2 - DRILLING SPINDLE 1/2
BSD-2606135026.A20
2606135026
|
-
|
|
|
|
2 - DRILLING SPINDLE 1/2
BSD-2606135010.A26
2606135010
|
-
|
|
|
|
3 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A260
1900905163
|
£11.30
|
£13.56
|
|
|
4 - GROOVE BALL BEARING
BSD-2600900006.A25
2600900006
|
-
|
|
|
|
5 - SHIM 0.5 MM
BSD-2600101616.A150
2600101616
|
-
|
|
|
|
5 - SUPPORTING DISC 2.5 MM
BSD-1610101617.A35
1610101617
|
-
|
|
|
|
6 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A272
2600917003
|
£2.80
|
£3.36
|
|
|
7 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A226
2916660014
|
£1.75
|
£2.10
|
|
|
8 - COMPRESSION SPRING
BSD-2604616002.A162
2604616002
|
£1.75
|
£2.10
|
|
|
10 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A211
2916650008
|
£1.75
|
£2.10
|
|
|
11 - RETAINING WASHER
BSD-2600101671.A194
2600101671
|
£1.75
|
£2.10
|
|
|
12 - FLAT KEY
BSD-2602300027.A19
2602300027
|
-
|
|
|
|
13 - CYLINDRICAL GEAR Z=43
BSD-2606317038.A18
2606317038
|
-
|
|
|
|
14 - CYLINDRICAL GEAR Z=48
BSD-2606317036.A19
2606317036
|
-
|
|
|
|
15 - CYLINDRICAL GEAR Z=36
BSD-2606317037.A117
2606317037
|
-
|
|
|
|
16 - CATCH DISK
BSD-2600190052.A28
2600190052
|
£7.78
|
£9.33
|
|
|
16 - LOCATING WASHER
BSD-2600190031.A7
2600190031
|
-
|
|
|
|
17 - CYLINDRICAL GEAR Z=15
BSD-2606317039.A21
2606317039
|
-
|
|
|
|
19 - SPRING RETAINING RING DIN 471-8x0.8 FSt
BSD-2916640005.A140
2916640005
|
£1.75
|
£2.10
|
|
|
20 - SHIM WASHER 0.2 MM
BSD-2600000012.A188
2600000012
|
£1.75
|
£2.10
|
|
|
20 - SHIM WASHER 0.3 MM
BSD-2600000013.A0
2600000013
|
-
|
|
|
|
20 - SHIM WASHER 0.5 MM
BSD-2600000014.A185
2600000014
|
£1.75
|
£2.10
|
|
|
20 - SHIM WASHER 0.1 MM
BSD-2600000018.A28
2600000018
|
-
|
|
|
|
21 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A13
1903230010
|
£1.75
|
£2.10
|
|
|
22 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A110
2600914010
|
£2.80
|
£3.36
|
|
|
24 - SHIM 0.3 MM
BSD-2600100607.A170
2600100607
|
£1.75
|
£2.10
|
|
|
27 - SHIM 0.5 MM
BSD-2600100682.A36
2600100682
|
-
|
|
|
|
27 - SHIM 0.3 MM
BSD-2600100683.A28
2600100683
|
-
|
|
|
|
27 - SHIM 0.2 MM
BSD-2600100684.A33
2600100684
|
-
|
|
|
|
28 - DISC SPRING
BSD-2600550008.A131
2600550008
|
£1.75
|
£2.10
|
|
|
29 - COVER DISC
BSD-2600114001.A41
2600114001
|
-
|
|
|
|
30 - LOCKING WASHER
BSD-2600116001.A50
2600116001
|
-
|
|
|
|
31 - TOOTHED RACK
BSD-2603070011.A9
2603070011
|
-
|
|
|
|
32 - FORK LEVER
BSD-2602033003.A26
2602033003
|
-
|
|
|
|
33 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A21
2914501011
|
£1.75
|
£2.10
|
|
|
34 - COMPRESSION SPRING
BSD-2604615010.A9
2604615010
|
-
|
|
|
|
35 - ROTARY KNOB
BSD-2602026034.A9
2602026034
|
-
|
|
|
|
36 - LOCKING WASHER DIN 6799-7-FSt
BSD-2916080910.A242
2916080910
|
£2.16
|
£2.59
|
|
|
37 - SHIM 0.5 MM
BSD-2600101612.A278
2600101612
|
£1.75
|
£2.10
|
|
|
38 - HEADLESS SCREW 74 MM
BSD-2603435019.A50
2603435019
|
-
|
|
|
|
39 - TAPPING SCREW 79 MM
BSD-2603435012.A43
2603435012
|
-
|
|
|
|
41 - PLUG
BSD-2600591002.A19
2600591002
|
-
|
|
|
|
43 - LOCATING WASHER
BSD-2600190029.A31
2600190029
|
-
|
|
|
|
44 - ROTARY KNOB
BSD-2602026033.A15
2602026033
|
-
|
|
|
|
45 - RATCHET CAP
BSD-2600590006.A75
2600590006
|
£1.75
|
£2.10
|
|
|
46 - RATCHET CAP
BSD-2600590006.A76
2600590006
|
£1.75
|
£2.10
|
|
|
47 - SLOTTED SPRING PIN 4x30 MM DIN 7346
BSD-2917780105.A79
2917780105
|
£1.75
|
£2.10
|
|
|
48 - FELT WASHER
BSD-2600108077.A439
2600108077
|
£1.75
|
£2.10
|
|
|
49 - CUPPED WASHER
BSD-2600500002.A614
2600500002
|
£1.75
|
£2.10
|
|
|
50 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A350
2600905021
|
£8.67
|
£10.41
|
|
|
51 - ARMATURE 220-240V
BSD-2604010524.A34
2604010524
|
-
|
|
|
|
52 - FAN
BSD-2606610049.A58
2606610049
|
£2.16
