2 - GEAR HOUSING
BSD-2605806917.A1
2605806917
|
-
|
|
|
|
3 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A221
2910021122
|
£2.16
|
£2.59
|
|
|
4 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A599
2916690003
|
£1.75
|
£2.10
|
|
|
5 - HOUSING COVER
BSD-2605500017.A8
2605500017
|
-
|
|
|
|
6 - GROOVE BALL BEARING 10 MM DIN 625
BSD-2600905007.A120
2600905007
|
-
|
|
|
|
7 - CUPPED WASHER
BSD-2600500008.A12
2600500008
|
-
|
|
|
|
8 - FELT DISC
BSD-2600108020.A14
2600108020
|
-
|
|
|
|
9 - RECEPTACLE
BSD-2600400020.A81
2600400020
|
-
|
|
|
|
10 - BEARING BOLT
BSD-2603123009.A8
2603123009
|
-
|
|
|
|
11 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A181
2910021118
|
£1.75
|
£2.10
|
|
|
12 - SHIM 0.5 MM
BSD-2600101616.A29
2600101616
|
-
|
|
|
|
13 - NEEDLE-ROLLER CAGE
BSD-2600913027.A12
2600913027
|
-
|
|
|
|
14 - NEEDLE ROLLER 1.5x5.8 MM
BSD-2603201037.A18
2603201037
|
£2.61
|
£3.13
|
|
|
15 - CYLINDRICAL GEAR Z=50
BSD-2606319037.A1
2606319037
|
-
|
|
|
|
16 - SHIM 1.0 MM
BSD-2600102653.A59
2600102653
|
£1.75
|
£2.10
|
|
|
16 - SHIM 0.5 MM
BSD-2600102652.A169
2600102652
|
£1.75
|
£2.10
|
|
|
18 - FORK LEVER
BSD-2601923000.A16
2601923000
|
-
|
|
|
|
20 - SHIM 0.3 MM
BSD-2600100515.A95
2600100515
|
£2.61
|
£3.13
|
|
|
20 - SHIM 0.5 MM
BSD-2600100516.A130
2600100516
|
£2.16
|
£2.59
|
|
|
23 - SHIM 0.1 MM
BSD-2600100625.A1
2600100625
|
-
|
|
|
|
23 - SHIM 0.2 MM
BSD-2600100626.A237
2600100626
|
-
|
|
|
|
23 - SHIM 0.3 MM
BSD-2600100627.A1
2600100627
|
-
|
|
|
|
23 - SHIM 0.5 MM
BSD-2600100628.A297
2600100628
|
£1.75
|
£2.10
|
|
|
24 - COUNTERWEIGHT
BSD-2601015030.A25
2601015030
|
-
|
|
|
|
25 - ECCENTRIC DISC
BSD-2601072004.A2
2601072004
|
-
|
|
|
|
26 - SOCKET HEAD CAP SCREW DIN 84-AM4x10-8.8
BSD-2910020120.A0
2910020120
|
-
|
|
|
|
27 - SHIM 0.2 MM
BSD-2600100575.A77
2600100575
|
£2.16
|
£2.59
|
|
|
27 - SHIM 0.3 MM
BSD-2600100576.A238
2600100576
|
-
|
|
|
|
27 - SHIM 0.5 MM
BSD-2600100577.A80
2600100577
|
£1.75
|
£2.10
|
|
|
28 - LOCKING WASHER DIN 6799-7-FSt
BSD-2916080910.A57
2916080910
|
£2.16
|
£2.59
|
|
|
29 - LOCKING WASHER DIN 6799-5-FSt
BSD-2916080008.A1
2916080008
|
-
|
|
|
|
31 - ECCENTRIC DISC 0.3 MM
BSD-2601072006.A12
2601072006
|
-
|
|
|
|
31 - ECCENTRIC DISC 0.5 MM
BSD-2601072007.A2
2601072007
|
-
|
|
|
|
33 - NEEDLE-ROLLER CAGE
BSD-2600913010.A6
2600913010
|
-
|
|
|
|
34 - NEEDLE BEARING
BSD-2600917900.A102
2600917900
|
£8.67
|
£10.41
|
|
|
35 - SEALING PLATE
BSD-2601015039.A4
2601015039
|
-
|
|
|
|
36 - AIR ELIMINATOR
BSD-2602389001.A7
2602389001
|
-
|
|
|
|
37 - GEAR COVER
BSD-2605808902.A1
2605808902
|
-
|
|
|
|
37 - GEAR COVER
BSD-2605808901.A25
2605808901
|
-
|
|
|
|
38 - NEEDLE ROLLER A 3x15.8G2DIN5402
BSD-1903201044.A31
