1 - HOUSING SECTION
BSD-2605104711.A7
2605104711
|
£31.64
|
£37.97
|
|
2 - FIELD 230-240V
BSD-2604220688.A3
2604220688
|
£27.23
|
£32.68
|
|
3 - ARMATURE 230-240V
BSD-2604011254.A4
2604011254
|
£37.72
|
£45.27
|
|
4 - SWITCH
BSD-2607200556.A109
2607200556
|
£27.23
|
£32.68
|
|
5 - POWER SUPPLY CORD GB 230V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460147.A127
2604460147
|
£16.41
|
£19.69
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A57
2600703017
|
£2.61
|
£3.13
|
|
9 - MANUFACTURER'S NAMEPLATE GSB 16 RE
BSD-2601116655.A6
2601116655
|
£3.72
|
£4.47
|
|
16 - BRUSH PLATE
BSD-2604337115.A7
2604337115
|
-
|
|
|
20 - REFERENCE PLATE
BSD-2601117427.A5
2601117427
|
-
|
|
|
24 - O-RING 5.0x1.5 MM
BSD-1900210000.A159
1900210000
|
£1.75
|
£2.10
|
|
25 - CHANGE-OVER SWITCH
BSD-2602098008.A77
2602098008
|
£1.75
|
£2.10
|
|
27 - DAMPING ELEMENT
BSD-2603239024.A93
2603239024
|
£1.75
|
£2.10
|
|
28 - HANDLE COVER
BSD-2608040177.A27
2608040177
|
£5.87
|
£7.04
|
|
53 - CONTACT STRAP
BSD-2601329043.A119
2601329043
|
£1.32
|
£1.58
|
|
55 - PVC-INSULATED CABLE L=95 MM
BSD-1614431025.A188
1614431025
|
£2.61
|
£3.13
|
|
56 - PVC-INSULATED CABLE L=120 MM
BSD-2604448228.A18
2604448228
|
£2.16
|
£2.59
|
|
654 - AUXILIARY HANDLE dia43 MM
BSD-2602025118.A103
2602025118
|
£14.91
|
£17.89
|
|
655 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A467
1613001009
|
£3.72
|
£4.47
|
|
808 - MARKING PLATE
BSD-2601117496.A0
2601117496
|
-
|
|
|
813 - BALL BEARING 7x19x6
BSD-2600905032.A2169
2600905032
|
£5.30
|
£6.36
|
|
816 - CARBON-BRUSH SET
BSD-2604321946.A9
2604321946
|
£10.82
|
£12.99
|
|
819 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A280
2910611006
|
£1.75
|
£2.10
|
|
826 - TAPPING SCREW DIN 7981-ST3.9x19-C-H
BSD-2910611020.A212
2910611020
|
£1.75
|
£2.10
|
|
830 - DRILLING SPINDLE 1/2
BSD-2606135931.A2
2606135931
|
-
|
|
|
831 - CARRIER 1.0 M
BSD-2606320083.A11
2606320083
|
£14.91
|
£17.89
|
|
832 - CATCH DISK
BSD-2600190078.A29
2600190078
|
£5.87
|
£7.04
|
|
833 - BEARING BRACKET
BSD-2605807937.A17
2605807937
|
£21.52
|
£25.83
|
|
836 - GEAR COVER
BSD-2605808084.A4
2605808084
|
£3.72
|
£4.47
|
|
837 - FLANGED BEARING
BSD-2605805009.A6
2605805009
|
-
|
|
|
838 - INDEXING DISK
BSD-2601990027.A4
2601990027
|
£1.75
|
£2.10
|
|
839 - PRESSURE PLATE
BSD-2601074004.A7
2601074004
|
£1.75
|
£2.10
|
|
840 - BALL DIN 5401-5 G28
BSD-1903230009.A833
1903230009
|
£1.75
|
£2.10
|
|
841 - COMPRESSION SPRING
BSD-2604616006.A328
2604616006
|
£1.75
|
£2.10
|
|
842 - SHIM 0.3 MM
BSD-2600101047.A192
2600101047
|
£1.75
|
£2.10
|
|
844 - ROLLER BODY
BSD-2602329038.A10
2602329038
|
£1.75
|
£2.10
|
|
846 - KEYLESS CHUCK
BSD-2608572142.A20
2608572142
|
£52.15
|
£62.58
|
|
847 - FRAME
BSD-2608040120.A155
2608040120
|
£2.61
|
£3.13
|
|
849 - RETAINING RING DIN 7993-A8
BSD-2916540005.A46
2916540005
|
£1.75
|
£2.10
|
|
870 - FAN
BSD-2606610093.A69
2606610093
|
£2.80
|
£3.36
|
|
890 - FASTENING PARTS KIT
BSD-2607001305.A258
2607001305
|
£4.26
|
£5.11
|
|
891 - CROSS RECESSED-HEAD SCREW M3x5
BSD-2603410046.A78
2603410046
|
£2.16
|
£2.59
|
|
895 - RETAINING SNAP RING
BSD-2600290044.A4
2600290044
|
£3.80
|
£4.56
|
|
