1 - HOUSING COVER
BSD-3600508023.A60
3600508023
|
£13.41
|
£16.09
|
|
|
2 - COUNTERSUNK-HEAD SCREW DIN 63-AM3.5x8-5.8
BSD-2910501084.A85
2910501084
|
-
|
|
|
|
3 - GROMMET dia7 MM
BSD-2600703007.A286
2600703007
|
-
|
|
|
|
3 - GROMMET dia8.2 MM
BSD-2600703008.A49
2600703008
|
£1.75
|
£2.10
|
|
|
3 - GROMMET dia8.2 MM
BSD-2600703008.A50
2600703008
|
£1.75
|
£2.10
|
|
|
3 - GROMMET dia9.5 MM
BSD-2600703006.A98
2600703006
|
-
|
|
|
|
4 - HEX SCREW
BSD-2603527004.A86
2603527004
|
£1.75
|
£2.10
|
|
|
5 - FASTENING CLAMP
BSD-2601301002.A93
2601301002
|
£2.16
|
£2.59
|
|
|
6 - SUPPRESSION FILTER
BSD-2607329048.A73
2607329048
|
-
|
|
|
|
8 - SPIRAL SPRING
BSD-2604652000.A140
2604652000
|
-
|
|
|
|
9 - CLAMPING SADDLE
BSD-2601321005.A73
2601321005
|
-
|
|
|
|
10 - SOCKET HEAD CAP SCREW
BSD-2603410010.A215
2603410010
|
-
|
|
|
|
12 - SOCKET HEAD CAP SCREW M 2.6x5 DIN 84
BSD-2910011028.A36
2910011028
|
-
|
|
|
|
13 - CLAMPING PIECE
BSD-2602305034.A4
2602305034
|
-
|
|
|
|
14 - CONNECTING TERMINAL
BSD-2604490003.A23
2604490003
|
-
|
|
|
|
15 - HEX NUT M 2.6 DIN 934-M-6
BSD-2915011002.A8
2915011002
|
-
|
|
|
|
16 - MOTOR HOUSING
BSD-2605108032.A75
2605108032
|
-
|
|
|
|
17 - INSULATING PART
BSD-2601322002.A82
2601322002
|
£1.75
|
£2.10
|
|
|
18 - CABLE
BSD-2604411061.A31
2604411061
|
-
|
|
|
|
19 - SWITCH
BSD-2607200045.A16
2607200045
|
-
|
|
|
|
20 - COUNTERSUNK-HEAD SCREW M 3x6 DIN 63-5.8
BSD-2910501048.A12
2910501048
|
-
|
|
|
|
21 - MANUFACTURER'S NAMEPLATE
BSD-2601007003.A195
2601007003
|
-
|
|
|
|
22 - HEX NUT M 2.6 DIN 934-M-6
BSD-2915011002.A9
2915011002
|
-
|
|
|
|
23 - CABLE CLIP
BSD-2601035005.A27
2601035005
|
£1.75
|
£2.10
|
|
|
24 - SOCKET HEAD CAP SCREW DIN 84-AM2.6x15-5.8
BSD-2910011033.A15
2910011033
|
-
|
|
|
|
25 - HEX NUT DIN 439-BM 3
BSD-2915051103.A15
2915051103
|
£1.75
|
£2.10
|
|
|
26 - SPRING LOCK WASHER A3-FSt
BSD-2916690001.A124
2916690001
|
-
|
|
|
|
27 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A46
2916011005
|
£1.75
|
£2.10
|
|
|
28 - HEX NUT DIN 934-M 3-m-8
BSD-2915011003.A103
2915011003
|
£1.75
|
£2.10
|
|
|
29 - NAMEPLATE
BSD-2601100038.A58
2601100038
|
-
|
|
|
|
30 - ROUND-HEAD GROOVED PIN 2x3 DIN 1476 ST
BSD-2917724031.A8
2917724031
|
-
|
|
|
|
31 - SOCKET HEAD CAP SCREW DIN 84-BM3x50-5.8
BSD-2910011074.A66
2910011074
|
£1.75
|
£2.10
|
|
|
32 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A45
2916011005
|
£1.75
|
£2.10
|
|
|
33 - CABLE CLIP
BSD-2601099015.A31
2601099015
|
£1.75
|
£2.10
|
|
|
34 - FIELD 220-230V
BSD-2604220269.A31
2604220269
|
-
|
|
|
|
35 - SEAL RING
BSD-2600113019.A9
2600113019
|
£2.80
|
£3.36
|
|
|
36 - SHIM
BSD-2600100699.A75
2600100699
|
£1.75
|
£2.10
|
|
|
37 - SHIM
BSD-2600150002.A72
2600150002
|
-
|
|
|
|
38 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A53
1900905015
|
£30.42
|
£36.51
|
|
|
39 - SHIM 0.3 MM
BSD-2600100612.A73
2600100612
|
£2.61
|
£3.13
|
|
|
40 - ARMATURE 220-230V
BSD-2604010275.A7
2604010275
|
-
|
|
|
|
41 - FAN
BSD-2606610038.A41
2606610038
|
-
|
|
|
|
42 - GROOVE BALL BEARING 609-ZY DIN 625
BSD-1900905007.A108
1900905007
|
-
