1 - HOUSING SECTION
BSD-2605104342.A14
2605104342
|
£13.41
|
£16.09
|
|
|
2 - FIELD 220-230V
BSD-2604220506.A4
2604220506
|
-
|
|
|
|
3 - ARMATURE 230V
BSD-2604010838.A2
2604010838
|
-
|
|
|
|
3/60 - FAN
BSD-2606610027.A195
2606610027
|
£2.80
|
£3.36
|
|
|
4 - ON-OFF SWITCH
BSD-2607200276.A3
2607200276
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 240V 2.65m 2 x 1.0mm H05VV-F
BSD-2604460106.A0
2604460106
|
-
|
|
|
|
6 - GROMMET dia8.8 MM
BSD-2600707061.A392
2600707061
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia7x8.4 MM
BSD-2600707062.A0
2600707062
|
£1.75
|
£2.10
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1175
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2609130059.A3
2609130059
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-2607329128.A1
2607329128
|
-
|
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A732
2600905032
|
£5.30
|
£6.36
|
|
|
14 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A512
2600917003
|
£2.80
|
£3.36
|
|
|
16 - BRUSH PLATE
BSD-2605807039.A7
2605807039
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1054
2603410001
|
£1.75
|
£2.10
|
|
|
19 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A50
2910611019
|
£2.80
|
£3.36
|
|
|
29 - O-RING 5.0x1.5 MM
BSD-1900210000.A591
1900210000
|
£1.75
|
£2.10
|
|
|
30 - SPACER RING
BSD-2600209004.A42
2600209004
|
-
|
|
|
|
32 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A128
2603490024
|
£1.75
|
£2.10
|
|
|
33 - SEALING CAP
BSD-2605500111.A1
2605500111
|
-
|
|
|
|
36 - NEEDLE BEARING
BSD-2600917004.A10
2600917004
|
£3.72
|
£4.47
|
|
|
43 - CYLINDRICAL GEAR Z=55
BSD-2606319060.A3
2606319060
|
-
|
|
|
|
44 - GROOVE BALL BEARING 6200-2Z DIN 625
BSD-1900905232.A61
1900905232
|
£21.68
|
£26.01
|
|
|
45 - SPRING RETAINING RING DIN 471-10x1MM-FSt
BSD-2916650001.A400
2916650001
|
£2.61
|
£3.13
|
|
|
46 - CONNECTING CABLE
BSD-2604448152.A5
2604448152
|
-
|
|
|
|
47 - CONNECTING CABLE
BSD-2604448153.A15
2604448153
|
-
|
|
|
|
55 - CONNECTING CABLE L=52MM
BSD-2604448016.A38
2604448016
|
£1.75
|
£2.10
|
|
|
56 - CONNECTING CABLE L=88 MM
BSD-2604448034.A357
2604448034
|
£1.75
|
£2.10
|
|
|
740 - KEY CHUCK dia 1-10 MM. 3/8
BSD-1608571047.A33
1608571047
|
-
|
|
|
|
740/800 - CHUCK WRENCH SG2
BSD-2607950007.A1011
2607950007
|
£6.52
|
£7.83
|
|
|
810 - CARBON-BRUSH SET
BSD-2607014004.A17
2607014004
|
-
|
|
|
|
825 - TAPPING SCREW DIN 7981-B2.9x16-C-H
BSD-2910611007.A73
2910611007
|
£1.75
|
£2.10
|
|
|
828 - TAPPING SCREW DIN 7981-ST3.9x19-C-H
BSD-2910611020.A485
2910611020
|
£1.75
|
£2.10
|
|
|
831 - BEARING BRACKET
BSD-2605807922.A6
2605807922
|
-
|
|
|
|
841 - DRILLING SPINDLE 3/8 - 24 UNF 2A
BSD-2606135916.A2
2606135916
|
£27.23
|
£32.68
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2331
160111A3H3
|
£2.61
|
£3.13
|
|
