1 - MOTOR HOUSING
BSD-3605108175.A1
3605108175
|
£23.86
|
£28.63
|
|
|
3 - ARMATURE 115V
BSD-3604010017.A0
3604010017
|
£116.15
|
£139.38
|
|
|
3/60 - FAN
BSD-1606610122.A83
1606610122
|
£2.80
|
£3.36
|
|
|
4 - SWITCH
BSD-1607200076.A2
1607200076
|
£120.11
|
£144.13
|
|
|
4/10 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x12-5.8
BSD-2910011088.A3
2910011088
|
£1.75
|
£2.10
|
|
|
5 - ELEC. CABLE W/CONNECTION EU 2.65m 2 x 1.5mm H07RN-F
BSD-3604460021.A2
3604460021
|
-
|
|
|
|
6 - GROMMET dia7.9-dia12.0x120 MM
BSD-1600703022.A90
1600703022
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A499
1601302014
|
£2.61
|
£3.13
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-3601119129.A7
3601119129
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A266
1607328028
|
£5.30
|
£6.36
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A2099
2600905032
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING 9x26x8
BSD-3600905131.A17
3600905131
|
£11.30
|
£13.56
|
|
|
20 - TORX OVAL-HEAD SCREW
BSD-2914201507.A52
2914201507
|
£1.75
|
£2.10
|
|
|
21 - COMPRESSION SPRING
BSD-1604613006.A52
1604613006
|
£1.75
|
£2.10
|
|
|
23 - SEALING CAP
BSD-3605500090.A9
3605500090
|
£10.10
|
£12.12
|
|
|
24 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A661
2910211019
|
£1.75
|
£2.10
|
|
|
25 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A874
2910021118
|
£1.75
|
£2.10
|
|
|
26 - INTERMEDIATE RING
BSD-1600502011.A353
1600502011
|
£2.61
|
£3.13
|
|
|
29 - ROTARY SHAFT LIP SEAL
BSD-3600283043.A45
3600283043
|
£12.04
|
£14.45
|
|
|
30 - INTERMEDIATE RING
BSD-1600300090.A10
1600300090
|
£3.72
|
£4.47
|
|
|
32 - BEARING COVER
BSD-3605500156.A24
3605500156
|
£5.58
|
£6.70
|
|
|
33 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A445
2910211018
|
£1.75
|
£2.10
|
|
|
34 - AIR-DEFLECTOR RING
BSD-3600499006.A3
3600499006
|
£5.30
|
£6.36
|
|
|
35 - WIRE GUIDE
BSD-3601025003.A21
3601025003
|
£1.75
|
£2.10
|
|
|
36 - LENS HEAD SCREW
BSD-3603435039.A3
3603435039
|
£2.61
|
£3.13
|
|
|
38 - SPIRAL SPRING
BSD-3604652001.A37
3604652001
|
£2.61
|
£3.13
|
|
|
39 - TORX OVAL-HEAD SCREW
BSD-2914201527.A117
2914201527
|
£2.16
|
£2.59
|
|
|
40 - INSULATING PLATE 20x20x50 MM
BSD-1602381006.A146
1602381006
|
£1.75
|
£2.10
|
|
|
41 - THREAD-FORMING TAP. SCREW
BSD-3604411040.A11
3604411040
|
£2.61
|
£3.13
|
|
|
43 - MANUFACTURER'S NAMEPLATE
BSD-3601119902.A1
3601119902
|
£2.80
|
£3.36
|
|
|
44 - CONNECTING CABLE L=360 MM
BSD-3604460027.A30
3604460027
|
£6.52
|
£7.83
|
|
|
46 - CONNECTING CABLE L=375 MM
BSD-3604438027.A3
3604438027
|
£10.10
|
£12.12
|
|
|
47 - BLADE TERMINAL
BSD-1604477001.A31
1604477001
|
£1.75
|
£2.10
|
|
|
48 - ROTARY KNOB