1903201044
|
£2.33
|
£2.80
|
|
|
39 - COMPRESSION SPRING
BSD-2604613000.A23
2604613000
|
£1.75
|
£2.10
|
|
|
40 - GUIDE
BSD-2601032014.A19
2601032014
|
-
|
|
|
|
42 - CLAMP SCREW
BSD-2603400000.A1
2603400000
|
£4.26
|
£5.11
|
|
|
43 - CLAMPING SADDLE
BSD-2602329011.A53
2602329011
|
£4.75
|
£5.70
|
|
|
44 - SLIDING PIECE 31/35 MM
BSD-2601321022.A1
2601321022
|
-
|
|
|
|
45 - COUNTERSUNK-HEAD SCREW DIN 7962-M3.5x8-10.9
BSD-2603421040.A260
2603421040
|
£1.75
|
£2.10
|
|
|
46 - SHIM 0.5 MM
BSD-2600101612.A227
2600101612
|
£1.75
|
£2.10
|
|
|
47 - SEAL RING 0.5 MM
BSD-2600290017.A148
2600290017
|
£1.75
|
£2.10
|
|
|
48 - SUPPORTING DISC 0.5 MM
BSD-2600112031.A225
2600112031
|
£1.75
|
£2.10
|
|
|
49 - SEALING PLATE
BSD-2601015900.A14
2601015900
|
-
|
|
|
|
50 - PIVOT PIN
BSD-2603105015.A8
2603105015
|
-
|
|
|
|
51 - GUIDE ROLLER
BSD-2607001018.A6
2607001018
|
-
|
|
|
|
52 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A572
2916080007
|
£2.61
|
£3.13
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM5x6-5.8
BSD-2910011148.A3
2910011148
|
£1.75
|
£2.10
|
|
|
55 - AXLE
BSD-2600326900.A21
2600326900
|
-
|
|
|
|
58 - LOCKING WASHER DIN 6799-2.3
BSD-2916080005.A13
2916080005
|
-
|
|
|
|
59 - SWITCH HANDLE
BSD-2607200042.A14
2607200042
|
-
|
|
|
|
60 - COMPRESSION SPRING
BSD-2604611023.A12
2604611023
|
-
|
|
|
|
61 - RATCHET SLEEVE
BSD-2600506002.A16
2600506002
|
-
|
|
|
|
62 - SHIM 0.5 MM
BSD-2600100568.A127
2600100568
|
£1.75
|
£2.10
|
|
|
62 - SHIM 1.0 MM
BSD-2600100569.A147
2600100569
|
£1.75
|
£2.10
|
|
|
62 - SHIM 0.3 MM
BSD-2600100570.A171
2600100570
|
£1.75
|
£2.10
|
|
|
63 - BASE PLATE
BSD-2601016038.A9
2601016038
|
-
|
|
|
|
64 - COUNTERSUNK-HEAD SCREW DIN 63-AM5x10-8.8
BSD-2910501152.A4
2910501152
|
-
|
|
|
|
65 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A142
1903201042
|
£2.16
|
£2.59
|
|
|
66 - SOCKET HEAD CAP SCREW DIN 84-AM4x25-8.8
BSD-2910021132.A67
2910021132
|
£1.75
|
£2.10
|
|
|
66 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A224
2910021122
|
£2.16
|
£2.59
|
|
|
73 - HEX NUT DIN 439-BM 4-04
BSD-2915051104.A61
2915051104
|
-
|
|
|
|
101 - GEAR HOUSING
BSD-2607010003.A57
2607010003
|
-
|
|
|
|
102 - COVER DISC
BSD-2600522009.A79
2600522009
|
-
|
|
|
|
103 - FIELD 220V
BSD-2604220251.A3
2604220251
|
-
|
|
|
|
103 - POLE SHOE 220V
BSD-2604220285.A2
2604220285
|
-
|
|
|
|
104 - COMPRESSION SPRING
BSD-2604611024.A58
2604611024
|
£2.16
|
£2.59
|
|
|
105 - COMMUTATOR END SHIELD
BSD-2607010004.A2
2607010004
|
-
|
|
|
|
106 - SQUARE NUT M4
BSD-2603320001.A166
2603320001
|
£1.75
|
£2.10
|
|
|
108 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A731
2910021125
|
£1.75
|
£2.10
|
|
|
113 - SPIRAL SPRING
BSD-2604652000.A117
