1 - HOUSING SECTION
BSD-2605104711.A6
2605104711
|
£31.64
|
£37.97
|
|
|
2 - FIELD 100-115V
BSD-2604220596.A0
2604220596
|
£14.75
|
£17.70
|
|
|
3 - ARMATURE 110-115V
BSD-2604011287.A1
2604011287
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200543.A0
2607200543
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 110V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460207.A24
2604460207
|
£18.96
|
£22.75
|
|
|
6 - GROMMET dia6.2-dia6.9x90 MM
BSD-2600707066.A173
2600707066
|
£2.48
|
£2.97
|
|
|
9 - MANUFACTURER'S NAMEPLATE GSB 16 RE
BSD-2601116655.A1
2601116655
|
£3.72
|
£4.47
|
|
|
16 - BRUSH PLATE
BSD-2604337115.A6
2604337115
|
-
|
|
|
|
20 - REFERENCE PLATE
BSD-2601117427.A1
2601117427
|
-
|
|
|
|
24 - O-RING 5.0x1.5 MM
BSD-1900210000.A154
1900210000
|
£1.75
|
£2.10
|
|
|
25 - CHANGE-OVER SWITCH
BSD-2602098008.A81
2602098008
|
£1.75
|
£2.10
|
|
|
27 - DAMPING ELEMENT
BSD-2603239024.A90
2603239024
|
£1.75
|
£2.10
|
|
|
28 - HANDLE COVER
BSD-2608040177.A25
2608040177
|
£5.87
|
£7.04
|
|
|
53 - CONTACT STRAP
BSD-2601329043.A113
2601329043
|
£1.32
|
£1.58
|
|
|
55 - PVC-INSULATED CABLE L=95 MM
BSD-1614431025.A192
1614431025
|
£2.61
|
£3.13
|
|
|
56 - PVC-INSULATED CABLE L=120 MM
BSD-2604448228.A21
2604448228
|
£2.16
|
£2.59
|
|
|
654 - AUXILIARY HANDLE dia43 MM
BSD-2602025118.A94
2602025118
|
£14.91
|
£17.89
|
|
|
655 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A463
1613001009
|
£3.72
|
£4.47
|
|
|
808 - MARKING PLATE
BSD-2601117537.A0
2601117537
|
-
|
|
|
|
813 - BALL BEARING 7x19x6
BSD-2600905032.A2161
2600905032
|
£5.30
|
£6.36
|
|
|
816 - BRUSH HOLDER
BSD-1607000CJ1.A81
1607000CJ1
|
£5.87
|
£7.04
|
|
|
819 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A278
2910611006
|
£1.75
|
£2.10
|
|
|
826 - TAPPING SCREW DIN 7981-ST3.9x19-C-H
BSD-2910611020.A214
2910611020
|
£1.75
|
£2.10
|
|
|
831 - DRILLING SPINDLE
BSD-2606135932.A3
2606135932
|
-
|
|
|
|
833 - BEARING BRACKET
BSD-2605807937.A12
2605807937
|
£21.52
|
£25.83
|
|
|
836 - GEAR COVER
BSD-2605808084.A9
2605808084
|
£3.72
|
£4.47
|
|
|
837 - FLANGED BEARING
BSD-2605805009.A2
2605805009
|
-
|
|
|
|
838 - INDEXING DISK
BSD-2601990027.A11
2601990027
|
£1.75
|
£2.10
|
|
|
839 - PRESSURE PLATE
BSD-2601074004.A4
2601074004
|
£1.75
|
£2.10
|
|
|
840 - BALL DIN 5401-5 G28
BSD-1903230009.A827
1903230009
|
£1.75
|
£2.10
|
|
|
841 - COMPRESSION SPRING
BSD-2604616006.A322
2604616006
|
£1.75
|
£2.10
|
|
|
842 - SHIM 0.3 MM
BSD-2600101047.A188
2600101047
|
£1.75
|
£2.10
|
|
|
846 - KEY CHUCK
BSD-2608571065.A3
2608571065
|
£37.27
|
£44.72
|
|
|
847 - FRAME
BSD-2608040120.A160
2608040120
|
£2.61
|
£3.13
|
|
|
848 - CHUCK WRENCH SG2
BSD-2607950007.A15
2607950007
|
£6.52
|
£7.83
|
|
|
849 - FAN
BSD-2606610093.A75
2606610093
|
£2.80
|
£3.36
|
|
|
890 - FASTENING PARTS KIT
BSD-2607001305.A252
2607001305
|
£4.26
|
£5.11
|
|
|
891 - CROSS RECESSED-HEAD SCREW M3x5
BSD-2603410046.A80
2603410046
|
£2.16
|
£2.59
|
|