BSD-3603231004.A8
3603231004
|
£21.52
|
£25.83
|
|
|
50 - STRAIGHT PIN DIN 6325-4m6x20
BSD-2917550099.A5
2917550099
|
£1.75
|
£2.10
|
|
|
51 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A62
1903230010
|
£1.75
|
£2.10
|
|
|
53 - CYLINDRICAL GEAR Z=35
BSD-3606317023.A4
3606317023
|
-
|
|
|
|
54 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A309
1600910018
|
£5.30
|
£6.36
|
|
|
55 - SHIM 0.5 MM
BSD-1600100617.A40
1600100617
|
£1.75
|
£2.10
|
|
|
56 - TOOTHED SHAFT Z=9
BSD-3606309014.A17
3606309014
|
£40.80
|
£48.96
|
|
|
57 - CYLINDRICAL GEAR Z=21
BSD-3606317024.A6
3606317024
|
£40.80
|
£48.96
|
|
|
58 - LOCATING WASHER
BSD-3600390015.A19
3600390015
|
£45.67
|
£54.80
|
|
|
59 - LOCATING WASHER
BSD-3600190009.A13
3600190009
|
£31.64
|
£37.97
|
|
|
60 - COUPLING PLATE
BSD-3600101030.A13
3600101030
|
£10.10
|
£12.12
|
|
|
62 - CYLINDRICAL GEAR Z=43
BSD-3606317022.A6
3606317022
|
£48.38
|
£58.06
|
|
|
63 - BALL PIN
BSD-3603126000.A16
3603126000
|
£5.30
|
£6.36
|
|
|
64 - COMPRESSION SPRING
BSD-3604610026.A13
3604610026
|
£2.16
|
£2.59
|
|
|
65 - SEAL
BSD-3601015009.A21
3601015009
|
£2.61
|
£3.13
|
|
|
66 - PRESSURE DISK
BSD-3600101029.A6
3600101029
|
£5.58
|
£6.70
|
|
|
67 - COLLAR SLEEVE
BSD-3600320009.A6
3600320009
|
£11.30
|
£13.56
|
|
|
68 - ROTARY KNOB
BSD-3603231005.A8
3603231005
|
£4.26
|
£5.11
|
|
|
69 - SHIM 0.2 MM
BSD-2600100575.A0
2600100575
|
£2.16
|
£2.59
|
|
|
69 - SHIM 0.3 MM
BSD-2600100576.A317
2600100576
|
-
|
|
|
|
69 - SHIM 0.5 MM
BSD-2600100577.A0
2600100577
|
£1.75
|
£2.10
|
|
|
70 - SPRING RETAINING RING DIN 471-10x1MM-FSt
BSD-2916650001.A96
2916650001
|
£2.61
|
£3.13
|
|
|
71 - STRAIGHT PIN 5 H 8x18 DIN 7
BSD-2917500121.A43
2917500121
|
£1.75
|
£2.10
|
|
|
72 - GROOVE BALL BEARING 15x32x9
BSD-1900905162.A62
1900905162
|
£18.96
|
£22.75
|
|
|
73 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A534
2916660013
|
£2.16
|
£2.59
|
|
|
74 - COMPRESSION SPRING
BSD-2604617000.A11
2604617000
|
£2.61
|
£3.13
|
|
|
75 - DISC SPRING
BSD-3600550004.A5
3600550004
|
£3.72
|
£4.47
|
|
|
77 - RATCHET CAP
BSD-2600590006.A88
2600590006
|
£1.75
|
£2.10
|
|
|
78 - NEEDLE BEARING
BSD-3600913008.A7
3600913008
|
£3.72
|
£4.47
|
|
|
80 - CONNECTING CABLE L=290 MM
BSD-1604445006.A26
1604445006
|
£5.58
|
£6.70
|
|
|
82 - RETAINING RING
BSD-3600224008.A18
3600224008
|
£2.16
|
£2.59
|
|
|
83 - HOLDING PLATE
BSD-3600190010.A6
3600190010
|
£1.75
|
£2.10
|
|
|
84 - COMPRESSION SPRING
BSD-3604611016.A3
3604611016
|
-
|
|
|
|
85 - PRESSURE SPINDLE
BSD-3603123003.A4
3603123003
|
£6.52
|
£7.83
|
|
|
86 - BUSHING
BSD-3600200011.A19
3600200011
|
£7.36
|
£8.83
|
|
|
87 - O-RING 6.0x2.0 MM
BSD-3600210028.A16
3600210028
|
£2.16
|
£2.59