2604652000
|
-
|
|
|
|
114 - CARBON-BRUSH SET
BSD-2604320902.A22
2604320902
|
-
|
|
|
|
115 - SOCKET HEAD CAP SCREW
BSD-2603410010.A175
2603410010
|
-
|
|
|
|
116 - NAMEPLATE
BSD-2601100038.A52
2601100038
|
-
|
|
|
|
117 - ARMATURE 220V
BSD-2604010389.A6
2604010389
|
-
|
|
|
|
118 - GROOVE BALL BEARING 6x19x6
BSD-1900905019.A143
1900905019
|
£14.91
|
£17.89
|
|
|
119 - SHIM
BSD-2600150003.A79
2600150003
|
£2.16
|
£2.59
|
|
|
120 - FAN
BSD-2606610013.A108
2606610013
|
-
|
|
|
|
121 - SHIM 0.5 MM
BSD-2600101657.A119
2600101657
|
-
|
|
|
|
121 - SHIM 0.2 MM
BSD-2600101655.A119
2600101655
|
-
|
|
|
|
121 - SHIM 0.3 MM
BSD-2600101656.A62
2600101656
|
-
|
|
|
|
123 - SUPPRESSION CAPACITOR
BSD-2607329056.A56
2607329056
|
-
|
|
|
|
124 - ON-OFF SWITCH
BSD-2607200048.A75
2607200048
|
-
|
|
|
|
125 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A114
2603410023
|
-
|
|
|
|
126 - ELEC. CABLE W/CONNECTION
BSD-2604460080.A1
2604460080
|
-
|
|
|
|
127 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A589
2600703012
|
£2.80
|
£3.36
|
|
|
127 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A621
2600703013
|
£2.61
|
£3.13
|
|
|
127 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A618
2600703011
|
£2.80
|
£3.36
|
|
|
128 - CABLE CLIP
BSD-2601035001.A2275
2601035001
|
£1.75
|
£2.10
|
|
|
129 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A279
2910211019
|
£1.75
|
£2.10
|
|
|
130 - MANUFACTURER'S NAMEPLATE
BSD-1601110013.A127
1601110013
|
-
|
|
|
|
131 - HOUSING COVER
BSD-2605500028.A4
2605500028
|
-
|
|
|
|
132 - TAPPING SCREW DIN 7971-3.9x38
BSD-2910215093.A34
2910215093
|
-
|
|
|
|
133 - AUXILIARY HANDLE
BSD-2602025025.A2
2602025025
|
-
|
|
|
|
134 - STRAP-SHAPED HANDLE
BSD-2602025026.A10
2602025026
|
-
|
|
|
|
135 - SOCKET HEAD CAP SCREW DIN 84-AM5x12-8.8
BSD-2910021154.A157
2910021154
|
£1.75
|
£2.10
|
|
|
136 - TAPPING SCREW DIN 7971-BZ3.9x25
BSD-2910211022.A116
2910211022
|
£1.75
|
£2.10
|
|
|
137 - SOCKET HEAD CAP SCREW DIN 84-BM4x30-8.8
BSD-2910021134.A212
2910021134
|
£1.75
|
£2.10
|
|
|
138 - CONNECTING TERMINAL
BSD-2604490003.A8
2604490003
|
-
|
|
|
|
139 - SOCKET HEAD CAP SCREW
BSD-2603410009.A20
2603410009
|
£1.32
|
£1.58
|
|
|
140 - CONNECTING CABLE L = 58 MM
BSD-2604412016.A8
2604412016
|
-
|
|
|
|
141 - SPRING LOCK WASHER DIN 128-A5-FST
BSD-2916690004.A148
2916690004
|
£1.75
|
£2.10
|
|
|
142 - NON-WW POTENTIOMETER
BSD-2604505009.A8
2604505009
|
-
|
|
|
|
143 - FIXING PLATE
BSD-2600099000.A8
2600099000
|
-
|
|
|
|
144 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A352
2910211005
|
£1.75
|
£2.10
|
|
|
146 - NON-WW POTENTIOMETER
BSD-2604505004.A5
2604505004
|
-
|
|
|
|
147 - ROUND-HEAD GROOVED PIN
BSD-2603133000.A4
2603133000
|
-
