
1600102003
|
£1.75
|
£2.10
|
|
|
36 - DRILLING SPINDLE
BSD-3603523053.A6
3603523053
|
£40.80
|
£48.96
|
|
|
37 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A295
2916650006
|
£1.75
|
£2.10
|
|
|
38 - SHIM 0.5 MM
BSD-1600100631.A325
1600100631
|
£1.75
|
£2.10
|
|
|
39 - SPINDLE WITH GEAR Z=9/33
BSD-1606328103.A9
1606328103
|
£48.38
|
£58.06
|
|
|
40 - GROOVE BALL BEARING 15x32x9
BSD-1900905162.A41
1900905162
|
£18.96
|
£22.75
|
|
|
42 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A379
1613435009
|
£1.75
|
£2.10
|
|
|
43 - TORX OVAL-HEAD SCREW
BSD-2914201527.A39
2914201527
|
£2.16
|
£2.59
|
|
|
44 - TAPPING SCREW B4.8x50 MM
BSD-1603435012.A4
1603435012
|
£1.75
|
£2.10
|
|
|
45 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A88
2910211011
|
£1.75
|
£2.10
|
|
|
46 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1603
2910021118
|
£1.75
|
£2.10
|
|
|
47 - CONNECTING CABLE L=290 MM
BSD-1604445006.A70
1604445006
|
£5.58
|
£6.70
|
|
|
47/2 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A339
1901350003
|
£1.75
|
£2.10
|
|
|
48 - TAPPING SCREW DIN 7971-B 3.9x19
BSD-2910211220.A112
2910211220
|
-
|
|
|
|
49 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A240
2910021116
|
£2.16
|
£2.59
|
|
|
50 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A436
2915011005
|
£1.75
|
£2.10
|
|
|
51 - NEEDLE BEARING
BSD-1600910013.A193
1600910013
|
£5.58
|
£6.70
|
|
|
52 - REFERENCE PLATE
BSD-1601110120.A4
1601110120
|
-
|
|
|
|
53 - RETAINING SNAP RING
BSD-1610500004.A36
1610500004
|
-
|
|
|
|
54 - STICKER
BSD-2601110041.A230
2601110041
|
-
|
|
|
|
650 - AUXILIARY HANDLE dia43 MM
BSD-3602025021.A41
3602025021
|
£40.80
|
£48.96
|
|
|
650/1 - AUXILIARY HANDLE M14
BSD-1602025022.A832
1602025022
|
£13.41
|
£16.09
|
|
|
650/1 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A30
1602025030
|
£18.96
|
£22.75
|
|
|
650/2 - SUPPORT CLAMP
BSD-1618040077.A186
1618040077
|
-
|
|
|
|
650/3 - STUD BOLT M8
BSD-1613521001.A134
1613521001
|
£5.58
|
£6.70
|
|
|
650/4 - CLAMPING BAND dia43 MM
BSD-3601038048.A32
3601038048
|
£18.96
|
£22.75
|
|
|
650/5 - STRAIGHT PIN
BSD-1613100012.A211
1613100012
|
£2.61
|
£3.13
|
|
|
650/8 - HANDLE BAR
BSD-3602025022.A10
3602025022
|
£18.96
|
£22.75
|
|
|
651 - KEY CHUCK dia 1.5-13 MM.1/2
BSD-1608571048.A2
1608571048
|
-
|
|
|
|
651/8 - CHUCK WRENCH SG2
BSD-2607950007.A1105
2607950007
|
£6.52
|
£7.83
|
|
|
652 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001008.A28
1613001008
|
£8.67
|
£10.41
|
|
|
800 - HANDLE
BSD-3605133012.A69
3605133012
|
-
|
|
|
|
801 - CARBON-BRUSH SET
BSD-1607014126.A11
1607014126
|
£16.41
|
£19.69
|
|
|
805 - POWER SUPPLY CORD
BSD-3607030489.A79
3607030489
|
£31.64
|
£37.97
|
|
|
817 - BRUSH HOLDER
BSD-1604336017.A110
1604336017
|
£7.36
|
£8.83
|
|
|
832 - SPINDLE HOUSING
BSD-3605806146.A13
3605806146
|
£63.50
|
£76.20
|
|
|
835 - RETAINING SNAP RING
BSD-3607030355.A110
3607030355
|
£18.96
|
£22.75
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2172
160111A3H3
|
£2.61
|
£3.13
|
|