|
|
|
88 - O-RING 27.0x3.0 MM
BSD-3600210027.A17
3600210027
|
£1.75
|
£2.10
|
|
|
90 - TAB WASHER
BSD-1601030022.A546
1601030022
|
£1.75
|
£2.10
|
|
|
92 - SHRINKABLE TUBE
BSD-3600707022.A56
3600707022
|
£3.72
|
£4.47
|
|
|
152 - FELT WASHER
BSD-3600200044.A6
3600200044
|
£2.80
|
£3.36
|
|
|
153 - COVER DISC
BSD-3600150027.A8
3600150027
|
£3.72
|
£4.47
|
|
|
651 - KEY CHUCK dia3-16MM.5/8
BSD-1608571083.A6
1608571083
|
£72.18
|
£86.62
|
|
|
651/8 - CHUCK WRENCH SG2
BSD-2607950011.A34
2607950011
|
£11.30
|
£13.56
|
|
|
652 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001008.A85
1613001008
|
£8.67
|
£10.41
|
|
|
653 - AUXILIARY HANDLE dia 43 MM
BSD-3602025012.A12
3602025012
|
£27.23
|
£32.68
|
|
|
653/10 - AUXILIARY HANDLE M8
BSD-1612025019.A109
1612025019
|
£6.52
|
£7.83
|
|
|
653/10/1 - AUXILIARY HANDLE
BSD-160202507H.A300
160202507H
|
£11.30
|
£13.56
|
|
|
653/20 - SUPPORT CLAMP
BSD-1618040077.A63
1618040077
|
-
|
|
|
|
653/30 - STUD BOLT M8
BSD-1613521001.A54
1613521001
|
£5.58
|
£6.70
|
|
|
653/40 - CLAMPING BAND dia43 MM
BSD-1611316003.A124
1611316003
|
£2.61
|
£3.13
|
|
|
653/50 - STRAIGHT PIN
BSD-1613100012.A122
1613100012
|
£2.61
|
£3.13
|
|
|
802 - FIELD 110-120V
BSD-3604220130.A1
3604220130
|
£72.18
|
£86.62
|
|
|
806 - END SPLICE DIN 46 228-A2.5-7
BSD-1900452003.A59
1900452003
|
£2.61
|
£3.13
|
|
|
808 - NAMEPLATE
BSD-160111A3HC.A264
160111A3HC
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-3607014012.A35
3607014012
|
£23.86
|
£28.63
|
|
|
816 - BRUSH HOLDER
BSD-3604336012.A141
3604336012
|
£5.58
|
£6.70
|
|
|
822 - SPINDLE HOUSING
BSD-3605806179.A15
3605806179
|
£81.81
|
£98.17
|
|
|
825 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A873
2910021118
|
£1.75
|
£2.10
|
|
|
827 - HANDLE
BSD-3605133017.A4
3605133017
|
£40.80
|
£48.96
|
|
|
828 - DRILLING SPINDLE 5/8. SW17
BSD-3607030413.A7
3607030413
|
£72.18
|
£86.62
|
|
|
831 - ROTARY SHAFT LIP SEAL
BSD-3600290070.A82
3600290070
|
£12.04
|
£14.45
|
|
|
832 - BEARING COVER
BSD-3605500043.A21
3605500043
|
£4.26
|
£5.11
|
|
|
835 - WIRE GUIDE
BSD-1601025001.A154
1601025001
|
£1.75
|
£2.10
|
|
|
837 - INTERMEDIATE BEARING
BSD-3605820078.A0
3605820078
|
£135.25
|
£162.30
|
|
|
844 - CONNECTING CABLE L=330 MM
BSD-1604438012.A69
1604438012
|
£7.36
|
£8.83
|
|
|
846 - CONNECTING CABLE L=345 MM
BSD-1604438013.A5
1604438013
|
£7.36
|
£8.83
|
|
|
851 - SPRING WASHER DIN 137-A 4-ST
BSD-2916060005.A64
2916060005
|
£1.75
|
£2.10
|
|
|
853 - CYLINDRICAL GEAR
BSD-3607030411.A12
3607030411
|
£48.38
|
£58.06
|
|
|
856 - CONTROL SHAFT
BSD-3607031177.A3
3607031177
|
£135.25
|
£162.30
|
|
|
861 - CYLINDRICAL GEAR Z=33
BSD-3607030274.A14
3607030274
|
£54.42
|
£65.30
|
|