|
|
|
|
43 - BEARING SLEEVE
BSD-2600300044.A22
2600300044
|
-
|
|
|
|
44 - CUPPED WASHER
BSD-2600500017.A58
2600500017
|
£1.75
|
£2.10
|
|
|
45 - FELT WASHER
BSD-2600108026.A68
2600108026
|
£1.75
|
£2.10
|
|
|
46 - INTERMEDIATE BEARING
BSD-2605700135.A8
2605700135
|
-
|
|
|
|
47 - SOCKET HEAD CAP SCREW
BSD-1603410007.A6
1603410007
|
-
|
|
|
|
48 - TOOTHED GEAR Z=43
BSD-1606316012.A2
1606316012
|
-
|
|
|
|
49 - SPRING RETAINING RING DIN 472-26x1.2 MM
BSD-2916660010.A36
2916660010
|
£1.75
|
£2.10
|
|
|
50 - SPACER SLEEVE
BSD-1600300071.A4
1600300071
|
-
|
|
|
|
51 - GROOVE BALL BEARING
BSD-3600900025.A28
3600900025
|
£8.67
|
£10.41
|
|
|
52 - GUIDE
BSD-1609223006.A8
1609223006
|
-
|
|
|
|
53 - ECCENTRIC SHAFT
BSD-1606110001.A8
1606110001
|
-
|
|
|
|
54 - NEEDLE-ROLLER BEARING
BSD-1609269002.A2
1609269002
|
-
|
|
|
|
55 - CLAMP RING
BSD-1600224032.A4
1600224032
|
-
|
|
|
|
56 - GROOVE BALL BEARING 609-ZY DIN 625
BSD-1900905007.A107
1900905007
|
-
|
|
|
|
57 - SINTERED-METAL BUSHING
BSD-1900301005.A8
1900301005
|
-
|
|
|
|
58 - SHIM 0.3 MM
BSD-2600100612.A74
2600100612
|
£2.61
|
£3.13
|
|
|
59 - TOOTHED SHAFT Z=31/12
BSD-1606328085.A7
1606328085
|
-
|
|
|
|
60 - GROOVE BALL BEARING 5x16x5
BSD-1900900232.A64
1900900232
|
£16.74
|
£20.09
|
|
|
61 - GEAR HOUSING
BSD-1605110022.A2
1605110022
|
-
|
|
|
|
62 - CONNECTING ROD
BSD-1602001004.A5
1602001004
|
-
|
|
|
|
63 - CONROD PIN
BSD-1603100025.A4
1603100025
|
-
|
|
|
|
64 - TAPPET
BSD-1603104008.A5
1603104008
|
-
|
|
|
|
65 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A638
2916690003
|
£1.75
|
£2.10
|
|
|
66 - SOCKET HEAD CAP SCREW DIN 84-BM4x40-8.8
BSD-2910021138.A63
2910021138
|
£2.61
|
£3.13
|
|
|
67 - CUT-OFF PUNCH
BSD-1608635032.A6
1608635032
|
-
|
|
|
|
68 - THREADED RING
BSD-1603344046.A5
1603344046
|
-
|
|
|
|
69 - TRANSVERSE MEMBER
BSD-1603121015.A3
1603121015
|
-
|
|
|
|
70 - SET SCREW
BSD-1603402014.A3
1603402014
|
-
|
|
|
|
71 - SUPPORT PIN
BSD-1603501016.A4
1603501016
|
-
|
|
|
|
72 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x25-8.8
BSD-2910141164.A150
2910141164
|
£2.16
|
£2.59
|
|
|
73 - PISTON RING
BSD-1609202007.A2
1609202007
|
-
|
|
|
|
74 - SUPPORTING PAN
BSD-1600311006.A4
1600311006
|
-
|
|
|
|
75 - HEX SCREW
BSD-1603300007.A5
1603300007
|
-
|
|
|
|
76 - GUIDE SLEEVE
BSD-1600361009.A5
1600361009
|
-
|
|
|
|
77 - GUIDE BUSHING
BSD-1603314007.A3
1603314007
|
-
|
|
|
|
78 - LOWER DIE
BSD-1608635031.A2
1608635031
|
-
|
|
|
|
79 - DIE CARRIER
BSD-1608042004.A2
1608042004
|
-
|
|
|
|
80 - HEX SOCKET HEAD CAP SCREW DIN 912-M5X16-8.8
BSD-2910141158.A159
2910141158
|
£1.75
|
£2.10
|
|
|
81 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H05 VV-F
BSD-1604460427.A124
1604460427
|
£12.04
|
£14.45
|
|
|
602 - KEY
BSD-1607950033.A7
1607950033
|
-
|
|
|
|
603 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A556
2607950004
|
£1.75
|
£2.10
|
|
|
800 - GEAR HEAD
BSD-1608584007.A7
1608584007
|
-
|
|
|
|
807 - CARBON-BRUSH SET
BSD-2604320905.A82
2604320905
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3977
160111A3H3
|
£2.61
|
£3.13
|
|