|
£2.59
|
|
|
53 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A321
2916660008
|
£2.16
|
£2.59
|
|
|
54 - RECEPTACLE
BSD-2600400008.A512
2600400008
|
£1.75
|
£2.10
|
|
|
55 - MOTOR HOUSING
BSD-2605104116.A73
2605104116
|
-
|
|
|
|
56 - COVER DISC
BSD-2601328033.A266
2601328033
|
-
|
|
|
|
57 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A684
2603490017
|
£2.16
|
£2.59
|
|
|
58 - FIELD 220-230V
BSD-2604220491.A48
2604220491
|
£21.68
|
£26.01
|
|
|
59 - CABLE L=130 MM
BSD-2604448005.A276
2604448005
|
£1.75
|
£2.10
|
|
|
60 - BRUSH HOLDER
BSD-2604337003.A23
2604337003
|
£2.16
|
£2.59
|
|
|
60 - CONNECTING CABLE L=68 MM
BSD-2604448100.A116
2604448100
|
£1.75
|
£2.10
|
|
|
62 - BALL BEARING 7x22x7
BSD-1900905018.A306
1900905018
|
£18.96
|
£22.75
|
|
|
65 - SUPPRESSION FILTER
BSD-2604465068.A79
2604465068
|
-
|
|
|
|
66 - SWITCH
BSD-1617200089.A21
1617200089
|
-
|
|
|
|
67 - CABLE CLIP
BSD-2601035001.A1660
2601035001
|
£1.75
|
£2.10
|
|
|
68 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A387
2910611019
|
£2.80
|
£3.36
|
|
|
69 - SUPPRESSION FILTER
BSD-2607329096.A132
2607329096
|
£7.36
|
£8.83
|
|
|
70 - HOUSING COVER
BSD-2605132040.A23
2605132040
|
-
|
|
|
|
71 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A479
2603490023
|
£1.75
|
£2.10
|
|
|
72 - GROMMET dia6.9 MM
BSD-2600707059.A321
2600707059
|
£3.72
|
£4.47
|
|
|
72 - GROMMET dia11.6-dia12.5x84 MM
BSD-2600707060.A145
2600707060
|
£2.61
|
£3.13
|
|
|
72 - GROMMET dia8.8 MM
BSD-2600707061.A159
2600707061
|
£2.80
|
£3.36
|
|
|
74 - CABLE
BSD-2604448003.A38
2604448003
|
-
|
|
|
|
78 - STICKER
BSD-2601110093.A51
2601110093
|
-
|
|
|
|
79 - STICKER
BSD-2601110204.A1
2601110204
|
-
|
|
|
|
80 - STICKER
BSD-2601110205.A4
2601110205
|
-
|
|
|
|
82 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1967
2603410001
|
£1.75
|
£2.10
|
|
|
83 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A633
2603435015
|
£2.16
|
£2.59
|
|
|
85 - SHIM 0.5 MM
BSD-2600101020.A502
2600101020
|
£1.75
|
£2.10
|
|
|
85 - SHIM 0.2 MM
BSD-2600101022.A130
2600101022
|
£1.75
|
£2.10
|
|
|
85 - SHIM 0.3 MM
BSD-2600101023.A417
2600101023
|
£1.75
|
£2.10
|
|
|
87 - SHIM
BSD-2600150004.A646
2600150004
|
£2.16
|
£2.59
|
|
|
88 - STICKER
BSD-2601110230.A175
2601110230
|
-
|
|
|
|
92 - SHIM 0.5 MM
BSD-2600100623.A28
2600100623
|
-
|
|
|
|
94 - O-RING 12.0x1.0 MM
BSD-1600210024.A79
1600210024
|
-
|
|
|
|
95 - CHUCK dia1.5-13 MM. 1/2
BSD-1608571069.A349
1608571069
|
£23.86
|
£28.63
|
|
|
95/01 - CHUCK WRENCH SG2
BSD-2607950007.A100
2607950007
|
£6.52
|
£7.83
|
|
|
96 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A367
2603421226
|
£1.75
|
£2.10
|
|
|
97 - SHIM
BSD-2600150018.A18
2600150018
|
-
|
|
|
|
98 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A725
2603490024
|
£1.75
|
£2.10
|
|
|
651 - AUXILIARY HANDLE dia43 MM
BSD-1619P10682.A166
1619P10682
|
£12.49
|
£14.99
|
|
|
652 - WING NUT M6 DIN 315-G-GTW-40
BSD-2915191006.A25
2915191006
|
-
|
|
|
|
653 - HEX SCREW DIN 931-M6x75-8.8
BSD-2911011220.A68
2911011220
|
-
|
|
|
|
654 - CONICAL SPRING WASHER
BSD-2601098001.A7
2601098001
|
-
|
|
|
|
655 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001005.A206
1613001005
|
-
|
|
|
|
801 - LOCKING WASHER DIN 6799-7-FSt
BSD-2916080910.A240
2916080910
|
£2.16
|
£2.59
|
|
|
802 - GEAR HOUSING
BSD-2605806970.A3
2605806970
|
-
|
|
|
|
803 - INTERMEDIATE FLANGE
BSD-2605700931.A8
2605700931
|
-
|
|
|
|
804 - OVERLOAD CLUTCH
BSD-2606309907.A11
2606309907
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A61
2604321905
|
£11.30
|
£13.56
|
|
|
810/06 - RATCHET CAP
BSD-2601322013.A444
2601322013
|
£1.75
|
£2.10
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A4986
160111A3H3
|
£2.61
|
£3.13
|
|