|
|
|
|
148 - SOCKET HEAD CAP SCREW DIN 84-AM3x4-5.8
BSD-2910011047.A5
2910011047
|
-
|
|
|
|
149 - CONNECTING CABLE L = 303 MM
BSD-2604412013.A5
2604412013
|
-
|
|
|
|
150 - CONNECTING CABLE L = 368 MM
BSD-2604412011.A8
2604412011
|
-
|
|
|
|
151 - ELEC. CABLE W/CONNECTION L = 273 MM
BSD-2604440001.A5
2604440001
|
-
|
|
|
|
152 - ON-OFF SWITCH
BSD-2607200141.A8
2607200141
|
-
|
|
|
|
153 - SWITCH-PAWL
BSD-2602098003.A9
2602098003
|
-
|
|
|
|
154 - TAPPING SCREW DIN 7971-BZ2.2x6.5
BSD-2910211001.A12
2910211001
|
-
|
|
|
|
155 - CONNECTING CABLE L = 303 MM
BSD-2604440004.A8
2604440004
|
-
|
|
|
|
156 - CONNECTING CABLE L = 243 MM
BSD-2604412009.A5
2604412009
|
-
|
|
|
|
159 - TAPPING SCREW DIN 7971-BZ2.9x6.5
BSD-2910211004.A1
2910211004
|
-
|
|
|
|
160 - SINTERED-METAL BUSHING
BSD-2600301046.A206
2600301046
|
£3.72
|
£4.47
|
|
|
161 - BUSHING
BSD-2600301045.A21
2600301045
|
£2.80
|
£3.36
|
|
|
200 - COOLANT TANK
BSD-2605405005.A4
2605405005
|
-
|
|
|
|
201 - COOLANT TANK
BSD-2605405004.A9
2605405004
|
-
|
|
|
|
202 - VALVE NEEDLE
BSD-2603102003.A9
2603102003
|
-
|
|
|
|
203 - SPRING RETAINING RING DIN 471-6x0.7-FSt
BSD-2916640003.A21
2916640003
|
-
|
|
|
|
204 - PLAIN WASHER DIN 433-6.4-ST 50
BSD-2916011013.A49
2916011013
|
£1.75
|
£2.10
|
|
|
205 - COMPRESSION SPRING
BSD-2604610002.A4
2604610002
|
-
|
|
|
|
206 - VALVE BOTTOM
BSD-2600760001.A9
2600760001
|
-
|
|
|
|
207 - HEX NUT DIN 439-BM8-04
BSD-2915051107.A21
2915051107
|
£1.75
|
£2.10
|
|
|
208 - RESERVOIR CAP
BSD-2600502005.A1
2600502005
|
-
|
|
|
|
210 - RETAINING BRACKET
BSD-2601331016.A0
2601331016
|
-
|
|
|
|
211 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-5.8
BSD-2910011122.A103
2910011122
|
-
|
|
|
|
212 - HEX NUT DIN 439-BM 4-04
BSD-2915051104.A62
2915051104
|
-
|
|
|
|
213 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A600
2916690003
|
£1.75
|
£2.10
|
|
|
214 - STUD BOLT
BSD-2603465007.A12
2603465007
|
-
|
|
|
|
215 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A180
2910021118
|
£1.75
|
£2.10
|
|
|
216 - PLAIN WASHER 8.4 DIN 433-ST
BSD-2916011015.A22
2916011015
|
£1.75
|
£2.10
|
|
|
231 - SUPPORT CLAMP
BSD-2608598001.A15
2608598001
|
-
|
|
|
|
232 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A271
2910011157
|
-
|
|
|
|
233 - SPRING LOCK WASHER DIN 128-A5-FST
BSD-2916690004.A147
2916690004
|
£1.75
|
£2.10
|
|
|
654 - SAW BLADE SET T 101 B
BSD-2608630030.A5
2608630030
|
£8.01
|
£9.61
|
|
|
655 - SAW BLADE SET HCS
BSD-2608630033.A8
2608630033
|
£4.02
|
£4.82
|
|
|
656 - SAW BLADE SET
BSD-2608630040.A5
2608630040
|
£6.22
|
£7.47
|
|
|
657 - SAW BLADE SET
BSD-2608631013.A8
2608631013
|
£7.72
|
£9.26
|
|
|
841 - LIFTING ROD
BSD-2600780913.A95
2600780913
|
-
|
|
|
